PAN BEAM SERIES OPERATING AND INSTALLATION MANUAL
PB 04, PB 08, PB 16, PB 24, PB 32, PB 40, PB 224, PB 248, PB 272, PB 296
PAN BEAM -
ACTIVE DSP COLUMN SPEAKER
PURE ACOUSTICS
Shapely.
Versatile.
Functional.
Read the operating manual carefully prior to putting the device into operation.
The operating manual is to be kept in a safe place.
Pan Acoustics GmbH │ Lindener Str. 15 │ D-38300 Wolfenbüttel │ Germany │ Tel.: +49 (0) 5331 900 95 70 │ Email: kontakt@pan-acoustics.de
V 1.1
www.pan-acoustics.de
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pan Acoustics PB 04
Summary of Contents for Pan Acoustics PB 04
- Page 1 Read the operating manual carefully prior to putting the device into operation. The operating manual is to be kept in a safe place. www.pan-acoustics.de Pan Acoustics GmbH │ Lindener Str. 15 │ D-38300 Wolfenbüttel │ Germany │ Tel.: +49 (0) 5331 900 95 70 │ Email: kontakt@pan-acoustics.de...
-
Page 2: Table Of Contents
2.4. Side lobe optimization 3. Connections 3.1. Connector panel for Pan Beam PB 04/08/16/24/32/40 - analog/digital audio (AES/EBU) 3.2. Connector panel for Pan Beam PB 04/08/16/24/32/40 - DANTE 3.3. Connector panel for Pan Beam PB 224 - analog/digital audio (AES/EBU) 3.4. - Page 3 8.7. Pan Splitter 4/4 cabling example (alarm contact) 9. Scope of delivery and accessories 9.1. Delivery scope of speakers 9.1.1. PB 04 9.1.2. PB 04 - AES/EBU 9.1.3. PB 04 - D 9.1.4. PB 08 9.1.5. PB 08 - AES/EBU 9.1.6.
-
Page 4: Introduction
This operating manual describes the confi guration, function and connection of the Pan Beam speaker systems PB 04, PB 08, PB 16, PB 24, PB 32, PB 40, PB 224, PB 248, P 272, PB 296 to the power supply and audio sources. It is geared towards systems technicians and persons assigned the task of installing and operating a relevant system. -
Page 5: General Safety Regulations
To avoid injuries such as hearing damage from excessive volume levels, persons should • never stand directly in front of a connected speaker. • not be subjected to high volume levels for a prolonged period. © Pan Acoustics GmbH V 1.1 Page 5 of 36... -
Page 6: Safety Instructions
The original packaging should be used when transporting the device. The device is to be protected against vibrations. 1.4. Safety instructions All products from Pan Acoustics are developed and manufactured in Germany according to the latest safety regulations. Each product is thoroughly inspected prior to shipping according to in-house quality guidelines. -
Page 7: Setup Location
Internationally standardized power connector for devices (low heat device socket) DANTE Digital audio network protocol for transmission of audio and control data developed by Audinate. AES/EBU Interface for transmission of digital audio signals between various devices according to AES3 © Pan Acoustics GmbH V 1.1 Page 7 of 36... -
Page 8: Product Description
2. Product description 2.1. Pan Beam The Pan Beam models PB 04/08/16/24/32/40/224/248/272/296 are active, digitally steerable column speakers. The Pan Beam models PB S-208/-118 are active subwoofer systems. Via the Pan Beam Setup software, the radiating characteristics of the column speakers can be influenced individually in real time. -
Page 9: Connections
All connections for audio, control data and power supply are located on the back panel of the speakers. The connections are freely accessible. No tools are required for connecting the audio signals and power supply. 3.1. Connector panel for Pan Beam PB 04/08/16/24/32/40 - analog/digital audio (AES/EBU) (3) Pan Beam Net connection RJ45... -
Page 10: Connector Panel For Pan Beam Pb 224 - Analog/Digital Audio (Aes/Ebu)
(3) Dante Network primary port RJ45 / 1 GBit/s (2) Pan Beam Net-Link RJ45 (1) Power connection PowerCon TRUE1, integrated strain relief and protective ground conductor Supply voltage: 100–230 V, 50/60 Hz © Pan Acoustics GmbH V 1.1 Page 10 of 36... -
Page 11: Commissioning
When joining the modules, the inside cable assembly is to be fed into the interior of the speakers. Avoid crushing and bending the cables. © Pan Acoustics GmbH V 1.1 Page 11 of 36... - Page 12 A mounting plate is pre-fitted on the back panel for wall mounting, in order to fasten appropriate wall brackets. PB 224 PB 224 Dante PB 16 Dante PB 16 PB 224 AES/EBU PB 16 AES/EBU © Pan Acoustics GmbH V 1.1 Page 12 of 36...
-
Page 13: Cascading Of The Speaker Columns With Pan Beam Setup Software
Pan Beam Setup program. program launch Media controller does not Pin configuration incorrect Check pin configuration work Baud rate incorrect Configure proper baud rate Faulty instruction set Check instruction set © Pan Acoustics GmbH V 1.1 Page 13 of 36... -
Page 14: Service And Repair
If the error is not specifi ed in the above table or cannot be remedied using the measures mentioned, please consult the technical support of Pan Acoustics GmbH. Please retain the original packaging of the devices in order to ensure secure return shipping in the event of a claim. -
Page 15: Appendix
Pan Net jumper plug Pan Con 485 > 1 Alarm loop ---> Ethercon Pin 6 > 2 Alarm loop ---> Ethercon Pin 3 Alarm Pan Beam © Pan Acoustics GmbH V 1.1 Page 15 of 36... -
Page 16: Control Via Media Controller
6.3.2. Crestron The relevant module is ready for operation with a media controller by the manufacturer Crestron. The module can be obtained through the Crestron website or from Pan Acoustics. 6.3.3. Pan Beam Net interface confi guration, Crestron baud rate 38400 ±... -
Page 17: Dante
Sample rates: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz Encoding: Pan Beam speakers support PCM24 and PCM32 encoding Device latency and clocking Audinate Dante information http://www.audinate.com © Pan Acoustics GmbH V 1.1 Page 17 of 36... -
Page 18: Network Configuration
DANTE network. 6.4.5. Status Via the “Status” tab, information can be called up on the device, fi rmware and software version, clock status and net- work interface. © Pan Acoustics GmbH V 1.1 Page 18 of 36... -
Page 19: Cascading
AES/EBU interface in a daisy chain procedure. Pay attention to the proper sequence (Input/Output). Marking (1) to (4) See chapter 3.2. “Connector panel for Pan Beam PB 04/08/16/24/32/40 - DANTE” or chapter 3.4. “Connector panel for Pan Beam PB 224 - DANTE”... -
Page 20: Alarm Contact (Alarm Loop)
--> see chapter 6.2. "Alarm contact" audio signals (3) LED TRX (7) Pan Beam Illuminated orange during data transfer RJ45 connector for Pan Beam speakers (4) USB (B) connector for link to PC © Pan Acoustics GmbH V 1.1 Page 20 of 36... -
Page 21: Pan Beam Net
In case of failure, the alarm loop is interrupted accordingly and the error status in the system can be evaluated on an appropriate interface. For this purpose, the Pan Net jumper plug is to be used according to the cabling examples. © Pan Acoustics GmbH V 1.1 Page 21 of 36... -
Page 22: Pan Con Cabling Example
PB xx The Pan Net jumper plug is to be plugged into the open RJ45 slots on the Pan Beam speaker. This completes the return path for the alarm loop. © Pan Acoustics GmbH V 1.1 Page 22 of 36... -
Page 23: Pan Splitter 2/6 Cabling Example
Alarm contact for status message, e.g. on media controller PB xx PB xx PB xx PB xx PB xx PB xx PB xx PB xx PB xx PB xx PB xx PB xx © Pan Acoustics GmbH V 1.1 Page 23 of 36... -
Page 24: Pan Splitter 2/6 Cabling Example (Alarm Contact)
PB xx The Pan Net jumper plug is to be plugged into the open RJ45 slots on the Pan Beam speaker. This completes the return path for the alarm loop. © Pan Acoustics GmbH V 1.1 Page 24 of 36... -
Page 25: Pan Splitter 4/4 Cabling Example
Alarm contact for status message, e.g. on media controller PB xx PB xx PB xx PB xx PB xx PB xx PB xx PB xx © Pan Acoustics GmbH V 1.1 Page 25 of 36... -
Page 26: Pan Splitter 4/4 Cabling Example (Alarm Contact)
PB xx The Pan Net jumper plug is to be plugged into the open RJ45 slots on the Pan Beam speaker. This completes the return path for the alarm loop. © Pan Acoustics GmbH V 1.1 Page 26 of 36... -
Page 27: Scope Of Delivery And Accessories
9. Scope of delivery and accessories In its standard configuration, the Pan Beam series consists of the modules PB 04 and PB 08 as well as PB 224. As already mentioned in Chapter 4.2. “Installation of speakers, consisting of several modules”... -
Page 28: Pb 16 - Aes/Ebu
Closure cap (rubber) for RJ45 interface Quick start instructions 9.1.12. PB 16 - D (one enclosure) Description Quantity PB 16 - D IEC-60320 C13 power cord Closure cap (rubber) for RJ45 interface Quick start instructions © Pan Acoustics GmbH V 1.1 Page 28 of 36... -
Page 29: Pb 24 - Aes/Ebu
Quick start instructions 9.1.18. PB 24 - D (one enclosure) Description Quantity PB 24 - D module IEC-60320 C13 power cord Closure cap (rubber) for RJ45 interface Quick start instructions © Pan Acoustics GmbH V 1.1 Page 29 of 36... -
Page 30: Pb 32 - Aes/Ebu
PB 08 - AES/EBU module (bottom) PB 08 - AES/EBU module (middle) PB 08 - AES/EBU module (top) Connection set PB xx IEC-60320 C13 power cord Closure cap (rubber) for RJ45 interface Quick start instructions © Pan Acoustics GmbH V 1.1 Page 30 of 36... -
Page 31: Pb 40 - D
Pre-mounted connection plate for fastening a bracket Connection set PB xxx PowerCON TRUE1 power cord Connection cable set PB xxx PB xxx Closure cap (rubber) for RJ45 interface Quick start instructions © Pan Acoustics GmbH V 1.1 Page 31 of 36... -
Page 32: Pb 248 - Aes/Ebu
PB 224 - AES/EBU module Pre-mounted connection plate for fastening a bracket Connection set PB xxx PowerCON TRUE1 power cord Connection cable set PB xxx Closure cap (rubber) for RJ45 interface Quick start instructions © Pan Acoustics GmbH V 1.1 Page 32 of 36... -
Page 33: Pb 272 - D
PB 224 - AES/EBU module Pre-mounted connection plate for fastening a bracket Connection set PB xxx PowerCON TRUE1 power cord Connection cable set PB xxx Closure cap (rubber) for RJ45 interface Quick start instructions © Pan Acoustics GmbH V 1.1 Page 33 of 36... -
Page 34: Brackets
+/- 5°, PB xx (TWM Article no.: 801840 III)Article no.: 801841 Tripod attachment, PB xx Connection set, PB xx Wall bracket, swiveling/tilt- Article no.: 801843 Article no.: 801924 able, PB 224 Article no.: 801314 © Pan Acoustics GmbH V 1.1 Page 34 of 36... -
Page 35: Performance Specifications
The accessories with the article numbers: 801365, 01449, 801451, 801581 are also available in the color RAL 9010 (white). 10. Performance Specifi cations Please refer to the corresponding data sheets of the speakers for performance specifi cations. These are available at www.pan-acoustics.de. © Pan Acoustics GmbH V 1.1 Page 35 of 36... -
Page 36: Pan Acoustics Gmbh
Pan Acoustics from Germany. QUALITY - MADE IN GERMANY CONTACT: Pan Acoustics GmbH | Lindener Str. 15 | D-38300 Wolfenbüttel | Germany Tel: +49 (0) 5331 900 95 70 | Fax: +49 (0) 5331 900 95 79 | Mail: contact@pan-acoustics.de www.pan-acoustics.de...
