1037C Data Sheet
SYSTEM SPECIFICATIONS
1037C
Lower cut-off frequency, -3 dB < 35 Hz
Upper cut-off frequency, -3 dB > 22 kHz
Free fi eld frequency response 37 Hz - 21 kHz (±2.5 dB)
Maximum short term sine wave acoustic
output on axis in half space, averaged
from 100 Hz to 3 kHz @ 1 m >116 dB SPL
Maximum long term RMS acoustic
output in same conditions with
IEC-weighted noise (limited by driver
unit protection circuit) @ 1m >107 dB SPL
Maximum peak acoustic output per pair
@ 1.7 m from the engineer with music
material > 126 dB
Self generated noise level in free fi eld
@ 2 m on axis < 15 dBA
Harmonic distortion at 95 dB SPL Freq:
@ 1 m on axis
Drivers Bass
Mid
Treble
All drivers are magnetically shielded
Weight
37 kg (83 lb)
Speaker dimensions Height
Width
Depth
* Note that the cable connectors require additional
100 mm (4") of space behind the speaker cabinet.
Genelec Document BBA0054001 Copyright Genelec Oy 2.2003. All data subject to change without prior notice
< 100 Hz < 3%
> 100 Hz < 0.5
305 mm (12")
130 mm (5")
25 mm (1") metal dome
680 mm (26 3 / ")
4
400 mm (15 3 / ")
4
380 mm (15")
International enquiries:
Genelec, Olvitie 5
FIN-74100, Iisalmi, Finland
Phone +358 17 83881
Fax +358 17 812 267
Email genelec@genelec.com
AMPLIFIER SECTION
1037C
Bass amplifi er output power with
an 4 Ohm load Short term 180 W
Mid amplifi er output power with
an 8 Ohm load Short term 120 W
Treble amplifi er output power with
an 8 Ohm load Short term 120 W
Long term output power is limited by driver unit
protection circuitry.
Slew rate 80 V/µs
Amplifi er system distortion at THD
nominal output SMPTE-IM
CCIF-IM
DIM 100
Signal to Noise ratio, Bass
referred to full output Mid
Treble
Mains voltage: 100/200 or 115/230V
Voltage operating range at
230 V setting 207 - 244 V (-10/+6 %)
115 V setting 104 - 122 V (-10/+6 %)
Power consumption Idle
Full output
CROSSOVER SECTION
1037C
Input connector: XLR female pin 1 gnd
pin 2 +
pin 3 -
Input impedance 10 kOhm balanced
Input level for 100 dB SPL output @ 1m variable from +6 to -6 dBu
Input level for maximum short term output
of 116 dB SPL @ 1m variable from +22 to +10 dBu
Subsonic fi lter below 32 Hz 18 dB/octave
Ultrasonic fi lter above 25 kHz 12 dB/octave
Crossover frequencies Bass/Mid
Mid/Treble
Crossover acoustical slopes 18 - 24 dB/octave
Level control operating range Bass
in 1 dB steps Mid
Treble
Bass roll-off control in 2 dB steps from 0 to -8 dB @ 35 Hz
Bass tilt control in 2 dB steps from 0 to -8 dB @ 80 Hz
The 'CAL' position is with all tone controls set to 'off'
and input sensitivity control to maximum and
corresponds to a maximally fl at free fi eld response.
In the U.S. please contact
Genelec, Inc., 7 Tech Circle
Natick, MA 01760, USA
Phone +1 508 652 0900
Fax +1 508 652 0909
Email genelec.usa@genelec.com
<0.05%
<0.05%
<0.05%
<0.05%
>100 dB
>100 dB
>100 dB
50 W
300 W
420 Hz
3.2 kHz
from 0 to -6 dB & MUTE
from 0 to -6 dB & MUTE
from 0 to -6 dB & MUTE
