Amana ABB1921WEW2 User Instructions

Quick Links

Download this manual

THANK YOU for purchasing this high-quality product. If you should experience a problem not covered in TROUBLESHOOTING,

please visit our website at www.amana.com for additional information. If you still need assistance, call us at 1-800-843-0304.

In Canada, visit our website at www.amanacanada.ca or call us at 1-800-807-6777.

You will need your model and serial number, located on the inside wall of the refrigerator compartment.

REFRIGERATOR SAFETY ............................... 1

INSTALLATION INSTRUCTIONS.................... 2

REFRIGERATOR USE.................................... 11

REFRIGERATOR CARE ................................. 13

TROUBLESHOOTING .................................... 14

WATER FILTER CERTIFICATIONS............... 16

PERFORMANCE DATA SHEETS .................. 17

WARRANTY .................................................... 19

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety

messages.

This is the safety alert symbol.

This symbol alerts you to potential hazards that can kill or hurt you and others.

All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."

These words mean:

WARNING

All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can

happen if the instructions are not followed.

W10366213A

REFRIGERATOR USER INSTRUCTIONS

Table of Contents / Índice / Table des matières

SEGURIDAD DEL REFRIGERADOR............. 20

INSTRUCCIONES DE INSTALACIÓN........... 21

USO DE SU REFRIGERADOR....................... 30

CUIDADO DE SU REFRIGERADOR ............. 33

SOLUCIÓN DE PROBLEMAS ....................... 34

HOJA DE DATOS DEL RENDIMIENTO........ 37

GARANTÍA ...................................................... 39

REFRIGERATOR SAFETY

Your safety and the safety of others are very important.

DANGER

SÉCURITÉ DU RÉFRIGÉRATEUR ................ 41

INSTRUCTIONS D'INSTALLATION .............. 42

UTILISATION DU RÉFRIGÉRATEUR............ 52

ENTRETIEN DU RÉFRIGÉRATEUR.............. 54

DÉPANNAGE .................................................. 55

FEUILLES DE DONNÉES

SUR LA PERFORMANCE .............................. 58

GARANTIE ...................................................... 60

You can be killed or seriously injured if you don't immediately

follow instructions.

You can be killed or seriously injured if you don't follow

instructions.

Need help?

Do you have a question about the ABB1921WEW2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Amana ABB1921WEW2

Page 1: Table Of Contents
THANK YOU for purchasing this high-quality product. If you should experience a problem not covered in TROUBLESHOOTING, please visit our website at www.amana.com for additional information. If you still need assistance, call us at 1-800-843-0304. In Canada, visit our website at www.amanacanada.ca or call us at 1-800-807-6777.
Page 2: Installation Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electric shock, or injury when using your refrigerator, follow these basic precautions: Plug into a grounded 3 prong outlet. Use nonflammable cleaner. Do not remove ground prong. Keep flammable materials and vapors, such as gasoline, away from refrigerator.
Page 3 Clean Before Using After you remove all of the packaging materials, clean the inside of your refrigerator before using it. See the cleaning instructions in “Refrigerator Care.” Important information to know about glass shelves and covers: ¹⁄₂ " (1.25 cm) Do not clean glass shelves or covers with warm water when they are cold.
Page 4 Water Supply Requirements Connect the Water Supply Gather the required tools and parts before starting installation. Read all directions before you begin. Read and follow the instructions provided with any tools listed IMPORTANT: If you turn on the refrigerator before the water line is here.
Page 5 5. Using an adjustable wrench, hold the nut on the plastic water Connect to Refrigerator line to keep it from moving. Then, with a second wrench turn the compression nut on the copper tubing counterclockwise Depending on your model, the water line may come down from to completely tighten.
Page 6 Refrigerator Door(s) and Drawer TOOLS NEEDED: ⁵⁄₁₆", ³⁄₈", ¹⁄₄" hex head socket wrench, a Torx ®† T20 screwdriver, a #2 Phillips screwdriver, and a flat-blade Remove Door and Hinges screwdriver. Standard Door IMPORTANT: Your refrigerator may have a standard reversible refrigerator door with either a freezer door or freezer drawer, or French doors.
Page 7 3. Starting with the right-hand side door, remove the parts for the Replace Door and Hinges top hinge as shown in Top Hinge graphic. Lift the refrigerator door from the bottom hinge pin. Standard Door 4. Remove the hinge pin cover from the bottom hinge pin and keep it for later use.
Page 8 Remove and Replace Freezer Drawer Final Steps IMPORTANT: 1. Check all holes to make sure that hole plugs and screws are in place. Reinstall top hinge cover as shown in Top Hinge Two people may be required to remove and replace the freezer graphic.
Page 9 Standard Door Door Swing Reversal (optional) Door Removal & Replacement Top Hinge A. Cabinet Hinge Hole Plugs A. Hinge Cover Screw ⁵⁄₁₆ " Hex-Head Hinge Screws B. Top Hinge Cover " Hex-Head Hinge Screws D. Top Hinge Center Hinge A. Trim Screw B.
Page 10 French Doors WARNING Electrical Shock Hazard Disconnect power before removing doors. Failure to do so can result in death or electrical shock. Door Removal and Replacement Top Hinges Style 2 - Handle Style 1 - Handle A. Hinge Cover Screw B.
Page 11: Refrigerator Use
Door Closing and Door Alignment The base grille covers the leveling screws and roller assemblies located at the bottom of the refrigerator cabinet below the freezer door or drawer. Before making adjustments, remove the base grille and move the refrigerator to its final location. 1.
Page 12 Adjusting Controls Using the Controls The temperature controls are located at the top front of the If you need to adjust the temperature in either the refrigerator or refrigerator or freezer compartments. freezer compartment, use the settings listed in the chart below as a guide.
Page 13: Refrigerator Care
Ice Production Rate Water Filtration System The water filter is located in the upper right-hand corner of the The ice maker should produce a complete batch of ice refrigerator compartment. approximately every 3 hours. To increase ice production, lower the freezer and refrigerator temperature.
Page 14: Troubleshooting
TROUBLESHOOTING First try the solutions suggested here or visit our website and reference FAQs (Frequently Asked Questions) to possibly avoid the cost of a service call. In the U.S.A., www.amana.com In Canada, www.amanacanada.ca Refrigerator Operation Are controls on? Make sure the refrigerator controls are on.
Page 15 Popping - contraction/expansion of inside walls, especially during initial cool-down Ice and Water Water running - may be heard when ice melts during the defrost cycle and water runs into the drain pan The ice maker is not producing ice or not enough ice Creaking/Cracking - occurs as ice is being ejected from the Refrigerator connected to a water supply and the supply ice maker mold.
Page 16: Water Filter Certifications
The water dispenser will not operate properly WATER FILTER CERTIFICATIONS Refrigerator connected to a water supply and the supply shutoff valve turned on? Connect refrigerator to water supply and turn water shutoff valve fully open. Kink in the water source line? Straighten the water source line.
Page 17: Performance Data Sheets
PERFORMANCE DATA SHEETS Interior Water Filtration System Model UKF8001AXX-750 Capacity 750 Gallons (2839 Liters) System tested and certified by NSF International against NSF/ANSI Standard 42 for the reduction of Chlorine Taste and Odor, Particulate Class I*; and against NSF/ANSI Standard 53 for the reduction of Lead, Mercury, Atrazine, Benzene, p-Dichlorobenzene, Carbofuran, Toxaphene, Cysts, Turbidity, Asbestos, Tetrachloroethylene and Lindane.
Page 18 Interior Water Filtration System Model UKF8001AXX-200 Capacity 200 Gallons (757 Liters) System tested and certified by NSF International against NSF/ANSI Standard 42 for the reduction of Chlorine Taste and Odor, Particulate Class I*; and against NSF/ANSI Standard 53 for the reduction of Lead, Mercury, Atrazine, Benzene, p-Dichlorobenzene, Carbofuran, Toxaphene, Cysts, Turbidity, Asbestos, O-Dichlorobenzene, Ethylbenzene, Chlorobenzene, Endrin, Tetrachloroethylene and Lindane.
Page 19: Warranty
5. Cosmetic damage, including scratches, dents, chips or other damage to the finish of your major appliance, unless such damage results from defects in materials or workmanship and is reported to Amana within 30 days from the date of purchase.
Page 20 W10366213A ® Registered Trademark/™Trademark of Maytag Properties, LLC or its related companies. EN/FR PN W10366212A Used under license by Maytag Limited in Canada. ® Marca registrada/™Marca de comercio de Maytag Properties, LLC o sus compañías asociadas. © 2011 4/11 Usada bajo licencia por Maytag Limited en Canadá. All rights reserved.
