Gefen CAT5-7000 User Manual

Gefen cat5-7000 extenders: user manual
Hide thumbs

Advertisement

Quick Links

Download this manual
CAT5•7000
U S E R
M A N U A L
www.gefen.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the CAT5-7000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gefen CAT5-7000

Summary of Contents for Gefen CAT5-7000

  • Page 1 CAT5•7000 U S E R M A N U A L www.gefen.com...
  • Page 2 Chatsworth, CA 91311 www.gefen.com support@gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. CAT5•7000 is a trademark of Gefen Inc. Macintosh is a trademark of Apple Computer Inc.

  • Page 3: Table Of Contents

    Introduction and Operation Notes How it Works CAT5•7000S Front Panel Layout CAT5•7000R Front Panel Layout CAT5•7000S Back Panel Layout CAT5•7000S Back Panel Function Descriptions CAT5•7000R Back Panel Layout CAT5•7000R Back Panel Function Descriptions CAT5 Cable Length Setup Link Cable Wiring Diagrams CAT5•7000 - Wiring Diagram CAT5•7000 Rack Mount System Specifi...
  • Page 4 Thank you for purchasing the new ex•tend•it CAT5•7000 series by Gefen, Inc. The ex•tend•it CAT5•7000 by Gefen allows users the benefi ts of extending USB, audio in, audio out, PS/2, RS232, and video signals beyond the desktop. In a growing number of applications, broadcast stations and production facilities there is a need to locate a computer remotely, from the keyboard, mouse, and video monitor.

  • Page 5: How It Works

    HOW IT WORKS CONTENTS The CAT5•7000 system consists of: (1) CAT5•7000S (sender unit) (1) CAT5•7000R (receiver unit) (2) 5 VDC power supply (2) Video cables (6FT) (1) USB cable (6FT) (2) PS/2 cables (6FT) (1) Audio cable (6FT) (1) Rack Ears (1) User Manual HOW IT WORKS In its most basic application, the CAT5•7000S sender unit resides next to the com put er.
  • Page 6 CAT5•7000S FRONT PANEL DE SCRIP TIONS Front Panel Function Descriptions Power On Indication - Indicates that the unit is on and plugged in.

  • Page 7: Cat5•7000R Front Panel Layout

    CAT5•7000R FRONT PANEL LAYOUT Front Panel Function Descriptions BRIGHTNESS 1 - Trim pot settings adjust video brightness for monitor 2 BRIGHTNESS 2 - Trim pot settings adjust video brightness for monitor 1 POWER ON INDICATOR - Indicates that the unit is on and plugged in.

  • Page 8: Cat5•7000S Back Panel Layout

    CAT5•7000S BACK PANEL LAYOUT...
  • Page 9 CAT5•7000S BACK PANEL LAYOUT POWER - 5 VDC external power supply MONITOR 1 - HD15 output connects to the monitor 1 for local video VIDEO IN 1 - HD15 input from computer MONITOR 2 - HD15 output connects to the monitor 2 for local video VIDEO IN 2 - HD15 input from computer AUDIO IN 1 - Audio mini jack input connects to computers audio output CAT5 VIDEO 2 - RJ-45 input extends video input 2 with CAT-5 cable...

  • Page 10: Cat5•7000R Back Panel Layout

    CAT5•7000R BACK PANEL LAYOUT...
  • Page 11 CAT5•7000R BACK PANEL FUNC TIONS POWER - 5 VDC external power supply VIDEO OUT 1 - HD15 output connecting to the video monitor 1 VIDEO OUT 2 - HD15 output connecting to the video monitor 2 AUDIO 1 - Audio mini jack connects to speakers USB OUT - 4 port power USB hub, connects to USB devices CAT-5 VIDEO 2 - RJ-45 input connects CAT-5 cable to receive extended video signals...

  • Page 12: Cat5 Cable Length Setup

    CAT5 CABLE LENGTH SETUP Jumper settings are used to set the focus of the picture and characters to the best possible sharpness. The jump ers in the CAT5•7000R are set at the factory as shown in the diagram below. The fi rst step to adjusting the video is to have the CAT5•7000S and CAT5•7000R con nect ed together with the CAT-5 cable that is going to be used in the in stal la tion.

  • Page 13: Link Cable Wiring Diagrams

    CAT5 LINK CABLE - WIRING DIAGRAM...

  • Page 14: Cat5•7000 Wiring Diagram

    CAT5•7000 WIRING DIAGRAM...
  • Page 15 CAT5•7500S RACK MOUNT DIAGRAM...
  • Page 16 SPECIFICATIONS Video Amplifi er Bandwidth ... 350 MHz Actual Bandwidth ... 120 MHz Input Video Signal ... 1.2 Volts p-p Input Sync Signal ... 5 Volts p-p (TTL) Horizontal Frequency Range ... 15-70 KHz Vertical Frequency Range ... 30-170 Hz Video In...

  • Page 17: Warranty

    Gefen Inc. warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen Inc. is notifi ed within two (2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
