B E A M
SPEAKER
DOCUMENTATION
MANUAL PAN SPEAKER P 04 + VARIANTS
Shapely.
Versatile.
Functional.
Read the manual carefully before putting the device into operation.
The manual must be retained.
QUALITY
All products are designed, developed and manufactured by Pan Acoustics in Germany.
MADE IN GERMANY
Pan Acoustics reserves the right to modify products without prior notice.
SINCE 2002
Pan Acoustics GmbH │ Schweigerstr. 13d │ D-38302 Wolfenbüttel │ Germany │ Tel.: +49 (0) 5331 900 95 70 │ E-mail: contact@pan-acoustics.de
2 - L I N E
E V A C
V 1.0
www.pan-acoustics.de
Advertisement
Table of Contents
Related Manuals for Pan Acoustics P 04
Summary of Contents for Pan Acoustics P 04
- Page 1 All products are designed, developed and manufactured by Pan Acoustics in Germany. MADE IN GERMANY Pan Acoustics reserves the right to modify products without prior notice. www.pan-acoustics.de SINCE 2002 Pan Acoustics GmbH │ Schweigerstr. 13d │ D-38302 Wolfenbüttel │ Germany │ Tel.: +49 (0) 5331 900 95 70 │ E-mail: contact@pan-acoustics.de...
- Page 2 If the product is resold, the document must be handed over to the new owner in printed or electronic form. Pan Acoustics reserves the right to change / update the document without prior notice. The latest version of this document can be downloaded from the Pan Acoustics website.
-
Page 3: Table Of Contents
8. Assembly and connection 8.1. Assembly of mounts (accessories) 8.2. Electrical connection 8.2.1. P 04-Pi (low impedance) 8.2.2. P 04-Pi | IP65 (low impedance) 8.2.3. P 04-Pi (100 volts) 8.2.3.1. Power tapping 100% 8.2.3.2. Power tapping 50% 8.2.3.3. Power tapping 25% 8.2.3.4. -
Page 4: Product Description
This operating manual describes the setup, function and connection of the Pan Speaker loudspeaker systems P 04-Pi, P 04-Pi | 100 V, P 04-Pi | IP65 and P 04-Pi | 100 V | IP65. It is aimed at system technicians and persons assigned the task of installing and operating a relevant system. - Page 5 The base surface is to be checked for suitability of installation and, where required, prepared by qualifi ed personnel. • the connections and components delivered by Pan Acoustics or expressly mentioned in this manual are to be used. •...
-
Page 6: Safety Instructions
Manual 5. Safety instructions All products from Pan Acoustics are developed and manufactured in Germany according to the latest safety regulations. Each product is thoroughly inspected prior to shipping according to in-house quality guidelines. The device conforms to the current CE regulations for operation in residential, business, commercial and industrial areas. -
Page 7: Assembly And Connection
In case of doubt as to the type and composition of the building structure, consult a structural engineer. CONNECTION OF THE LOUDSPEAKER AND MOUNT • All mounts sourced via Pan Acoustics for the Pan Speaker series are delivered with suitable instal- lation material for connection with the loudspeaker. •... -
Page 8: Electrical Connection
8.2.1. P 04-Pi (low impedance) The low-impedance variant of the loudspeaker P 04-Pi is equipped with a 5-pin connector at the back. The audio signal must be connected via the enclosed connection terminal using pin 1 (+) and pin 2 (-). - Page 9 The wires of the connection cable must be fi tted with wire end ferrules. Step 3: Insert the connection terminal with the cable into the 5-pin connector on the loudspeaker. © Pan Acoustics GmbH V 1.0 Page 9 of 24...
- Page 10 3 and pin 4. To avoid damage to the connected power amplifi er, the total impedance of all connected loudspeakers in a line must not fall below the impedance of the amplifi er. © Pan Acoustics GmbH V 1.0...
-
Page 11: P 04-Pi | Ip65 (Low Impedance)
8.2.2. P 04-Pi | IP65 (low impedance) The low-impedance variant of the loudspeaker P 04-Pi | IP65 is equipped with a 2-pin connection cable of 5 m length. The connection cable is permanently connected to the loudspeaker at the factory and can be shortened to the required length. -
Page 12: P 04-Pi (100 Volts)
Manual 8.2.3. P 04-Pi (100 volts) The 100 V variant of the loudspeaker P 04-Pi is equipped with a 5-pin connector at the back. The audio signal must be connected via the enclosed connection terminal. Diff erent power taps (100%, 50%, 25% 12.5%) can be realised via the individual pins. - Page 13 Manual Step 2: Insert the connection terminal with the cable into the 5-pin connector on the loudspeaker. Step 3: Fix the connection terminal to the loudspeaker. © Pan Acoustics GmbH V 1.0 Page 13 of 24...
-
Page 14: Power Tapping
The wires of the connection cable must be fi tted with wire end ferrules. Step 2: Insert the connection terminal with the cable into the 5-pin connector on the loudspeaker. © Pan Acoustics GmbH V 1.0 Page 14 of 24... -
Page 15: Power Tapping
0.4 Nm so that the wires cannot slip out. NOTICE The wires of the connection cable must be fi tted with wire end ferrules. © Pan Acoustics GmbH V 1.0 Page 15 of 24... - Page 16 Manual Step 2: Insert the connection terminal with the cable into the 5-pin connector on the loudspeaker. Step 3: Fix the connection terminal to the loudspeaker. © Pan Acoustics GmbH V 1.0 Page 16 of 24...
-
Page 17: Power Tapping 12.5
The wires of the connection cable must be fi tted with wire end ferrules. Step 2: Insert the connection terminal with the cable into the 5-pin connector on the loudspeaker. © Pan Acoustics GmbH V 1.0 Page 17 of 24... - Page 18 Manual Step 3: Fix the connection terminal to the loudspeaker. © Pan Acoustics GmbH V 1.0 Page 18 of 24...
-
Page 19: P 04-Pi | Ip65 (100 Volts)
8.2.4. P 04-Pi | IP65 (100 volts) The 100 V variant of the loudspeaker P 04-Pi | IP65 is equipped with a 5-pin connection cable with numbering (1-5) of 5 m length. The connection cable is permanently connected to the loudspeaker at the factory and can be shortened to the required length. -
Page 20: Operating Conditions
The device must also not be exposed to strong vibrations. 10. Service and repair Service and repair work may only be carried out by persons and partners authorised by Pan Acoustics. No service or repair measures are to performed on the device that exceed the statements made in chapter 11 “Maintenance”. -
Page 21: Contact Address
Information on additional measures or the number of mounts to be used can be found in the manual of the corresponding accessory. If you have any technical questions, you can also contact our support team at support@pan-acoustics.de. © Pan Acoustics GmbH V 1.0 Page 21 of 24... -
Page 22: Technical Data Loudspeaker
Dimensions (H x W x D): 506 x 107 x 118 [mm] Weight: 1.9 kg Mounting option: Other mounting accessories available. 17.2. P 04-Pi | 100 V ACOUSTIC PROPERTIES Confi guration: Passive line array Frequency range: 130 Hz – 18 kHz Equipment: 4 x 3.5”... -
Page 23: Technical Drawing Loudspeaker 18.1. P 04-Pi
Manual 18. Technical drawing loudspeaker 18.1. P 04-Pi 118 mm 506 mm 107 mm © Pan Acoustics GmbH V 1.0 Page 23 of 24... - Page 24 CONTACT: Pan Acoustics GmbH | Schweigerstr. 13d | D-38302 Wolfenbüttel | Germany Tel.: +49 (0) 5331 900 95 70 | Fax: +49 (0) 5331 900 95 79 | E-mail: contact@pan-acoustics.de QUALITY MADE IN GERMANY SINCE 2002 www.pan-acoustics.de...
