OPERATING INSTRUCTIONS
Dishwasher DFI664XXL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DFI664XXL and is the answer not in the manual?

Questions and answers

Related Manuals for Asko DFI664XXL

Summary of Contents for Asko DFI664XXL

  • Page 1 OPERATING INSTRUCTIONS Dishwasher DFI664XXL...

  • Page 2: Table Of Contents

    To switch on the dishwasher, press and hold the main power switch until the display lights up. "Welcome to your new ASKO. This is a first time set up." is shown on the display the first time the dishwasher is switched on. It is important that you choose the right settings to ensure good dishwashing results.

  • Page 3: Important Safety Instructions

    Important safety instructions SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE Should a child swallow dishwasher detergent or rinse aid, give plenty to drink immediately, i.e., one or two glasses of milk or water. Do not try to induce vomiting. Seek medical advice immediately: WARNING! Call the National Capital Poison Center at 1-800-222-1222.

  • Page 4: Before Washing For The First Time

    "Welcome to your new ASKO. This is a first time set up." is shown In general, more rinse aid and detergent are needed for hard water. on the display. It is important that you choose the right settings to ensure good dishwashing results.

  • Page 5: Loading The Dishwasher

    Loading the dishwasher 3. Top up with rinse aid Energy-efficient dishwashing Use rinse aid to improve wash and dry times. Also use rinse aid to Run programs only with a full load achieve clear and spotless results. Wait until the dishwasher is fully loaded before running a program, this way you save energy.
  • Page 6 Fragile dishes The baskets Some cookware is not dishwasher safe. This can be for several reasons. The dishwasher includes a top cutlery tray, an upper basket, and a Some materials cannot withstand high temperatures, others can be lower basket with a cutlery basket. damaged by dishwasher detergent.
  • Page 7 Raising the upper basket Washing large plates 1 Pull out the upper basket. Move adjustable tines and their mounts to widen the distance between the tine rows to adapt the lower basket to plates with a diameter greater 2 Grab the sides of the upper basket with both hands and lift it up. than 9 3/4"...

  • Page 8: Using The Dishwasher

    Using the dishwasher Typical load for 10 place settings Add detergent Upper basket with 10 place settings AHAM DW-1 Press to open 1 Prewash detergent compartment 2 Main wash detergent compartment Detergent is added according to water hardness. Follow the instructions on the detergent packaging. Too much detergent can result in less effective dishwashing and also entails greater environmental impact.
  • Page 9 Press and hold the main power switch until the display lights up. Starting the dishwasher START STOP 2:00 Speed mode Select the program Select a program mode Select any options been used without dried leftovers can also be washed using this The main power switch program.
  • Page 10 1 Press the button once to activate Delayed Start. Press the button If the dishwasher is turned off due to a several times – or hold it in – to set the desired number of hours. power failure 2 Press Start/Stop and close the door. The timer counts down and the dishwasher starts after the selected delay.

  • Page 12: Settings

    Settings Open the dishwasher's Settings menu To open the dishwasher's Settings menu, press the Navigation button until Settings menu is shown on the display and confirm your selection with the mode selector To exit the dishwasher's Settings menu, select Exit and confirm your selection with the mode selector Navigation buttons for choosing setting Mode selector to confirm current setting START...
  • Page 13 Settings Options Super rinse On/Off Super rinse adds two extra rinses. Activated in the following programs: Normal wash ECO wash Sanitation wash Plastic wash Lower half Upper half High temperature On/Off Activate the setting High temperature to improve the dishwashing results.

  • Page 14: Care And Maintenance Instructions

    Care and maintenance instructions Top spray arm Coarse filter The upper basket must be removed before the top spray arm can The coarse filter traps larger food particles, which cannot get past the be released. Extend the upper basket then rotate the basket catch drain pump.
  • Page 15 Shut off the water. Unblocking the drain pump Unplug the unit from the power outlet. If the dishwasher still contains water after the program has finished, Call the Customer Care Center. something may be blocking the drain pump. Such items are easily removed.

  • Page 16: Troubleshooting

    Troubleshooting Type of fault on the display Action Overfilling water 1 Clear the drain pump. See the section Care and maintenance instructions. If the problem persists, call the Customer Care Center. Water outlet fault See “Water remains in the dishwasher above the filters” in the table “Problem” below. If the problem persists, call the Customer Care Center.
  • Page 17 Problem Possible causes Action The dishes are not clean. The spray arms do not rotate. Check that the dishes are not blocking the spray arms. Spray arm holes or bearings blocked. Clean the spray arms. See the chapter Care and maintenance instructions.
  • Page 18 Problem Possible causes Action Water remains in the dishwasher above the filters. The filters are blocked. Clean the coarse and fine filters. The filters are not fitted correctly. Check that the filter handle is locked in the stop position. The handle should point straight out from the dishwasher.

  • Page 19: Technical Information

    Technical information Technical data Height: 33 7/8 -36" Width: 24" Depth: 22" Weight: 110 lb (50 kg) Water pressure: 4.2–140 psi Electrical connection: See serial number plate Rated power: See serial number plate Weight can vary due to different specifications.

  • Page 20: Installation Instructions

    Installation instructions [''] 48 3/4 1 1/8 - 3 3/4 * If European widths of 23 5/8'' (600 mm) is required, remove the trim kit. **Door length. Nominal dimensions. Actual measurements may vary. It is important that you read through and follow the instructions and [''] directions below.
  • Page 21 a path of least resistance for electric current. This appliance is Drain connection equipped with a cord fitted with an equipment grounding conductor See the separate installation instructions for necessary information. and a grounding plug. The plug must be plugged into an appropriate outlet that is installed and grounded in accordance with all local codes This dishwasher is suitable for installing in a raised recess (to attain and ordinances.

  • Page 22: Service

    Some jurisdictions do not allow exclusion or limitations regarding by ASKO, that this ASKO Product is free of defects in materials and/or warranty rights. This Limited Warranty gives you specific legal rights workmanship, subject to the terms and conditions set forth herein.

  • Page 23: Notes

    Notes...

  • Page 24: Quick Start Guide

    Quick start guide Load the baskets (See page 5.) Do not rinse dishes under running water before loading them in the dishwasher. Simply scrape off large food particles before loading the dishwasher. Check that the spray arms can rotate freely Check also that the water supply valve is on.
