- Page 1 LED Cyclorama GTD-L3100 User’s Manual Guangzhou GTD Lighting Technology Co., Ltd. Tel: +86-20-61808296 Fax: +86-20-61812282 www.gtd-lighting.com http://...
- Page 2 © 2017 GTD all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. GTD logo and identifying product names and numbers herein are trademarks of GTD. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted.
-
Page 3: Table Of Contents
GTD-L3100 User Manual Contents Safety instructions ..................................3 General guidelines ..................................4 Packing and shipping .................................. 5 Unpacking ....................................... 5 Packing after use..................................... 5 Accessories ....................................5 Product introduction .................................. 6 Installation ....................................7 Clamps installation ..................................7 Device installation ..................................7 Power / Control connection ............................... -
Page 4: Safety Instructions
GTD-L3100 User Manual Safety instructions WARNING! Before using the fixture, read the latest version of the product user manual, paying particular attention to the safety instructions. Please check www.gtd-lighting.com for the latest revision/update of the user manual. The manufacture of this fixture, are not responsible for damages, resulting from misuse of this fixture, due to the disregard of the information printed in this user manual. -
Page 5: General Guidelines
Broken or damaged cables can only be fixed or changed by certified technicians, certified local distributors or the manufacturer to ensure operational safety. Do not stick filters or other materials onto the lens. Do not modify the fixture or install other than GTD manufactured parts. ... -
Page 6: Packing And Shipping
GTD-L3100 User Manual Packing and shipping Unpacking Notes All products are quality controlled and checked for any faults before they are dispatched to customers. If the fixture is damaged during delivery, the customer must notify the shipper and manufacturer to file a damage insurance claim. -
Page 7: Product Introduction
GTD-L3100 User Manual Product introduction LED lens Base Clamp mounting position Manually-adjustable screw DMX input Power switch Fuse DMX output Power input 10 Power output 11 Display... -
Page 8: Installation
GTD-L3100 User Manual Installation Clamps installation The fixture can be placed on the stage or mounted on the truss facing any direction. Attach the clamp to the mounting position on the base of the fixture. Warning Use one clamp when mounting the fixture. Fasten the screw properly and connect a safety cable to fixture. -
Page 9: Control Connection
GTD-L3100 User Manual Control connection The fixture has 5-pin XLR connectors for DMX data input and output (3-pin optional) as shown below. Connection between the console and fixture, and between fixtures must be made with 2 core screened DMX signal cable. Maximum connecting distance of signal cable is 150 meters. -
Page 10: Control Panel
GTD-L3100 User Manual Control panel The control panel with buttons and digital display can access the function menu and configure the fixture easily. Press MENU to check or modify the functions of the fixture; Press UP or DOWN to view or select the function menu. -
Page 11: Menu Structure
GTD-L3100 User Manual Menu structure L3100 - Menu Structure Revision: A Valid from firmware version: 1.0 Level 1 Level 2 Level 3 Level 4 Info Addr AXXX A001 Setting the DMX address MSTR/ ALON Running build-in program as the master or the slave... -
Page 12: Dmx Protocol
GTD-L3100 User Manual DMX protocol L3100 - DMX Protocol Revision: A Valid from firmware version: 1.0 DMX mode Default Name DMX value Function Standard Basic percentage (21ch) (12ch) Value 0.0% 12.2% Closed 12.5% 24.7% Open 25.1% 49.8% Synchronous strobe from slow to fast... - Page 13 GTD-L3100 User Manual DMX mode Default Name DMX value Function Standard Basic percentage Value (21ch) (12ch) 0.0% 9.4% No function 9.8% 13.7% 3200K 14.1% 18.0% 3400K 18.4% 22.4% 3600K 22.7% 26.7% 3800K 27.1% 31.0% 4000K 31.4% 35.3% 4200K 35.7% 39.6% 4400K 40.0%...
-
Page 14: Technical Specification
GTD-L3100 User Manual Technical specification Optical Light source: LED 3W, quantity: 100pcs (12R+12OR+12A+14G+14CY+12B+12IN+12W) Expected average lifetime: 50000 hours Beam angle (fixed): Pan: 72°, tilt: 60° (10% peak angle) 8 colors liner mixing, each ring of LEDs individually controllable Photometric ... -
Page 15: Cleaning And Maintenance
GTD-L3100 User Manual Humidity: ≤85% Connections AC power: Neutrik powerCon DMX data input/output: Chassis 5-pin Neutrik XLR (in/out) Certification and Safety EMC: EN 55103-1:2009, EN 55103-2:2009, EN 61000-3-2:2006+A2:2009, EN 61000-3-3:2013 Safety: EN 60598-2-17:1989/A2:1991 Photometric Pan angle: 72°... -
Page 16: Troubleshooting
GTD-L3100 User Manual If the lens is cracked or otherwise damaged, replace it immediately. If the LED lamp becomes damaged or deformed in any way it must be replaced. If the light from the LED lamp appears dim, this normally indicates that it is reaching the end of its life span and should be changed at once. -
Page 17: System Wiring Diagram
GTD-L3100 User Manual System wiring diagram... -
Page 18: Spare Parts List
GTD-L3100 User Manual Spare parts list Item Notes LED aluminum substrate 5802010033A LJB0304D LED driver board 5802030037A LCR0305D Display board 5809210026B L3100-101E11&102F11&103F11 SDI0200B XLR board 5802910008A SKL0006B Switching power supply 1412050023A EDS350-5628PN 350W EAGL Appendix 1... - Page 19 GTD-L3100 User Manual Notes: P/N: 1502011034A Time: May 15 , 2017...
