B E A M
SPEAKER
DOCUMENTATION
MANUAL PAN SPEAKER P 02 + VARIANTS
Shapely.
Versatile.
Functional.
Read the manual carefully before putting the device into operation.
The manual must be retained.
QUALITY
All products are designed, developed and manufactured by Pan Acoustics in Germany.
MADE IN GERMANY
Pan Acoustics reserves the right to modify products without prior notice.
SINCE 2002
Pan Acoustics GmbH │ Schweigerstr. 13d │ D-38302 Wolfenbüttel │ Germany │ Tel.: +49 (0) 5331 900 95 70 │ E-mail: contact@pan-acoustics.de
2 - L I N E
E V A C
V 1.0
www.pan-acoustics.de
Advertisement
Table of Contents
Related Manuals for Pan Acoustics P 02
Summary of Contents for Pan Acoustics P 02
- Page 1 All products are designed, developed and manufactured by Pan Acoustics in Germany. MADE IN GERMANY Pan Acoustics reserves the right to modify products without prior notice. www.pan-acoustics.de SINCE 2002 Pan Acoustics GmbH │ Schweigerstr. 13d │ D-38302 Wolfenbüttel │ Germany │ Tel.: +49 (0) 5331 900 95 70 │ E-mail: contact@pan-acoustics.de...
- Page 2 If the product is resold, the document must be handed over to the new owner in printed or electronic form. Pan Acoustics reserves the right to change / update the document without prior notice. The latest version of this document can be downloaded from the Pan Acoustics website.
-
Page 3: Table Of Contents
13. WEEE declaration (disposal) 14. Warranty 15. Contact address 16. Mounts 17. Technical data loudspeaker 17.1. P 02-Pi 17.2. P 02-Pi | 100 V 18. Technical drawing loudspeaker 18.1. P 02-Pi © Pan Acoustics GmbH V 1.0 Page 3 of 24... -
Page 4: Product Description
This operating manual describes the setup, function and connection of the Pan Speaker loudspeaker systems P 02-Pi, P 02-Pi (mB), P 02-Pi | 100 V and P 02-Pi | 100 V (mB). It is aimed at system tech- nicians and persons assigned the task of installing and operating a relevant system. - Page 5 The base surface is to be checked for suitability of installation and, where required, prepared by qualifi ed personnel. • the connections and components delivered by Pan Acoustics or expressly mentioned in this manual are to be used. •...
-
Page 6: Safety Instructions
Manual 5. Safety instructions All products from Pan Acoustics are developed and manufactured in Germany according to the lat- est safety regulations. Each product is thoroughly inspected prior to shipping according to in-house quality guidelines. The device conforms to the current CE regulations for operation in residential, business, commercial and industrial areas. -
Page 7: Assembly And Connection
In case of doubt as to the type and composition of the building structure, consult a structural engineer. CONNECTION OF THE LOUDSPEAKER AND MOUNT • All mounts sourced via Pan Acoustics for the Pan Speaker series are delivered with suitable instal- lation material for connection with the loudspeaker. •... -
Page 8: Assembly/Disassembly Of The Bracket (Mb Variant)
8.1.1. Assembly/disassembly of the bracket (mB variant) The mB variant of the loudspeaker P 02-Pi is delivered with a pre-assembled U-bracket. The bracket features three fi xing points for mounting e.g. on a building surface. To mount the U-bracket on a surface, it must fi rst be removed from the loudspeaker. - Page 9 Pull off the bracket to the back. Step 3: Secure plastic washer. Mount the bracket on the desired building surface. When assembling, position the plastic washers appropriately. NOTICE Assembly is done in reverse order. © Pan Acoustics GmbH V 1.0 Page 9 of 24...
-
Page 10: Angle Of The U-Bracket
8.2.1. P 02-Pi (low impedance) The low-impedance variant of the loudspeaker P 02-Pi is equipped with a 5-pin connector at the back. The audio signal must be connected via the enclosed connection terminal using pin 1 (+) and pin 2 (-). - Page 11 The wires of the connection cable must be fi tted with wire end ferrules. Step 3: Insert the connection terminal with the cable into the 5-pin connector on the loudspeaker. © Pan Acoustics GmbH V 1.0 Page 11 of 24...
- Page 12 3 and pin 4. To avoid damage to the connected power amplifi er, the total impedance of all connected loudspeakers in a line must not fall below the impedance of the amplifi er. © Pan Acoustics GmbH V 1.0 Page 12 of 24...
-
Page 13: P 02-Pi (100 Volts)
Manual 8.2.2. P 02-Pi (100 volts) The 100 V variant of the loudspeaker P 02-Pi is equipped with a 5-pin connector at the back. The audio signal must be connected via the enclosed connection terminal. Diff erent power taps (100%, 50%, 25% 12.5%) can be realised via the individual pins. - Page 14 Manual Step 2: Insert the connection terminal with the cable into the 5-pin connector on the loudspeaker. Step 3: Fix the connection terminal to the loudspeaker. © Pan Acoustics GmbH V 1.0 Page 14 of 24...
-
Page 15: Power Tapping 50
The wires of the connection cable must be fi tted with wire end ferrules. Step 2: Insert the connection terminal with the cable into the 5-pin connector on the loudspeaker. © Pan Acoustics GmbH V 1.0 Page 15 of 24... -
Page 16: Power Tapping 25
10 Nm so that the wires cannot slip out. NOTICE The wires of the connection cable must be fi tted with wire end ferrules. © Pan Acoustics GmbH V 1.0 Page 16 of 24... - Page 17 Manual Step 2: Insert the connection terminal with the cable into the 5-pin connector on the loudspeaker. Step 3: Fix the connection terminal to the loudspeaker. © Pan Acoustics GmbH V 1.0 Page 17 of 24...
-
Page 18: Power Tapping 12.5
The wires of the connection cable must be fi tted with wire end ferrules. Step 2: Insert the connection terminal with the cable into the 5-pin connector on the loudspeaker. © Pan Acoustics GmbH V 1.0 Page 18 of 24... -
Page 19: Operation On The Power Amplifier
8.3. Operation on the power amplifi er The loudspeaker P 02-Pi must be operated on a correctly confi gured DSP amplifi er or amplifi er with upstream audio DSP. The amplifi er to be used must be chosen according to the technical data of the loudspeaker. -
Page 20: Maintenance Measures
14. Warranty Pan Acoustics stands by its products and gives up to 10 years warranty on its loudspeakers for any material or manufacturing defects. New products manufactured in accordance with protection classes IP54 and IP65 as well as digital audio interfaces (Dante ) from Audinate Pty Ltd and re- ®... -
Page 21: Mounts
Information on additional measures or the number of mounts to be used can be found in the manual of the corresponding accessory. If you have any technical questions, you can also contact our support team at support@pan-acoustics.de. © Pan Acoustics GmbH V 1.0 Page 21 of 24... -
Page 22: Technical Data Loudspeaker
244 x 107 x 152 [mm] Weight: 1.5 kg Mounting option: Available with or without U-bracket. Other mounting accessories available. 17.2. P 02-Pi | 100 V ACOUSTIC PROPERTIES Confi guration: Passive compact loudspeaker Frequency range: 130 Hz – 18 kHz Equipment: 2 x 3.5”... -
Page 23: Technical Drawing Loudspeaker 18.1. P 02-Pi
Manual 18. Technical drawing loudspeaker 18.1. P 02-Pi without bracket 118 mm 228 mm 107 mm with bracket 152 mm 244 mm 107 mm © Pan Acoustics GmbH V 1.0 Page 23 of 24... - Page 24 CONTACT: Pan Acoustics GmbH | Schweigerstr. 13d | D-38302 Wolfenbüttel | Germany Tel.: +49 (0) 5331 900 95 70 | Fax: +49 (0) 5331 900 95 79 | E-mail: contact@pan-acoustics.de QUALITY MADE IN GERMANY SINCE 2002 www.pan-acoustics.de...
