B E A M
SPEAKER
DOCUMENTATION
MANUAL PAN SPEAKER P 01 + VARIANTS
Shapely.
Versatile.
Functional.
Read the manual carefully before putting the device into operation.
The manual must be retained.
QUALITY
All products are designed, developed and manufactured by Pan Acoustics in Germany.
MADE IN GERMANY
Pan Acoustics reserves the right to modify products without prior notice.
SINCE 2002
Pan Acoustics GmbH │ Schweigerstr. 13d │ D-38302 Wolfenbüttel │ Germany │ Tel.: +49 (0) 5331 900 95 70 │ E-mail: contact@pan-acoustics.de
2 - L I N E
E V A C
V 1.0
www.pan-acoustics.de
Advertisement
Table of Contents
Related Manuals for Pan Acoustics P 01
Summary of Contents for Pan Acoustics P 01
- Page 1 All products are designed, developed and manufactured by Pan Acoustics in Germany. MADE IN GERMANY Pan Acoustics reserves the right to modify products without prior notice. www.pan-acoustics.de SINCE 2002 Pan Acoustics GmbH │ Schweigerstr. 13d │ D-38302 Wolfenbüttel │ Germany │ Tel.: +49 (0) 5331 900 95 70 │ E-mail: contact@pan-acoustics.de...
- Page 2 If the product is resold, the document must be handed over to the new owner in printed or electronic form. Pan Acoustics reserves the right to change / update the document without prior notice. The latest version of this document can be downloaded from the Pan Acoustics website.
-
Page 3: Table Of Contents
11. Maintenance measures 12. Declaration of conformity 13. WEEE declaration (disposal) 14. Warranty 15. Contact address 16. Mounts 17. Technical data loudspeaker 17.1. P 01-Pi 18. Technical drawing loudspeaker 18.1. P 01-Pi © Pan Acoustics GmbH V 1.0 Page 3 of 16... -
Page 4: Product Description
This operating manual describes the setup, function and connection of the Pan Speaker loudspeaker systems P 01-Pi and P 01-Pi (mB). It is aimed at system technicians and persons assigned the task of installing and operating a relevant system. - Page 5 The base surface is to be checked for suitability of installation and, where required, prepared by qualifi ed personnel. • the connections and components delivered by Pan Acoustics or expressly mentioned in this manual are to be used. •...
-
Page 6: Safety Instructions
Manual 5. Safety instructions All products from Pan Acoustics are developed and manufactured in Germany according to the latest safety regulations. Each product is thoroughly inspected prior to shipping according to in-house quality guidelines. The device conforms to the current CE regulations for operation in residential, business, commercial and industrial areas. -
Page 7: Assembly And Connection
In case of doubt as to the type and composition of the building structure, consult a structural engineer. CONNECTION OF THE LOUDSPEAKER AND MOUNT • All mounts sourced via Pan Acoustics for the Pan Speaker series are delivered with suitable instal- lation material for connection with the loudspeaker. •... -
Page 8: Assembly / Disassembly Of The Bracket (Mb Variant)
8.1.1. Assembly / disassembly of the bracket (mB variant) The mB variant of the loudspeaker P 01-Pi is delivered with a pre-assembled U-bracket. The bracket features three fi xing points for mounting e.g. on a building surface. To mount the U-bracket on a surface, it must fi rst be removed from the loudspeaker. -
Page 9: Angle Of The U-Bracket
The U-bracket can be swivelled from the centre to the left and right by 110° each. To adjust the set angle, hand-tighten the screws connecting the U-bracket to the lids. © Pan Acoustics GmbH V 1.0 Page 9 of 16... -
Page 10: Electrical Connection
Manual 8.2. Electrical connection The loudspeaker P 01-Pi is equipped with two 2-pin connectors at the back. The audio signal must be connected via one of the enclosed connection terminals. The second connection terminal can be used to pick up the audio signal at the loudspeaker again and pass it on. -
Page 11: Operation On The Power Amplifier
8.3. Operation on the power amplifi er The loudspeaker P 01-Pi must be operated on a correctly confi gured DSP amplifi er or amplifi er with upstream audio DSP. The amplifi er to be used must be chosen according to the technical data of the loudspeaker. -
Page 12: Warranty
Manual 14. Warranty Pan Acoustics stands by its products and gives up to 10 years warranty on its loudspeakers for any material or manufacturing defects. New products manufactured in accordance with protection classes IP54 and IP65 as well as digital audio interfaces (Dante ) from Audinate Pty Ltd and re- ®... -
Page 13: Technical Data Loudspeaker 17.1. P 01-Pi
Manual 17. Technical data loudspeaker 17.1. P 01-Pi ACOUSTIC PROPERTIES Configuration: 2-way coaxial system (point source) Frequency range: 145 Hz – 20 kHz Equipment: 1 x 3.5” / 0.5” voice coil Rated power: 80 W (peak ) / 50 W (programme) / 30 W (nominal) -
Page 14: Technical Drawing Loudspeaker 18.1. P 01-Pi
Manual 18. Technical drawing loudspeaker 18.1. P 01-Pi without bracket 118 mm 116 mm 107 mm with bracket 130 mm 130 mm 107 mm © Pan Acoustics GmbH V 1.0 Page 14 of 16... - Page 15 Manual © Pan Acoustics GmbH V 1.0 Page 15 of 16...
- Page 16 CONTACT: Pan Acoustics GmbH | Schweigerstr. 13d | D-38302 Wolfenbüttel | Germany Tel.: +49 (0) 5331 900 95 70 | Fax: +49 (0) 5331 900 95 79 | E-mail: contact@pan-acoustics.de QUALITY MADE IN GERMANY SINCE 2002 www.pan-acoustics.de...
