- Page 1 H2THD QUICK SETUP GUIDE Home & Business SECURITY SYSTEMS QSG-H2THD.indd 1 2018/7/10 10:50...
-
Page 2: What's In The Box
LAN3 LAN4 Monitor Router NOTE: Monitor is required Mounting Hardware Metal Base for initial setup. (1 per IP camera) IMPORTANT: For best results, use all the included Night Owl accessories. Third-party accessories may not work properly. QSG-H2THD.indd 2 2018/7/10 10:50... -
Page 3: Product Overview
Product Overview DVR Rear View NOTE: Not all models have a power switch on the DVR. SYNC WIRED / Images used are for reference only. Your product may vary slightly. A 4 channel model is displayed above. Sync – Press and release to sync the DVR with the wireless cameras. Video Inputs –... -
Page 4: Connecting Your System
Connecting Your System HDMI HDMI SYNC WIRED / NOTE: Monitor is required for initial setup. view cameras, TV/Monitor must be tuned to the same Input the HDMI is plugged into. Plug included HDMI cable into Plug the other end of the HDMI the HDMI port on the back of cable into the back of the TV the DVR. - Page 5 Connecting Your Wired Cameras FROM Camera TO Camera SYNC WIRED / NOTE: Audio enabled cameras will have a white RCA connector to transmit audio NOTE: Make sure you twist and lock BNC connectors. signal (Optional). Connect the ends of the cable Connect the BNC connector of the attached to the camera to the video/power cable labeled TO DVR...
- Page 6 Connecting Your Wireless Indoor IP Cameras You MUST test the Wireless Indoor IP Cameras locally before mounting. (DO NOT MOUNT OUTDOORS. SERIOUSLY!) Plug the camera(s) in next to the DVR to make sure video is transmitted. The camera(s) are already in pairing mode. Insert the small end of the micro USB cable into the camera and the other end into the USB power supply.
- Page 7 Be patient as the camera(s) power up. It may take a couple of minutes. Once the camera(s) are powered up, video will be transmitted to the DVR. NOTE: If you see the camera(s) live view, you can move the camera(s) to the mounting location(s).
-
Page 8: Startup Wizard
Remember Your Password Night Owl strongly recommends writing down your password within the Quick Setup Guide. You will need it every time you log into your DVR and to remotely view on a Smart Device. - Page 9 When you reach the Camera / Channel Settings screen, you will want to have installed the cameras in their final position. Please make sure you have mounted cameras at least 7ft. above the ground and angled them slightly down. NOTE: If your camera has an infrared sensor, it works best for ‘side to...
- Page 10 Password Reset Instructions Did you forget your password? Right click the mouse to bring up the system menu. Select the login screen. Click on the “Forget Password” button. A reset code will be sent to the email address entered during account setup. NOTE: Make sure you enter a VALID email address.
- Page 11 Night Owl X & Night Owl X HD Mobile Apps Night Owl fits right in with your mobile lifestyle by allowing you to remotely monitor your home or business. Our free and exclusive Night Owl X App for iOS ®...
- Page 12 NOTE: Check your spam/junk inbox. You MUST complete Step 3 before continuing! Go to your email, open the Confirmation email from Night Owl, and click the “Confirm Email” link. You MUST confirm your email to use the app! QSG-H2THD.indd 12...
-
Page 13: Adding A Device
When adding a new device, it may take 5–10 minutes before you begin receiving notifications. A device can be added to the Night Owl X and Night Owl X HD App by using the application’s Smart Auto Detection or through a QR Code Setup. With... - Page 14 On the Device Login screen, enter the login information for the DVR (Remember, the DVR login and Night Owl X and Night Owl X HD App login are different). The DVR username is admin by default. If you are not the admin, login with your username credentials.
-
Page 15: App Overview
App Overview Live View Displays real-time footage of your system. Settings Playback Notifications Display connected devices, View recordings & Manage custom change view layout, view images and save them Push Notifications. favorites, manage accounts to your phone’s album. and access the help section. QSG-H2THD.indd 15 2018/7/10 10:50... -
Page 16: Device Manager
PC or Mac cameras on your network. ® Night Owl X CMS Software The Night Owl X Control Management Software (CMS) allows you to view your Night Owl Security system remotely from a PC or Mac . Additionally, ®... - Page 17 W² Fusion Hybrid Technology ™ Wired and Wireless Connectivity Wired Wired • Uninterrupted viewing and recording • Uninterrupted viewing and recording • No interference from other Wi-Fi devices • No interference from other Wi-Fi devices • Internet only required for remote viewing •...
-
Page 18: Frequently Asked Questions
DVR’s admin password. Remember, you MUST confirm your email by clicking the “Confirm Email” link in the verification email sent by Night Owl during setup. 6. Why can’t I connect using the Night Owl X App, Night Owl X HD App or Night Owl X CMS Software? If you are having trouble connecting using the mobile app or client software: A) your system may not be connected to a router;... - Page 19 9. Wireless 1080p cameras include 2-way audio. Wired 4K cameras are not audio enabled. 10. Wireless 1080p cameras do not work independently and must be ® connected to this Night Owl Hybrid DVR. These cameras are ONLY compatible with an HTHD Series DVR. These are NOT stand-alone cameras.
-
Page 20: Need Help
Need Help? CONTACT US For system manuals, troubleshooting guides, FAQs, video tutorials and more: PHONE (English, Spanish & French) Sales/Technical Support Please refer to the sticker located on top of 1.866.390.1303 the device for steps on how to access your Live Chat 24/7, 365 days a year product’s support material.
