Planet Networking & Communication GSD-1222VHP User Manual page 19

„ 10/100/1000Mbps PoE Ports
LED Color
LNK/ACT Red
LNK/ACT Green
PoE-in-Use Orange
„ 1000Mbps SFP Slots
LED Color
LNK/ACT Green
„ 1000Mbps TP Slots (GSD-1222VHP)
LED Color
LNK/ACT Red
LNK/ACT Green
Indicates the link through that port is
Lights
successfully established at 10/100Mbps.
Indicates that the Switch is actively sending
Blinks
or receiving data over that port.
Indicates the link through that port is
Lights
successfully established at 1000Mbps.
Indicates that the Switch is actively sending
Blinks
or receiving data over that port.
Indicates the port is providing 53V DC in-line
Lights
power.
Indicates the connected device is not a PoE
Off
PD.
Indicates the port is successfully established
Lights
at 1000Mbps.
Indicates that the Switch is actively sending
Blinks
or receiving data over that port.
Indicates the link through that port is
Lights
successfully established at 10/100Mbps.
Indicates that the Switch is actively sending
Blinks
or receiving data over that port.
Indicates the link through that port is
Lights
successfully established at 1000Mbps.
Indicates that the Switch is actively sending
Blinks
or receiving data over that port.
Function
Function
Function
19
