- Page 1 LED Flood Light GTD-L2080P User’s Manual Guangzhou GTD Culture & Technology Group Co.,Ltd. Tel: +86-20-61808296 Fax: +86-20-61812282 www.gtd-lighting.com http://...
- Page 2 GTD-L2080P User Manual © 2019 GTD all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. GTD logo and identifying product names and numbers herein are trademarks of GTD. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted.
-
Page 3: Table Of Contents
GTD-L2080P User Manual Contents Safety instructions ..................................3 General guidelines ..................................4 Packing and shipping .................................. 5 Unpacking ....................................... 5 Packing after use..................................... 5 Accessories ....................................5 Product introduction .................................. 6 Installation ....................................6 Device installation ..................................6 Power / Control connection ............................... 7 Power connection ................................... -
Page 4: Safety Instructions
GTD-L2080P User Manual Safety instructions WARNING! Before using the fixture, read the latest version of the product user manual, paying particular attention to the safety instructions. Please check www.gtd-lighting.com for the latest revision/update of the user manual. The manufacture of this fixture, are not responsible for damages, resulting from misuse of this fixture, due to the disregard of the information printed in this user manual. -
Page 5: General Guidelines
Broken or damaged cables can only be fixed or changed by certified technicians, certified local distributors or the manufacturer to ensure operational safety. Do not stick filters or other materials onto the lens. Do not modify the fixture or install other than GTD manufactured parts. ... -
Page 6: Packing And Shipping
GTD-L2080P User Manual Packing and shipping Unpacking Notes All products are quality controlled and checked for any faults before they are dispatched to customers. If the fixture is damaged during delivery, the customer must notify the shipper and manufacturer to file a damage insurance claim. -
Page 7: Product Introduction
GTD-L2080P User Manual Product introduction Glass fixing plate Manual adjusting screw Handle Lens Base Aluminum profiles of power supply Installation Device installation The lamp is placed on the floor for use, see below:... -
Page 8: Power/ Control Connection
GTD-L2080P User Manual Power/ Control connection Power connection Connection method: L (Live) Brown wire E (Earth) Yellow / Green bi-color wire N (Neutral) Blue wire The voltage and frequency of the power source must be in compliance with the ones marked on the fixture. It is ... -
Page 9: Control Panel
GTD-L2080P User Manual Control panel The control panel with buttons and digital display can access the function menu and configure the fixture easily. Press MENU to check or modify the functions of the fixture; Press UP or DOWN to view or select the function menu. -
Page 10: Menu Structure
GTD-L2080P User Manual Menu structure L2080P – Menu Structure Revision: A Valid from firmware version: 1.0 Level 4 Info Level 1 Level 2 Level 3 Addr AXXX A001 Setting the DMX address MSTR/ ALON Running build-in program as the master or the slave... -
Page 11: Dmx Protocol
GTD-L2080P User Manual DMX protocol L2080P- DMX Protocol Revision: A Valid from firmware version: 1.0 DMX protocol – CH1 [10 channels] Default CH1(10) Name DMX value Function percentage Value 0.0% 12.2% Closed 12.5% 24.7% Open 25.1% 49.8% Synchronous strobe from slow to fast... - Page 12 GTD-L2080P User Manual Default CH1(10) Name DMX value Function percentage Value 91.0% 100.0% Rainbow flow from slow to fast 0.0% 9.4% No function 9.8% 13.7% 3200K 14.1% 18.0% 3400K 18.4% 22.4% 3600K 22.7% 26.7% 3800K 27.1% 31.0% 4000K 31.4% 35.3% 4200K 35.7%...
- Page 13 GTD-L2080P User Manual Default CH1(10) Name DMX value Function percentage Value 78.8% 82.7% 6400K 83.1% 87.1% 6600K 87.5% 91.4% 6800K 91.8% 95.7% 7000K 96.1% 100.0% 7200K 0.0% 2.0% M0.600Hz, Dimming curve1, fade dimming 2.4% 4.3% M1.600Hz, Dimming curve2, snap dimming 4.7%...
- Page 14 GTD-L2080P User Manual DMX protocol – CH2 [17 channels] Default CH2(17) Name DMX value Function percentage Value 0.0% 12.2% Closed 12.5% 24.7% Open 25.1% 49.8% Synchronous strobe from slow to fast Strobe/Shutter 0(0%) 50.2% 62.4% Open 62.7% 87.5% Random strobe from slow to fast 87.8%...
- Page 15 GTD-L2080P User Manual Default CH2(17) Name DMX value Function percentage Value 22.7% 26.7% 3800K 27.1% 31.0% 4000K 31.4% 35.3% 4200K 35.7% 39.6% 4400K 40.0% 43.9% 4600K 44.3% 48.2% 4800K 48.6% 52.5% 5000K 52.9% 56.9% 5200K 57.3% 61.2% 5400K 61.6% 65.5% 5600K 65.9%...
- Page 16 GTD-L2080P User Manual Default CH2(17) Name DMX value Function percentage Value 0.0% 2.0% M0.600Hz, Dimming curve1, fade dimming 2.4% 4.3% M1.600Hz, Dimming curve2, snap dimming 4.7% 6.7% M2.1200Hz, Dimming curve1, fade dimming Dimmer Mode 7.1% 9.0% M3.1200Hz, Dimming curve2, snap dimming 0(0%) 9.4%...
-
Page 17: Technical Specification
GTD-L2080P User Manual Technical specification Optical Light source: LED 20W Quantity: 80 pcs Expected average lifetime: 50000 hours Beam angle (10% peak angle): 13° Std. (Opt. 38° /58°) Beam angle (50% peak angle): 7° Std. (Opt. 20° /38°) Photometric ... - Page 18 GTD-L2080P User Manual Certification and Safety EMC: EN 55103-1:2009, EN 55103-2:2009, EN 61000-3-2:2006+A2:2009, EN 61000-3-3:2013 Safety: EN 60598-2-17:1989/A2:1991 Photometric...
-
Page 19: Cleaning And Maintenance
GTD-L2080P User Manual Cleaning and maintenance It is required that the fixture should be kept clean and well maintained to ensure its reliability. Its lifespan mainly depends on the working environment and proper operation. Should you have any questions, please consult a technical engineer of GTD Lighting. -
Page 20: Troubleshooting
GTD-L2080P User Manual Troubleshooting Possible Cause Suggested Correction Problem Power switch not turned on. Turn on power switch. Locate the blown fuse. Remove the broken fuse. Insert a replacement Take out the fuse and check if it is blown. fuse of the correct amperage. -
Page 21: System Wiring Diagram
GTD-L2080P User Manual System wiring diagram... -
Page 22: Spare Parts List
GTD-L2080P User Manual Spare parts list Item Notes Switching Power Supply 1412050066A EDS720-4824P AC:100-240VAC DC:48V 14.5A 24V 1A 720W LED Aluminum board 5802010063A LJB0514D LED lens 1301020039A HL-OS08L-4526 Display board 5809210091A L2080P-101K10 SDI0102A Appendix 1 509mm 467mm (20.0'') (18.4'') 295mm 702mm (11.6'') - Page 23 GTD-L2080P User Manual Notes: P/N: 1502011096A Time: February 22 , 2019...
