USER MANUAL
TABLE OF CONTENTS
FOR YOUR SAFETY...................................................................
SAFETY PRECAUTIONS...................................................
CUSTOMER SERVICE......................................................
CLEANING..........................................................................
BEFORE YOU OPERATE THE MONITOR..............................
FEATURES..........................................................................
ACCESSORIES...................................................................
LOCATION OF CONTROLS...............................................
CONNECTING YOUR MONITOR......................................
OPERATING THE MONITOR.....................................................
ADJUSTMENT MENU CONTENTS...................................
POWER MANAGEMENT FEATURE..................................
TROUBLE SHOOTING...............................................................
APPENDIX...................................................................................
SPECIFICATIONS: A101GT/A102GT.................................
SPECIFICATIONS: S101GT/S102GT.................................
PRESET MODES................................................................
CONNECTOR PIN ASSIGNMENT.....................................
Thank you very much for choosing the iiyama Vision Master color monitor.
We recommend that you take a few minutes to read carefully through this brief but comprehensive
manual before installing and switching on the monitor. Please keep this manual in a safe place
for your future reference.
ENGLISH
1
1
3
3
4
4
4
5
5
6
7
12
13
15
15
16
17
17
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Iiyama Vision Master Pro 501
Summary of Contents for Iiyama Vision Master Pro 501
-
Page 1: Table Of Contents
PRESET MODES..............CONNECTOR PIN ASSIGNMENT........Thank you very much for choosing the iiyama Vision Master color monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a safe place... -
Page 2: Fcc Declaration Of Conformity
To meet the FCC requirements, the specified signal cables below should be used. Signal Cable MB30 (Enclosed): 242Z013-01 Signal Cable MB31 (Optional): 242Z017-01 CAUTION Changes or modifications not expressly approved by Iiyama Electric Co., Ltd. could void the user's authority to operate the equipment. CANADIAN DEPARTMENT OF COMMUNICATIONS COMPLIANCE STATEMENT This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the radio interference regulation of the Canadian department of communications. -
Page 3: For Your Safety
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fire or electric shock. - Page 4 CAUTION MAINTAIN GOOD VENTILATION Ventilation slots are provided to keep the monitor from overheating. Covering the slots may cause fire. To allow adequate air circulation, place the monitor at least 10 cm (or 4 inches) from any walls. Do not remove the tilt stand when operating the monitor, ventilation slots on the cabinet bottom will be blocked and the monitor may overheat if the stand is removed.
-
Page 5: Customer Service
WARNING If you drop any materials or liquids such as water into the monitor when cleaning, unplug the power cable immediately and contact your dealer or iiyama service center. CAUTION For safety reasons, turn off the power switch and unplug the monitor before you clean it. -
Page 6: Before You Operate The Monitor
An optional USB Hub Stand is available for your Vision Master color monitor to enable it to act as a central connection between a USB compliant computer and peripherals. Please contact your local iiyama dealer or regional iiyama office for the optional parts below. -
Page 7: Location Of Controls
The cable supplied with the monitor is for a standard 15 pin VGA connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama office for a suitable adaptor. -
Page 8: Operating The Monitor
OPERATING THE MONITOR The iiyama Vision Master has been preset at the factory with the signal timings listed on page 17 in PRESET MODES to create the best picture. If an incorrect picture appears during the operation, adjust the image by following the procedure below to get the desired picture. -
Page 9: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS MENU : 1 Screen Control Adjustment Item Problem / Option Button to Press Too dull CONTRAST * Too intense Too dark BRIGHTNESS * Too bright NOTE “CENT” is displayed at the right hand side of the adjustment scale to indicate the middle of the adjustment range. - Page 10 MENU : 2 Distortion Adjustment Item Problem / Option Button to Press To correct distortion PIN-CUSHION To correct distortion TRAPEZOID To correct distortion PARALLELOGRAM PIN-BALANCE To correct distortion To correct tilt TILT NOTE “CENT” is displayed at the right hand side of the adjustment scale to indicate the middle of the adjustment range.
- Page 11 MENU : 3 Color Control Adjustment Item Problem / Option Button to Press 9300K : Normal white COLOR TEMP. (in K: Kelvin) 6500K : Warmer white 5000K : Paper white USER : User color adjustment NOTE “USER” is set to 9300K as the factory-preset. Too light Too dark Too light...
- Page 12 MENU : 4 Function Adjustment Item Problem / Option Button to Press H-MOIRE To correct vertical wavy lines V-MOIRE To correct horizontal wavy lines Only available on S101GT and S102GT Moiré is the result of interference between the phosphor layout and the video signal. By NOTE changing the horizontal and vertical size, the moiré...
- Page 13 Adjustment Item Problem / Option The current display resolution, horizontal scan DISPLAY FREQ. frequency and vertical refresh rate is displayed. For example, if the monitor was currently displaying a NOTE The following resolution is also typical “XGA” resolution format of 1024 pixels displayed if you receive a (horizontal) by 768 pixels (vertical) and the horizontal standard timing.
-
Page 14: Power Management Feature
POWER MANAGEMENT FEATURE The power management feature of this product complies with every power saving requirement of E NERGY ® , VESA DPMS and Nutek 803299. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. -
Page 15: Trouble Shooting
MONITOR or if the problem persists. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem Check The picture does not appear. - Page 16 Normal phenomenon on ‘Diamondtron’ monitors A101GT A102GT Misalignment of Aperture Grille Due to the nature of the Diamondtron™ CRT, in rare cases, a misalignment of the aperture grille may happen by the shock or vibration caused during transportation. If a black vertical line appears on the screen, apply a light shock to the side of the monitor with your hand.
-
Page 17: Appendix
APPENDIX SPECIFICATIONS: A101GT/A102GT Outline diagonal: 53cm (21"), Phosphor area diagonal: 50cm (20"), AG pitch 0.28mm, Diamondtron™, 90 degree deflection, Short persistence phosphor, Anti-reflection & Anti-static coating Sync Frequency A101GT Horizontal: 27.0-96.0kHz, Vertical: 50-160Hz A102GT Horizontal: 27.0-110.0kHz, Vertical: 50-160Hz Video Bandwidth 240MHz dot clock Maximum Resolution 1600 ×... -
Page 18: Specifications: S101Gt/S102Gt
SPECIFICATIONS: S101GT/S102GT Outline diagonal: 53cm (21"), Phosphor area diagonal: 51cm (20"), Dot pitch 0.27mm (Horizontal: 0.22mm, Vertical: 0.16mm), Flat square tube, 90 degree deflection, Short persistence phosphor, Anti-reflection & Anti-static coating Sync Frequency S101GT Horizontal: 27.0-96.0kHz, Vertical: 50-160Hz S102GT Horizontal: 27.0-110.0kHz, Vertical: 50-160Hz Video Bandwidth 240MHz dot clock Maximum Resolution... -
Page 19: Preset Modes
PRESET MODES The following chart indicates the Factory Preset Modes. ( : Preset) Vertical Sync Polarity Horizontal A101GT A102GT VESA Timing Name Frequency Frequency S101GT S102GT 640×480 @60Hz 59.9Hz Negative Negative 31.47kHz 640×480 @75Hz 75.0Hz Negative Negative 37.50kHz Negative 640×480 @85Hz 43.27kHz 85.0Hz Negative... - Page 20 IIYAMA ELECTRIC CO., LTD. 710-1 Kitaowaribe, Nagano-shi 381-0014 Japan This manual is printed on recycled paper. Dieses Handbuch ist auf Recyclingpapier gedruckt. Ce manuel est imprimé sur du papier recyclé. Part No. 870Z046A01 Deze handleiding is op kringlooppapier gedrukt. Printed in Japan...
