- Page 1 CAT5•8000 U S E R M A N U A L www.gefen.com...
- Page 2 Chatsworth, CA 91311 www.gefen.com support@gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. CAT5•8000 is a trademark of Gefen Inc. © 2008 Gefen Inc., All Rights Reserved...
-
Page 3: Table Of Contents
Introduction / Operation Notes Features / Package Contents CAT5•8000 Sender Panel Descriptions CAT5•8000 Receiver Panel Description Connecting The CAT5•8000 Operating And Tuning The CAT5•8000 Tuning Diagram Wiring Diagram Network Wiring Diagram Specifi cations Warranty TABLE OF CONTENTS... -
Page 4: Introduction / Operation Notes
330 feet away. Multiple CAT5e extension cables (up to 4 for the CAT5-8000), user provided, connect the sender to the receiver units. Both the sender and the receiver are powered separately using the provided power supplies. -
Page 5: Features / Package Contents
Features • Relocate a triple display workstation up to 330 feet away • Supports resolutions up 1920 x 1200 • Supports USB 1.1 compliant devices • Analog audio and RS-232 extension Package Contents (1) CAT5•8000 Sender Unit (1) CAT5•8000 Receiver Unit (3) 6 ft VGA Cable (M-F) (1) 6 ft USB Cable (A-B) (1) 6 ft Mini Stereo Audio Cable (M-M) -
Page 6: Cat5•8000 Sender Panel Descriptions
CAT5•8000 SENDER PANEL DESCRIPTIONS... -
Page 7: Cat5•8000 Receiver Panel Description
CAT5•8000 RECEIVER PANEL DESCRIPTIONS... -
Page 8: Connecting The Cat5•8000
CONNECTING THE CAT5•8000 Connect the computer’s VGA output ports (supports up to three displays) to the CAT5•8000 Sender unit using the supplied VGA male to female cables. Connect the computer’s stereo audio mini-jack output to the CAT5•8000 Sender unit using the supplied stereo audio mini-jack cable. Connect the USB from the computer to the CAT5•8000 Sender unit using the supplied USB A to B cable. -
Page 9: Operating And Tuning The Cat5•8000
OPERATING AND TUNING THE CAT5•8000 Once all connection have been made and an image appears on the remote monitors, the images may need to be tuned to perfect the video signal. The CAT5•8000 has been engineered to provide exceptional video quality and user functionality, but the variance in cable length and quality is a variable that can create color separation and ghosting. -
Page 10: Tuning Diagram
Video 3 Blue Video 3 Green Video 3 Red Note: The jumpers on this board affect both Video 3 outputs. Video 1 Video 1 Green For 0-20 Meters please remove the jumper pin TUNING DIAGRAM Video 1 Video 2 Blue CAT5 Distance 81-100 Meters 61-80 Meters... -
Page 11: Wiring Diagram
WIRING DIAGRAM... -
Page 12: Network Wiring Diagram
Gefen has specifi cally engineered their products to work with the TIA/EIA-568-B specifi cation. Please adhere to the table below when fi eld terminating cable for use with Gefen products. Failure to do so may produce unexpected results and reduced performance.
