USER MANUAL
ENGLISH
Thank you very much for choosing the iiyama
LCD display for signage.
We recommend that you take a few minutes
to read this comprehensive manual carefully
before installing and switching on the display.
Please keep this manual in a safe place for
your future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProLite LE4340OUHS and is the answer not in the manual?

Questions and answers

Related Manuals for Iiyama ProLite LE4340OUHS

Summary of Contents for Iiyama ProLite LE4340OUHS

  • Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD display for signage. We recommend that you take a few minutes to read this comprehensive manual carefully before installing and switching on the display. Please keep this manual in a safe place for...
  • Page 3 Model No. : PL4340UH / PL5040UH / PL5540UH mark: Equipment protected throughout by Double insulation or Reinforced insulation. We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com You can access the Web page of diff...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS..............1 SPECIAL NOTES ON LCD MONITORS .........3 CUSTOMER SERVICE ..............5 CLEANING ..................5 BEFORE YOU OPERATE THE DISPLAY ..........6 FEATURES..................6 CHECKING THE CONTENTS OF THE PACKAGE ......6 UNPACKING : ProLite LE4340UHS / ProLite LE5040UHS ....7 UNPACKING : ProLite LE5540UHS ..........7 CONTROLS AND CONNECTORS : DISPLAY ........8 INSTALLATION ................12...

  • Page 5: For Your Safety

    STOP OPERATING THE DISPLAY WHEN YOU SENSE TROUBLE If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the display and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fi re or electric shock.
  • Page 6 CAUTION INSTALLATION LOCATION Do not install the display where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the sun shines directly on the display. DO NOT PLACE THE DISPLAY IN A HAZARDOUS POSITION The display may topple and cause injury if not suitably located.

  • Page 7: Special Notes On Lcd Monitors

    SPECIAL NOTES ON LCD MONITORS  The following symptoms are normal with LCD monitors and do not indicate a problem. NOTE - When you fi rst turn on the LCD monitor, the picture may not fi t in the display area because of the type of computer that is used.
  • Page 8 1 hour in order to clear the residual image. For all LFD products, iiyama recommends displaying moving images and utilising a moving screen saver at regular intervals whenever the screen is idle. You could also turn off the monitor when not in use to assist the prevention.

  • Page 9: Customer Service

     If you drop any materials or liquids such as water into the display when cleaning, WARNING unplug the power cable immediately and contact your dealer or iiyama service center.  For safety reasons, turn off the power switch and unplug the display before you CAUTION clean it.

  • Page 10: Before You Operate The Display

    CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the display. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama offi ce.

  • Page 11: Unpacking : Prolite Le4340Uhs / Prolite Le5040Uhs

    UNPACKING : ProLite LE4340UHS / ProLite LE5040UHS Before unpacking your display, prepare a stable, level, and clean surface near a wall outlet. Set the LCD display box in an upright position and open from the top of the box before removing the top cushions.

  • Page 12: Controls And Connectors : Display

    CONTROLS AND CONNECTORS : DISPLAY  ProLite LE4340UHS / ProLite LE5540UHS <Back Controller> Power Button MUTE Mute Button Enter / Input INPUT Select Button + Button - Button Up Button  ProLite LE5040UHS Down Button <Back Controller> MENU Menu Button <Front>...
  • Page 13 <Remote sensor and power indicator - location> 1. Pull down/left the lens to improve remote control performance and ensure good visibility of the power status diode. 2. Push up/right the lens before mounting the display for video wall application. 3. Pull/Push the lens until hearing the click sound. ...
  • Page 14 <Back>  ProLite LE4340UHS  ProLite LE5040UHS / ProLite LE5540UHS 10 BEFORE YOU OPERATE THE DISPLAY...
  • Page 15 Green Lighting : Normal Operation If turn off the Power Button on the Remote Control and the Back Controller. Power Management Power Indicator Green Flash : When SCHEDULE is enabled. & Red Off Power Off Remote Sensor Remote Sensor AC IN AC-INLET AC Connector( : Alternating current) (AC-IN)

  • Page 16: Installation

    INSTALLATION WARNING To prevent injury, this display must be securely attached to the fl oor/wall in accordance with the installation instructions. CAUTION  Follow the manual instructions for the type of mount you have selected. Refer all servicing to qualifi ed service personnel. ...

  • Page 17: Controls And Connectors : Remote Control

    CONTROLS AND CONNECTORS : REMOTE CONTROL Turns the display ON and OFF. Control playback of media fi les. : Play : Stop [PLAY] : Pause : Quick-Return : Fast-Forward Selects the source. Press button to select from HDMI1, HDMI2, DVI, VGA, SOURCE Mediaplayer, Browser, iiSignage, PDF player or Custom.

  • Page 18: Preparing The Remote Control

    PREPARING THE REMOTE CONTROL To use the remote control, insert the two dry batteries. CAUTION Do not use any other batteries other than those specifi ed in this manual for the Remote Control. Do not insert old and new batteries together in the Remote Control. Make sure that the terminals match the "+"...

  • Page 19: Id Remote Control

    ID REMOTE CONTROL You can set the remote control ID when you want to use the remote control on specifi c monitors. ID Mode (To enter ID Mode) : Press and hold the ID button until the red LED blinks twice. Normal Mode (To leave ID Mode) : Press and hold the Normal button until the green LED blinks twice.

  • Page 20: Basic Operation

    BASIC OPERATION  Turning the display ON [Remote Control] The display is turned On and the Power Indicator turns to Green when you press the POWER button on the display or the Remote Control. The display is turned Off and the Power Indicator turns to Red when you press the POWER button on the display or the Remote Control.
  • Page 21  Move the cursor vertically [Remote Control] Select adjustment by pressing the button on the display or the / button on the remote control while the menu page is displayed on the screen. [Display]  Move the cursor horizontally [Remote Control] Select menu or setting, or perform the adjustment by pressing the + / - button on the display or the button on the...
  • Page 22  Adjust the volume of sound [Remote Control] Press the + / - button on the display or the remote control to adjust the volume of sound when the menu page is not displayed on the screen. [Display]  Switch the input signal [Remote Control] This is activated when you successively press the INPUT button on the display or the SOURCE button the remote...

  • Page 23: Connecting Your The Display : Prolite Le4340Uhs

    An incorrect connection may cause serious damage to both the display and the computer. The cable supplied with the display is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce.

  • Page 24: Connecting Your The Display : Prolite Le5040Uhs / Prolite Le5540Uhs

    An incorrect connection may cause serious damage to both the display and the computer. The cable supplied with the display is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce.
  • Page 25 [ Connection example with the peripheral device ] CAUTION Turn off the power switch and unplug the display and peripherals before connection to avoid electric shock or damage. NOTE  Refer to the user manual of peripherals at the same time. ...
  • Page 26 [ About the daisy chain ]  Monitor control connection RS-232C MONITOR1 MONITOR2 [RS-232C] [RS-232C IN] [RS-232C OUT] [RS-232C IN] [ To setup the network ] 1. Switch on the router and switch on its DHCP setting. 2. Connect the router to this display with an Ethernet cable. 3.

  • Page 27: Computer Setting

    Change to the desired signal timing listed on page 55: COMPLIANT TIMING.  Windows XP/Vista/7/8/8.1/10 Plug & Play The iiyama LCD display complies with DDC2B of VESA standard. The Plug & Play function runs on Windows XP/Vista/7/8/8.1/10 by connecting the display to DDC2B compliant computer with the Signal Cable supplied.

  • Page 28: Operating The Display

    OPERATING THE DISPLAY To create the best picture, your iiyama LCD display has been preset at the factory with the COMPLIANT TIMING shown on page 55. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 44 for SCREEN ADJUSTMENTS.
  • Page 29 NOTE  The BACK button on the remote control or the + button on the display can be used to return previous menu item.  Any changes are automatically saved in the memory when the On Screen Display disappears. Turning off the power should be avoided while using the Menu. ...

  • Page 30: Adjustment Menu Contents

    ADJUSTMENT MENU CONTENTS Picture Picture Brightness Screen Contrast Audio Sharpness Configuration1 Black level Configuration2 Tint Advanced option Color Noise reduction Medium Gamma selection Native Color temperature Native Color controal Action Smart power Overscan Adjustment Item Problem / Option Button to Press Too dark Brightness* Too bright...
  • Page 31 Picture Picture Contrast Screen Sharpness Audio Black level Configuration1 Tint Configuration2 Color Advanced option Noise reduction Medium Gamma selection Native Color temperature Native Color controal Action Smart power Overscan Picture reset Action Adjustment Item Problem / Option Button to Press Set user color.
  • Page 32 Screen Picture H position Screen V position Audio Clock Configuration1 Clock Phase Configuration2 Zoom mode Full Advanced option Custom zoom Action Auto adjust Action Screen reset Action Adjustment Item Problem / Option Button to Press Too left H Position* Too right Too low V Position* Too high...
  • Page 33 Audio Picture Balance Screen Treble Audio Bass Configuration1 Volume Configuration2 Audio out (line out) Advanced option Maximum volume Minimum volume Mute Audio source Digital Audio reset Action Audio Out Sync Adjustment Item Problem / Option Button to Press Left side speaker is louder. Balance Right side speaker is louder.
  • Page 34 Confi guration1 Picture Switch on state Force on Screen Panel saving Action Audio RS232 routing RS232 Configuration1 Boot on source Action Configuration2 Advanced option RGB range Auto Configuration1 reset Action Factory reset Action Adjustment Item Problem / Option Button to Press The display will remain off...
  • Page 35 Confi guration1 Picture Switch on state Force on Screen Panel saving Action Audio RS232 routing RS232 Configuration1 Boot on source Action Configuration2 Advanced option RGB range Auto Configuration1 reset Action Factory reset Action Adjustment Item Problem / Option Button to Press Cancel Return to Menu.
  • Page 36 Set the period of time the information OSD is Information OSD displayed on the upper right corner of the screen. Off / 1 - 60 seconds iiyama Logo does not display when the display is Off turned on. Logo iiyama Logo displayed when the display is turned on.
  • Page 37 Advanced option Picture IR control Unlock Screen Power LED Light Audio Keyboard control Unlock Configuration1 Off timer Configuration2 Action Date and time Advanced option Schedule Action HDMI with One Wire Language English OSD transparency Power Save Mode1 Advanced option reset Action Adjustment Item Problem / Option...
  • Page 38 Advanced option Picture IR control Unlock Screen Power LED Light Audio Keyboard control Unlock Configuration1 Off timer Configuration2 Date and time Action Advanced option Schedule Action HDMI with One Wire Language English OSD transparency Power Save Mode1 Advanced option reset Action Adjustment Item Problem / Option...
  • Page 39 Advanced option Picture IR control Unlock Screen Power LED Light Audio Keyboard control Unlock Configuration1 Off timer Configuration2 Date and time Action Advanced option Schedule Action HDMI with One Wire Language English OSD transparency Power Save Mode1 Advanced option reset Action Adjustment Item Problem / Option...
  • Page 40 APPLICATION Press the HOME button and number 1668 on the remote control. 36 OPERATING THE DISPLAY...
  • Page 41 The Boot Logo is only available when you select “User” of Logo function in the OSD menu "Confi guration2". For details, refer to download the Custom Boot Animation manual on the IIYAMA web site. For details, refer to download the iiSignage manual on the IIYAMA web site.
  • Page 42 Not available on this model. When you change the system settings, a problem like system Developer options instability may occur. In that case, contact your dealer or iiyama service center for assistance. Main info in About: System updates / Android version / Kernel version...
  • Page 43 <Android> * Android upgrade is not available on this model. • Settings : Go to settings app. • Apps : Show all apps. (Browser/Chromium/iiSignage/File Manager/Media Player/PDF player/ Settings) • Network : Set Ethernet. • Storage : Display current Android storage information. ...
  • Page 44 [Media Player] · Play: Select playlist to play · Compose: Edit playlist · Settings: Setting play properties  Compose 1. Select "Compose" on the page. First you select one playlist to play between FILE1 and FILE7. 2. Select the fi le and select edit or delete. 3.
  • Page 45  Settings Select "Settings" on the page. • Repeat mode: Play mode. Repeat once: All fi les are repeated once. Repeat all: All fi les in the same folder play repeatedly. • Slideshow Eff ect: Photo slideshow eff ect. Right to left: Change from right to left sliding. Fold: Change by rotating horizontally in the center.
  • Page 46 [PDF Player]  Compose 1. Select "Compose" on the page. First you select one playlist to play between FILE1 and FILE7. 2. Select the fi le and select edit or delete. 3. Save the edited fi le. -pdfs in /signage/pdf/ ...
  • Page 47 When Ver.3, Server/Account/PIN code is available. To be able to use the functionality, please download the iiSignage Software and User Manual from our Website https://iiyama.com/iisignage iiSignage software is using the network Port: 9989, future information’s are available in the iiSignage User Manual.

  • Page 48: Screen Adjustments

    If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http://www.iiyama. com).
  • Page 49 Adjust the Auto Adjustment. (Auto Adjust) Adjust the image manually by following procedure below when the screen has a fl icker or blur, or the picture does not fi t in the display area after performing the Auto Adjust. Adjust the V.Position so that the top and bottom of the picture frame will fi t to the display area.
  • Page 50 Adjust the Phase to correct horizontal wavy noise, fl icker or blur in the zebra pattern. NOTE  In case the strong fl icker or blurs remain on a part of the screen, repeat steps because the Clock may not be adjusted correctly. ...

  • Page 51: Power Management Feature

    POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the display when your computer is not in use. To use the feature, the display needs to be connected to a VESA DPMS compliant computer. There is a power management step the display takes as described below.

  • Page 52: Trouble Shooting

    DISPLAY or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the display and contact your dealer or iiyama service center for further assistance. Problem...

  • Page 53: Recycling Information

    RECYCLING INFORMATION For better environment protection please don't dispose your display. Please visit our web site: www.iiyama.com for monitor recycling. RECYCLING INFORMATION 49...

  • Page 54: Appendix

    APPENDIX Design and specifi cations are subject to change without prior notice. SPECIFICATIONS : ProLite LE4340UHS Size Category 43" Panel technology Size Diagonal: 42.5" (107.9cm) Pixel pitch 0.315mm H × 0.315mm V Brightness 350cd/m (Typical) Panel Contrast ratio 5000 : 1 (Typical) Viewable angle Horizontal : 178 degrees, Vertical: 178 degrees (Typical) Response time...

  • Page 55: Specifications : Prolite Le5040Uhs

    SPECIFICATIONS : ProLite LE5040UHS Size Category 50" Panel technology Size Diagonal: 49.5" (127.0cm) Pixel pitch 0.2854mm H × 0.2854mm V Brightness 350cd/m (Typical) Panel Contrast ratio 4000 : 1 (Typical) Viewable angle Horizontal : 178 degrees, Vertical: 178 degrees (Typical) Response time 8.5ms (Typical, Gray to Gray) Display Colors...

  • Page 56: Specifications : Prolite Le5540Uhs

    SPECIFICATIONS : ProLite LE5540UHS Size Category 55" Panel technology Size Diagonal: 54.6" (139cm) Pixel pitch 0.315mm H × 0.315mm V Brightness 350cd/m (Typical) Panel Contrast ratio 4000 : 1 (Typical) Viewable angle Horizontal : 178 degrees, Vertical: 178 degrees (Typical) Response time 8ms (Typical, Gray to Gray) Display Colors...

  • Page 57: Dimensions : Prolite Le4340Uhs

    DIMENSIONS : ProLite LE4340UHS 724.0mm/28.5” 968.0mm/38.1” 8xM6 SCREW HOLE 944.5mm/37.2” (VESA MOUNT) 400.0mm/15.7” 200.0mm/7.8” DIMENSIONS : ProLite LE5040UHS 942.5mm/37.1” 1123.5mm/44.2” 8xM6 SCREW HOLE (VESA MOUNT) 1100.0mm/43.3” 400.0mm/15.7” 400.0mm/15.7” APPENDIX 53...

  • Page 58: Dimensions : Prolite Le5540Uhs

    DIMENSIONS : ProLite LE5540UHS 944.0mm/37.2” 1239.0mm/48.8” 8xM6 SCREW HOLE 1213.5mm/47.8” (VESA MOUNT) 400.0mm/15.7” 400.0mm/15.7” 54 APPENDIX...

  • Page 59: Compliant Timing

    COMPLIANT TIMING Timing VGA 640x480 31.5 60.0 25.175 SVGA 800x600 37.9 60.0 40.000 XGA 1024x768 48.4 60.0 65.000 WXGA 1280x768 47.8 60.0 79.500 QVGA 1280x960 60.0 60.0 108.000 SXGA 1280x1024 64.0 60.0 108.000 VESA HD FWXGA 1366x768 47.7 60.0 85.500 CVT 1400x900 55.9 60.0...
