- Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read this comprehensive manual carefully before installing and switching on the monitor. Please keep this manual in a safe place for...
- Page 2 IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands Model No. : PL3820HB We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com You can access the Web page of different countries from there.
-
Page 3: Table Of Contents
CONNECTING YOUR MONITOR ..........11 COMPUTER SETTING ..............12 OPERATING THE MONITOR .............13 ADJUSTMENT MENU CONTENTS ..........15 SCREEN ADJUSTMENTS ............22 TROUBLE SHOOTING ..............25 RECYCLING INFORMATION .............26 APPENDIX ..................27 SPECIFICATIONS : ProLite S3820HSB ........27 DIMENSIONS : ProLite S3820HSB ..........28 COMPLIANT TIMING ..............28... -
Page 4: For Your Safety
DO NOT PUT ANY OBJECT INTO THE MONITOR Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fire, electric shock or damage. - Page 5 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located. Please also ensure that you do not place any heavy objects on the monitor, and that all cables are routed such that children may not pull the cables and possibly cause injury.
-
Page 6: Special Notes On Lcd Monitors
SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitors and do not indicate a problem. NOTE - When you first turn on the LCD monitor, the picture may not fit in the display area because of the type of computer that is used. In this case, adjust the picture position to the correct position. - You may find slightly uneven brightness on the screen depending on the desktop pattern you use. - Page 7 1 hour and there is evidence of a residual or “ghost” image, you should turn off the monitor for 1 hour in order to clear the residual image. For all LFD products, iiyama recommends displaying moving images and utilising a moving screen saver at regular intervals whenever the screen is idle. You could also turn off the monitor when not in use to assist the prevention.
-
Page 8: Customer Service
If you drop any materials or liquids such as water into the monitor when cleaning, WARNING unplug the power cable immediately and contact your dealer or iiyama service center. For safety reasons, turn off the power switch and unplug the monitor before you CAUTION clean it. -
Page 9: Before You Operate The Monitor
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office. Power Cable* AC Adapter*... -
Page 10: Controls And Connectors : Monitor
CONTROLS AND CONNECTORS : MONITOR <Back Controller> Power Button Green Normal Operation Power Indicator Power Management Power Off Increase / Input Select Button Menu / Enter Button Decrease / Brightness Button <Front> BEFORE YOU OPERATE THE MONITOR 7... - Page 11 <Back> DC IN DC jack Connector for AC Adapter( : Direct current) (DC-IN) VGA Connector DVI-D DVI-D Connector RS232 RS-232C 9pin RS-232C Connector AUDIO IN Mini Jack Audio Connector (PC Audio In) LIGHT SENSOR Light Sensor Light Sensor Connector HDMI HDMI HDMI Connector SPEAKERS Speakers HANDLES Handles 8 BEFORE YOU OPERATE THE MONITOR...
-
Page 12: Installation
INSTALLATION CAUTION Follow the manual instructions for the type of mount you have selected. Refer all servicing to qualified service personnel. Moving the monitor requires at least two people. Before installing, please make sure the wall is strong enough to hold the necessary weight of the display and the mount. - Page 13 [ROTATING THE DISPLAY] It is designed to be compatible in both landscape and portrait modes. Available Not Available Landscape Portrait Portrait 10 BEFORE YOU OPERATE THE MONITOR...
-
Page 14: Connecting Your Monitor
* Cable is not supplied with the monitor. If you use low quality cable, it may cause a result of electro- magnetic interference. Please contact the iiyama Support Centre in your country if you wish to connect the monitor via the VGA or DVI input. -
Page 15: Computer Setting
COMPUTER SETTING Signal Timing Change to the desired signal timing listed on page 28: COMPLIANT TIMING. 12 BEFORE YOU OPERATE THE MONITOR... -
Page 16: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 28. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 22 for SCREEN ADJUSTMENTS. - Page 17 [LOCK MODE] Back Controller Button: Pressing and holding the MENU and buttons when Menu is not displayed, will lock/unlock the Back Controller Button Lock function. 14 OPERATING THE MONITOR...
-
Page 18: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Brightness Adjustment Item Problem / Option Button to Press Automatically adjust image brightness to Ambient Light OSD Brightness Sensor* changing ambient lighting conditions. Ambient Light Sensor Adjust to minimum brightness according to your application. with OSD offset* Too dark Brightness* Direct Too bright... - Page 19 Signal Select Adjustment Item Problem / Option Button to Press Select the Analog (VGA) input. Select the Digital (DVI) input. HDMI Select the Digital (HDMI) input. Signal Select Direct Not available on this model. S-VIDEO Not available on this model. YPbPr Not available on this model. Return to Menu. Exit Direct You can skip the Menu items and directly display an option setting screen by using the following button operations.
- Page 20 Sound Adjustment Item Problem / Option Button to Press Too soft Volume Too loud Return the sound volume to the previous level. Mute Turn off the sound temporarily. Exit Return to Menu. OPERATING THE MONITOR 17...
- Page 21 Color Adjustment Item Problem / Option Button to Press Adjusts color automatically. Color Adjustment sRGB sRGB sRGB is an international standard which defines and unifies the difference of color NOTE appearance between equipment. Too weak User Green Too strong Color Temperature Blue Warm...
-
Page 22: Screen Adjustments
Image * Adjustment Item Problem / Option Button to Press Auto Adjustment * Adjusts H. Position, V. Position, Clock and Phase automatically. Too narrow Clock Too wide Phase To correct flickering text or lines Too left H. Position Too right Too low V. Position Too high Return to Menu. - Page 23 Tools Adjustment Item Problem / Option Button to Press You can set the OSD display duration time between 3 and 27 OSD timeout seconds. OSD is too left OSD H. Position OSD is too right OSD Control OSD is too low OSD V.
- Page 24 Exit Adjustment Item Problem / Option Button to Press Exit. Exit OPERATING THE MONITOR 21...
-
Page 25: Screen Adjustments
Perform the Auto Adjust first when the monitor is connected to a new computer, or resolution is changed. If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http://www.iiyama.com). Adjust the image by following the procedure below to get the desired picture. ®... - Page 26 Adjust the Auto Adjustment. Adjust the image manually by following procedure below when the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Adjust. Adjust the V. Position so that the top and bottom of the picture frame will fit to the display area.
- Page 27 Adjust the Phase to correct horizontal wavy noise, flicker or blur in the zebra pattern. In case the strong flicker or blurs remain on a part of the screen, repeat steps NOTE because the Clock may not be adjusted correctly. If the flicker or blurs still remain, set the refresh rate of computer to low (60Hz) and repeat steps from again. Adjust the H. Position after the Phase adjustment if the horizontal position moves during the adjustment. Adjust the Brightness and Color to get the desired picture after you complete the Clock and Phase adjustments.
- Page 28 MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem...
-
Page 29: Recycling Information
RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com for monitor recycling. 26 Recycling information... -
Page 30: Appendix
APPENDIX Design and specifications are subject to change without prior notice. SPECIFICATIONS : ProLite S3820HSB Size Category 38" Panel technology Size Diagonal: 37.6" (96.5cm) Pixel pitch 0.1596mm H × 0.4788mm V Brightness 1000cd/m (Typical) Panel Contrast ratio 4000 : 1 (Typical) Viewable angle Horizontal : 178 degrees, Vertical: 178 degrees (Typical) Response time 8ms (Typical) Display Colors Approx.16.7M Analog: Horizontal: 30.0-83.0kHz, Vertical: 50-76Hz Sync Frequency Digital: Horizontal: 30.0-83.0kHz, Vertical: 50-76Hz... -
Page 31: Dimensions : Prolite S3820Hsb
DIMENSIONS : ProLite S3820HSB 524.0mm/20.6” 4xM6 SCREW HOLE 962.5mm/37.9” (VESA MOUNT) 924.5mm/36.4” 400.0mm/15.7” COMPLIANT TIMING Horizontal Vertical Video Mode Dot Clock Frequency Frequency 640 × 480 31.469kHz 59.940Hz 25.175MHz 800 × 600 37.879kHz 60.317Hz 40.000MHz 1024 × 768 48.363kHz 60.004Hz 65.000MHz...
