PRODUCT GUIDE
MODEL 08301390
IMPORTANT: Fill out the product record information below.
Serial Number
See rating label on grill for serial number.
Date Purchased
For support and to register your
grill, please visit us at
www.charbroil.com
If you have questions or need
assistance during assembly,
please call 1-800-241-7548.
Estimated assembly time: 30 - 45 minutes
Tools required for assembly:
Phillips Screwdriver (Not Supplied)
Adjustable Wrench (Not Supplied)
Assembly instructions © 2009
®
TM REVISION 04
11/19/09 • 42804432
