- Page 1 T E C H N I C A L R E F E R E N C E & M A N U A L DMX MEGA STROBE DMX-750 CHAUVET 3000 North 29 Hollywood, FL 33020 USA Tel: 954-929-1115 Fax: 954-929-5560...
-
Page 2: Table Of Contents
General Troubleshooting ... 12 Issue Date: December 2003 Rev. No. Version 1.00 1.10 DMX-750 Manual Version 1.1 Date Description Dec 2003 DMX-750 Users Guide version 1.00: Author: V.M. at CHAUVET Feb 2004 DMX-750 Users Guide version 1.10: Author: V.M. at CHAUVET... -
Page 3: Warranty Information
If this product is not covered under the terms of this warranty, CHAUVET will advise you of the costs to carry out any repairs necessary and the unit will be shipped to you on receipt of payment for the work including the return freight charges. -
Page 4: Introduction
Introduction Product Overview Thank you for purchasing the “DMX Mega Strobe” Model Number DMX-750. It is a very powerful and high output xenon strobe with enhanced features. It can operate in a sound to light mode and using any universal DMX control device. Enhanced operational manual controls using dip switches provide for both controls of intensity as well as a flash rate. -
Page 5: Technical Specifications
0-100% via dipswitches Programmable using any universal DMX controller. Warranty 2 Year Limited Warranty What is enclosed? Manual / Warranty Card DMX-750 Mega Strobe Lamp (CH750B) Installed Power cord with plug (affixed to device) Mounting bracket with knobs DMX-750 Manual Version 1.1... -
Page 6: Before You Begin
All fixtures must be connected to circuits with a suitable Earth Ground. Check the fixture or device carefully to make sure that if a voltage selection switch exists that it is set to the correct line voltage you will use. DMX-750 Manual Version 1.1... -
Page 7: Warnings
Read the booklet that accompanies each lamp and heed attention to the warnings concerning exposure to skin and eyes. Use appropriate eye protection to block all UV rays. Do not use ordinary sunglasses. DMX-750 Manual Version 1.1... -
Page 8: Operating Instructions
Operating Instructions General The DMX-750 is a 750 watt high output xenon strobe light that can be remotely operated using any universal DMX 512 controller. It is well suited for large rooms and can be daisy chained with additional DMX-750 strobes. -
Page 9: Self-Test Mode
1, 2 1, 4 2, 3 1, 2, 3 DMX-750 Manual Version 1.1 SWITCH VALUE 233 – (128) = 105, Turn ON Dip # 8 105 – (64) = 41, Turn ON Dip # 7 41 – (32) = 9, Turn ON Dip # 6 9 –... -
Page 10: Automatic Sound-To-Light Mode
DMX Channel Attributes Channel Value 0 – 254 0 – 255 Hyper-flash Effect (Blinder Mode) 43 - 254 Sound to Light (Audio Mode) DMX-750 Manual Version 1.1 Continuation from previous table. Speed Level Slowest Fastest Dip Switch Function 1 – 8 9 –... -
Page 11: Appendix
Return Merchandise Authorization Number (RA #). Products returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the customer’s... -
Page 12: General Troubleshooting
Check cable connections Remote does not work Make sure connector is firmly connected to device Stand alone mode All Chauvet lighting fixtures featuring stand-alone functions do not require additional settings, simply power the fixture and it will automatically enter into this mode...
