- Page 1 4x1 DVIKVM Switcher U S E R M A N U A L www.gefen.com...
- Page 2 Chatsworth, CA 91311 www.gefen.com support@gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. The 4x1 DVIKVM Switcher is a trademark of Gefen Inc.
-
Page 3: Table Of Contents
Introduction Front Panel Descriptions Back Panel Descriptions How To Connect The 4x1 DVIKVM Switcher RMT-4IR IR Code Confl icts IR Codes Operation Notes & Troubleshooting Wiring Diagram Specifi cations Warranty TABLE OF CONTENTS... -
Page 4: Introduction
INTRODUCTION Thank you for purchasing Gefen’ s 4x1 DVIKVM Switcher series. The 4x1 DVIKVM Switcher switches DVI, USB and audio between any combination of four computers. Now you can switch easily and reliably between any combination of four computers using one DVI display and USB keyboard and mouse. -
Page 5: Front Panel Descriptions
FRONT PANEL DESCRIPTIONS... -
Page 6: Back Panel Descriptions
BACK PANEL DESCRIPTIONS... -
Page 7: How To Connect The 4X1 Dvikvm Switcher
HOW TO CONNECT THE 4x1 DVIKVM SWITCHER Connect your computers DVI, USB, and audio to the 4x1 DVIKVM Switcher inputs using the supplied cables. Connect your DVI display to the DVI output of the 4x1 DVIKVM Switcher. Connect your USB and audio devices to the USB and audio outputs. Connect the RMT-4 remote control (if applicable). -
Page 8: Rmt-4Ir
RMT-4IR 1. Remove battery cover from the back of the RMT4-IR remote. 2. Verify that dip switches 1 & 2 are in the down (OFF) position. 3. Insert the battery, hold the battery so that you can see the positive side facing up. The side that is not marked must be facing down. -
Page 9: Ir Code Confl Icts
There are matching pairs of dip switches underneath the Switcher unit and under the remote battery cover. Switch 1 & 2 on the Remote and Switch 3 & 4 underneath the unit are the matching switches. These switches need to be matched for the remote to communicate with the switcher. -
Page 10: Ir Codes
4. Dip Switches 1 and 2 in the RMT4-IR correspond with Dip Switches 3 and 4 on the bottom of the 4x1 DVI Switch respectively. Switch the switches on the bottom of the 4x1 DVI Switch to match the dip switches on the RMT4-IR. The 4x1 DVI Switcher is now set to a new IR Code. -
Page 11: Operation Notes & Troubleshooting
DVI Switcher and locate the blank sticker. Peel it off to reveal a bank of four dip switch- es. Find the dip switch labeled “4” and fl ip it to the ON position. Now every time you switch the hub will re-initialize itself. -
Page 12: Wiring Diagram
4X1 DVI WIRING DIAGRAM... -
Page 13: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ... 1.65 GHz Single Link Range ... 1920 x 1200 Vertical Frequency Range ... 60 Hz DVI Input/Output Connector Type ... DVI-I (digital only) USB Input Connector ... Type “B” USB Output Connector ... Type “A” Power Consumption ...
