B E A M
SPEAKER
DOCUMENTATION
MANUAL PAN SPEAKER P 04-RJ + VARIANTS
Shapely.
Versatile.
Functional.
Read the manual carefully before putting the device into operation.
The manual must be retained.
QUALITY
All products are designed, developed and manufactured by Pan Acoustics in Germany.
MADE IN GERMANY
Pan Acoustics reserves the right to modify products without prior notice.
SINCE 2002
Pan Acoustics GmbH │ Schweigerstr. 13d │ D-38302 Wolfenbüttel │ Germany │ Tel.: +49 (0) 5331 900 95 70 │ E-mail: contact@pan-acoustics.de
2 - L I N E
E V A C
V 1.0
www.pan-acoustics.de
Advertisement
Table of Contents
Related Manuals for Pan Acoustics P 04
Summary of Contents for Pan Acoustics P 04
- Page 1 All products are designed, developed and manufactured by Pan Acoustics in Germany. MADE IN GERMANY Pan Acoustics reserves the right to modify products without prior notice. www.pan-acoustics.de SINCE 2002 Pan Acoustics GmbH │ Schweigerstr. 13d │ D-38302 Wolfenbüttel │ Germany │ Tel.: +49 (0) 5331 900 95 70 │ E-mail: contact@pan-acoustics.de...
- Page 2 If the product is resold, the document must be handed over to the new owner in printed or electronic form. Pan Acoustics reserves the right to change / update the document without prior notice. The latest version of this document can be downloaded from the Pan Acoustics website.
-
Page 3: Table Of Contents
8.1.1. Assembly/disassembly of the bracket (mB variant) 8.1.2. Angle of the U-bracket 8.2. Electrical connection 8.2.1. P 04-RJ (low impedance) 8.3. Important notice regarding the network cable and amplifier power 8.3.1. Permissible cable cross sections and lengths 8.3.2. RJ pin assignment 8.3.3. -
Page 4: Product Description
This operating manual describes the setup, function and connection of the Pan Speaker loudspeaker systems P 04-RJ and P 04-RJ (mB). It is aimed at system technicians and persons assigned the task of installing and operating a relevant system. - Page 5 The base surface is to be checked for suitability of installation and, where required, prepared by qualifi ed personnel. • the connections and components delivered by Pan Acoustics or expressly mentioned in this manual are to be used. •...
-
Page 6: Safety Instructions
Manual 5. Safety instructions All products from Pan Acoustics are developed and manufactured in Germany according to the latest safety regulations. Each product is thoroughly inspected prior to shipping according to in-house quality guidelines. The device conforms to the current CE regulations for operation in residential, business, commercial and industrial areas. -
Page 7: Assembly And Connection
In case of doubt as to the type and composition of the building structure, consult a structural engineer. CONNECTION OF THE LOUDSPEAKER AND MOUNT • All mounts sourced via Pan Acoustics for the Pan Speaker series are delivered with suitable instal- lation material for connection with the loudspeaker. •... -
Page 8: Assembly/Disassembly Of The Bracket (Mb Variant)
8.1.1. Assembly/disassembly of the bracket (mB variant) The mB variant of the loudspeaker P 04-RJ is delivered with a pre-assembled U-bracket. The bracket features three fi xing points for mounting e.g. on a building surface. To mount the U-bracket on a surface, it must fi rst be removed from the loudspeaker. - Page 9 Pull off the bracket to the back. Step 3: Secure plastic washer. Mount the bracket on the desired building sur- face. When assembling, position the plastic washers appropriately. NOTICE Assembly is done in reverse order. © Pan Acoustics GmbH V 1.0 Page 9 of 18...
-
Page 10: Angle Of The U-Bracket
8.2. Electrical connection 8.2.1. P 04-RJ (low impedance) The low impedance variant of the loudspeaker P 04-RJ is equipped with an RJ45 socket with high electrical and mechanical load capacity at the back. The contacts of the RJ45 socket are wired in such a way that 4 wires of a network cable are combined for low-impedance signal transmission. - Page 11 Check the locking mechanism of the connec- tion cable for function to prevent the cable from slipping out. Step 3: Connect the network cable to the socket of the loudspeaker and snap it into place. © Pan Acoustics GmbH V 1.0 Page 11 of 18...
-
Page 12: Important Notice Regarding The Network Cable And Amplifier Power
The maximum cable lengths and cable cross sections that may be used are indicated below. Pan Acoustics loudspeakers have a high effi ciency. Due to the high sensitivity of the systems, a con- siderable sound pressure can already be generated from little applied power. The RJ variants of the loudspeakers therefore do not have to be driven to the maximum in order to produce a sound level that is suffi... -
Page 13: Operation On The Power Amplifier
8.4. Operation on the power amplifi er The loudspeaker P 04-RJ must be operated on a correctly confi gured DSP amplifi er or amplifi er with upstream audio DSP. The power of the amplifi er to be used must be limited to 20 watts (programme) and 60 watts (peak). -
Page 14: Warranty
Manual 14. Warranty Pan Acoustics stands by its products and gives up to 10 years warranty on its loudspeakers for any material or manufacturing defects. New products manufactured in accordance with protection classes IP54 and IP65 as well as digital audio interfaces (Dante ) from Audinate Pty Ltd and re- ®... -
Page 15: Technical Data Loudspeaker 17.1. P 04-Rj
Manual 17. Technical data loudspeaker 17.1. P 04-RJ ACOUSTIC PROPERTIES Configuration: Passive line array Frequency range: 130 Hz – 18 kHz Equipment: 4 x 3.5” Rated power: 300 W (peak ) / 200 W (programme) / 100 W (nominal) 20 ms... -
Page 16: Technical Drawing Loudspeaker
Manual 18. Technical drawing loudspeaker 18.1. P 04-RJ 116 mm 506 mm 107 mm © Pan Acoustics GmbH V 1.0 Page 16 of 18... -
Page 17: P 04-Rj (Mb)
Manual 18.2. P 04-RJ (mB) 152 mm 522 mm 107 mm 137 mm © Pan Acoustics GmbH V 1.0 Page 17 of 18... - Page 18 CONTACT: Pan Acoustics GmbH | Schweigerstr. 13d | D-38302 Wolfenbüttel | Germany Tel.: +49 (0) 5331 900 95 70 | Fax: +49 (0) 5331 900 95 79 | E-mail: contact@pan-acoustics.de QUALITY MADE IN GERMANY SINCE 2002 www.pan-acoustics.de...
