- Page 1 LED Wash Flood Light GTD-L6119P User’s Manual Guangzhou GTD Lighting Technology Co., Ltd. Tel: +86-20-61808296 Fax: +86-20-61812282 www.gtd-lighting.com http://...
- Page 2 © 2017 GTD all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. GTD logo and identifying product names and numbers herein are trademarks of GTD. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted.
-
Page 3: Table Of Contents
GTD-L6119P User Manual Contents Safety instructions ..................................3 General guidelines ..................................4 Packing and shipping .................................. 5 Unpacking ....................................... 5 Packing after use..................................... 5 Accessories ....................................5 Product introduction .................................. 6 Installation ....................................6 Device installation ..................................6 Power / Control connection ............................... 7 Power connection ................................... -
Page 4: Safety Instructions
GTD-L6119P User Manual Safety instructions WARNING! Before using the fixture, read the latest version of the product user manual, paying particular attention to the safety instructions. Please check www.gtd-lighting.com for the latest revision/update of the user manual. The manufacture of this fixture, are not responsible for damages, resulting from misuse of this fixture, due to the disregard of the information printed in this user manual. -
Page 5: General Guidelines
Broken or damaged cables can only be fixed or changed by certified technicians, certified local distributors or the manufacturer to ensure operational safety. Do not stick filters or other materials onto the lens. Do not modify the fixture or install other than GTD manufactured parts. ... -
Page 6: Packing And Shipping
GTD-L6119P User Manual Packing and shipping Unpacking Notes All products are quality controlled and checked for any faults before they are dispatched to customers. If the fixture is damaged during delivery, the customer must notify the shipper and manufacturer to file a damage insurance claim. -
Page 7: Product Introduction
GTD-L6119P User Manual Product introduction Manual adjusting screw Handle Base LED lens Aluminum profiles of power supply Installation Clamps installation The fixture can be placed on the stage or mounted on the truss facing any direction. Attach the clamps to the mounting position on the base of the fixture. -
Page 8: Power/ Control Connection
GTD-L6119P User Manual Power/ Control connection Power connection Connection method: L (Live) Brown wire E (Earth) Yellow / Green bi-color wire N (Neutral) Blue wire The voltage and frequency of the power source must be in compliance with the ones marked on the fixture. Please apply series connection when many sets of fixtures are connected to the power source to avoid heavy load to the power source. -
Page 9: Testing
GTD-L6119P User Manual Testing Connect the fixture to AC power. Check if the LED lamp is on and the fixture is independently controllable before putting into operation. Control panel The control panel with buttons and digital display can access the function menu and configure the fixture easily. -
Page 10: Menu Structure
GTD-L6119P User Manual Menu structure L6119P – Menu Structure Revision: A Valid from firmware version: 1.0 Level 1 Level 2 Level 3 Level 4 Info Addr AXXX A001 Setting the DMX address MSTR/ALON Running build-in program as the master or the slave... -
Page 11: Dmx Protocol
GTD-L6119P User Manual DMX protocol L6119P - DMX Protocol Revision: A Valid from firmware version: 1.0 DMX mode Default Name DMX value DMX percentage Function Standard Basic Value (11ch) (7ch) 0.0% 12.2% Closed 12.5% 24.7% Open 25.1% 49.8% Synchronous strobe from slow to fast... - Page 12 GTD-L6119P User Manual DMX mode Default Name DMX value DMX percentage Function Standard Basic Value (11ch) (7ch) 0.0% 9.4% No function 9.8% 13.7% 3200K 14.1% 18.0% 3400K 18.4% 22.4% 3600K 22.7% 26.7% 3800K 27.1% 31.0% 4000K 31.4% 35.3% 4200K 35.7% 39.6%...
-
Page 13: Technical Specification
GTD-L6119P User Manual Technical specification Optical Light source: LED 6W, quantity: 119pcs Expected average lifetime: 50000 hours Beam angle (10% peak angle): 35° Std. (Opt. 50°) RGB linear color mixing 3200K-7200K linear regulation CRI: 85Ra Electrical ... - Page 14 GTD-L6119P User Manual Certification and Safety EMC: EN 55103-1:2009, EN 55103-2:2009, EN 61000-3-2:2006+A2:2009, EN 61000-3-3:2013 Safety: EN 60598-2-17:1989/A2:1991 Photometric...
-
Page 15: Cleaning And Maintenance
GTD-L6119P User Manual Cleaning and maintenance It is required that the fixture should be kept clean and well maintained to ensure its reliability. Its lifespan mainly depends on the working environment and proper operation. Should you have any questions, please consult a technical engineer of GTD Lighting. -
Page 16: Troubleshooting
GTD-L6119P User Manual Troubleshooting Possible Cause Suggested Correction Problem Power switch not turned on. Turn on power switch. Locate the blown fuse. Remove the broken fuse. Insert a Take out the fuse and check if it is blown. replacement fuse of the correct amperage. -
Page 17: System Wiring Diagram
GTD-L6119P User Manual System wiring diagram... -
Page 18: Spare Parts List
GTD-L6119P User Manual Spare parts list Item Notes Switching Power Supply 1412050028A EDS400-5624P LED drive board 5802030046A LCR0205B LED lamp board 5802030055A LCR0206B Display board 5809210049A L6119P-101E10&102F10 SDI0200C Appendix 1... - Page 19 GTD-L6119P User Manual Notes: P/N: 1502011093A Time: August 15 , 2017...
