AUDIO PRECISION 1037CANEC LEVEL(dBr)
dBr
90
85
80
BASS TILT
90
85
80
BASS LEVEL
90
85
80
BASS ROLL-OFF
20 50 100 200
Figure 7: The curves above show the effect of the 'bass', 'mid' and
'treble' level controls, and the 'bass tilt' and 'bass roll-off ' controls
on the free field response of the 1037C, measured at 2 m.
AUDIO PRECISION 1037CANEC LEVEL(dBr)
dBr
95
90
85
80
75
70 100
65 95
90
85
20 50 100 200
Figure 9: The upper curve group shows the horizontal directivity
characteristics of the 1037C in its vertical configuration
measured at 2 m. The lower curve is a 1/6 octave power
response measurement, derived from 144 individual directivity
measurements.

Safety considerations

Although the 1037C and 1038B monitors
have been designed in accordance with
international safety standards, to ensure
safe operation and to maintain the instrument
under safe operating conditions, the following
warnings and cautions must be observed:
1. Servicing and adjustment must only
be performed by qualified service
personnel. The amplifier's rear panel
must not be opened.
2. Do not use this product with an
unearthed mains cable as this may lead
to personal injury.
3. To prevent fire or electric shock, do not
expose the unit to water or moisture. Do
not place any objects filled with liquid,
vs FREQ(Hz) 04 OCT 02
TREBLE LEVEL
MIDRANGE LEVEL
500 1k 2k 5k 10k 20k
Hz
vs FREQ(Hz) 04 0CT 02
0
15
30
45
500 1k 2k 5k 10k 20k
Hz
such as vases on the speaker or near it.
4. Note that the amplifier is not completely
disconnected from the AC mains
service unless the mains cable
is removed from the amplifier or the
mains outlet.
WARNING!
These speakers are capable of producing
sound pressure levels in excess of 85 dB,
which may cause permanent hearing
damage.
Guarantee
This product is supplied with one year guar-
antee against manufacturing faults or defects
that might alter its performance. Refer to sup-
plier for full sales and guarantee terms.
AUDIO PRECISION 1038BANEC LEVEL(dBr)
dBr
90
85
80
BASS TILT
90
85
80
BASS LEVEL
90
85
80
BASS ROLL-OFF
MIDRANGE LEVEL
100
20 50 200 500
Figure 8: The curves above show the effect of the 'bass', 'mid' and
'treble' level controls, and the 'bass tilt' and 'bass roll-off ' controls
on the free field response of the 1038B, measured at 2 m.
AUDIO PRECISION 1038BANEC LEVEL(dBr)
dBr
95
90
85
80
75
70 100
65 95
90
85
20 50 100 200 500
Figure 10: The upper curve group shows the horizontal
directivity characteristics of the 1038B in its vertical configuration
measured at 2 m. The lower curve is a 1/6 octave power
response measurement, derived from 144 individual directivity
measurements.
1037C Accessories
Wall mount
Floor stand
Handles
Protective grille
Rack adapter
* Factory installed option only
1038B Accessories
Floor stand
Handles
Protective grille
Rack adapter
* Factory installed option only
vs FREQ(Hz) 16 APR 02
TREBLE LEVEL
1k 2k 5k 10k 20k
Hz
vs FREQ(Hz) 16 APR 02
0°
15°
30° 45°
1k 2k 5k 10k 20k
Hz
Order code
1037-404
1037-405
1001-406*
1037-409
1037-412
Order code
1038-405
1001-406*
1038-409
1038-421
