- Page 1 ® R&S NGL200/NGM200 Power Supply Series Getting Started (;ÜåD2) 1178872002...
- Page 2 Trade names are trademarks of the owners. ® 1178.8720.02 | Version 05 | R&S NGL200/NGM200 ® Throughout this manual, products from Rohde & Schwarz are indicated without the symbol, e.g. ® ® R&S NGL200, R&S NGM200 are indicated as R&S NGL/NGM.
- Page 3 Safety Instructions Instrucciones de seguridad Sicherheitshinweise Consignes de sécurité Risk of injury and instrument damage The instrument must be used in an appropriate manner to prevent electric shock, fire, personal injury or instrument damage. ● Do not open the instrument casing. ●...
- Page 4 Gefahr von Verletzungen und Schäden am Gerät Betreiben Sie das Gerät immer ordnungsgemäß, um elektrischen Schlag, Brand, Verletzungen von Personen oder Geräteschäden zu verhindern. ● Öffnen Sie das Gerätegehäuse nicht. ● Lesen und beachten Sie die "Grundlegenden Sicherheitshinweise", die als gedruckte Broschüre dem Gerät beiliegen.
- Page 5 Customer Support Technical support – where and when you need it For quick, expert help with any Rohde & Schwarz product, contact our customer support center. A team of highly qualified engineers provides support and works with you to find a solution to your query on any aspect of the operation, programming or applications of Rohde &...
-
Page 6: Table Of Contents
® Contents R&S NGL200/NGM200 Contents 1 Documentation Overview............5 2 Welcome to R&S NGL/NGM..........7 3 Putting into Operation............9 3.1 Safety....................10 3.2 Intended Operation................12 3.3 Unpacking and Checking the Instrument......... 13 3.4 Setting Up the Instrument..............14 3.4.1 Bench Operation................... 14 3.4.2 Rack Mounting.................. - Page 7 ® Contents R&S NGL200/NGM200 Getting Started 1178.8720.02 ─ 05...
-
Page 8: Documentation Overview
® Documentation Overview R&S NGL200/NGM200 Documentation Overview This section provides an overview of the R&S NGL/NGM user documentation. You can find it on the product page at: www.rohde-schwarz.com/product/ngl200 www.rohde-schwarz.com/product/ngm200 Getting Started Introduces the R&S NGL/NGM power supply series and describes how to set up and start working with the instrument. - Page 9 See www.rohde-schwarz.com/firmware/ngl200. The open source acknowledg- ment document can also be read directly on the instrument. See www.rohde-schwarz.com/firmware/ngm200. The open source acknowledg- ment document can also be read directly on the instrument. Getting Started 1178.8720.02 ─ 05...
-
Page 10: Welcome To R&S Ngl/Ngm
® Welcome to R&S NGL/NGM R&S NGL200/NGM200 Welcome to R&S NGL/NGM The one or two-channel power supply series are based on a classical transformer concept with linear regulators. This concept allows the instrument to achieve highest accuracy and lowest residual ripple. - Page 11 ® Welcome to R&S NGL/NGM R&S NGL200/NGM200 (http://www.rohde-schwarz.com/product/ngl200 for R&S NGL and http:// www.rohde-schwarz.com/product/ngm200 for R&S NGM) . Getting Started 1178.8720.02 ─ 05...
-
Page 12: Putting Into Operation
® Putting into Operation R&S NGL200/NGM200 Putting into Operation This chapter describes how to set up the R&S NGL/NGM power supply series for the first time. Risk of injury and instrument damage The instrument must be used in an appropriate manner to prevent electric shock, fire, personal injury, or damage. -
Page 13: Safety
® Putting into Operation R&S NGL200/NGM200 Safety Risk of instrument damage during operation An unsuitable operating site or test setup can cause damage to the instru- ment and the connected devices. Ensure the following operating conditions before you switch on the instrument: ●... - Page 14 ® Putting into Operation R&S NGL200/NGM200 Safety For safety reasons, the instrument may only be operated with authorized safety sockets. The power cable must be plugged in before signal circuits may be con- nected. Never use the product if the power cable is damaged. Check regularly if the power cables are in perfect condition.
-
Page 15: Intended Operation
® Putting into Operation R&S NGL200/NGM200 Intended Operation Intended Operation The instrument is intended only for use by personnel familiar with the potential risks of measuring electrical quantities. For safety reasons, the instrument may only be connected to properly installed wall outlets. -
Page 16: Unpacking And Checking The Instrument
® Putting into Operation R&S NGL200/NGM200 Unpacking and Checking the Instrument General data Mains fuses 2 x IEC T4.0H 250 V +5 °C to +40 °C Operating temperature range -20 °C to +70 °C Storage temperature range Humidity noncondensing 5 % to 95 % Display TFT 5"... -
Page 17: Setting Up The Instrument
® Putting into Operation R&S NGL200/NGM200 Setting Up the Instrument Risk of damage during transportation and shipment Insufficient protection against mechanical and electrostatic effects during transportation and shipment can damage the instrument. ● Always ensure that sufficient mechanical and electrostatic protections are provided ●... -
Page 18: Rack Mounting
® Putting into Operation R&S NGL200/NGM200 Setting Up the Instrument Figure 3-1: Operating positions Positioning of instrument The instrument must be positioned in a manner that allows you to discon- nect the unit from the mains at any time and without restrictions. -
Page 19: Instrument Tour
® Instrument Tour R&S NGL200/NGM200 Overview of Controls Instrument Tour This chapter provides an overview of all the controls available in the R&S NGL/NGM models and steps to switch on the instrument for the first time. ● Overview of Controls..................16 ●... - Page 20 ® Instrument Tour R&S NGL200/NGM200 Overview of Controls 5 = Output terminals (one channel with sense for NGL201, NGM201; two channels for NGL202, NGM202) 6 = USB connector 7 = Power key Display (1) The display is a color TFT touch screen. Depending on the instrument model, up to two channels are shown on the display.
-
Page 21: Rear Panel
® Instrument Tour R&S NGL200/NGM200 Overview of Controls Both instrument models are equipped with 4 terminals. The NGL201, NGM201 models provide both the output plus the sense connectors at the front panel while the NGL202, NGM202 models provide only output terminals for both channels. - Page 22 ® Instrument Tour R&S NGL200/NGM200 Overview of Controls AC inlet with fuse holder and voltage selector (8) Main supply cord Do not use detachable mains supply cord with inadequate rating. The power cable must be plugged in before signal circuits can be connected. Do not use the product if the power cable is damaged.
- Page 23 ® Instrument Tour R&S NGL200/NGM200 Overview of Controls Ethernet connector (13) 10/100 Ethernet port for remote control operation via the local area network. For a detailed description on the connection setup, see section "LAN Connection" in the User Manual. Option IEEE-488 (GPIB) interface (14) An IEEE-488 (GPIB) interface can be ordered (NGL-B105 or NGM-B105).
-
Page 24: Switching On The Instrument
® Instrument Tour R&S NGL200/NGM200 Switching On the Instrument Table 4-2: Inhibit signals Signal name Descriptions Inhibit Ch1 Pin 1 of Digital I/O If the inhibit signal goes active, channel 1 connector output is turned off. The inhibit signal is low active (inverted logic). - Page 25 ® Instrument Tour R&S NGL200/NGM200 Switching On the Instrument 2. Connect the power cable to the socket outlet. 3. Press [Power] key on the front panel. The instrument performs a system check, boots the operating system, and starts the R&S NGL/NGM firmware.
-
Page 26: Trying Out The Instrument
® Trying Out the Instrument R&S NGL200/NGM200 Activating the Channels Output Trying Out the Instrument This chapter describes some basic functions that you can perform with the R&S NGL/NGM. Source and sink current The R&S NGL/NGM power supply series are 2 quadrant power supplies which may both source and sink current. - Page 27 ® Trying Out the Instrument R&S NGL200/NGM200 Activating the Channels Output The R&S NGL/NGM outputs the set voltage level on the selected output chan- nel terminal. Depending on the mode which the channels are operated in, the followings are observed:...
-
Page 28: Maintenance
® Maintenance R&S NGL200/NGM200 Maintenance Before cleaning the instrument, ensure that it has been switched off and the power cable is disconnected. Clean the outer case of the instrument at regular intervals, using a soft, lint-free dust cloth. Instrument damage caused by cleaning agents Use a dry, lint-free cloth to clean the product. -
Page 29: Index
® Index R&S NGL200/NGM200 Index Activating the channels output ....23 Rear panel AC inlet with fuse holder ..... 19 Channel connectors ......19 Digital I/O connector ......20 Delivery package contents ...... 14 Ethernet connector ......20 Documentation overview ......5 IEEE-488 (GPIB) interface ....20...
