19 - BOARD NOMENCLATURE

Spare fuses
Reset Hard Shut
down button
Force select
Figure - GENERAL BOARD OVERVIEW
THE PROGRAMMING BUTTONS INDICATED IN THE ABOVE REFERENCE SHOULD BE USED ONLY AFTER UNDERSTANDING THE
MANUAL AND ITS RELATION TO THE PROGRAMMING SEQUENCES SHOWN ON THE FOLLOWING PAGES. CARE SHOULD BE TAKEN
WHENEVER CHANGES ARE IMPLEMENTED TO ENSURE PROPER FUNCTIONALITY AND SAFETY.
38
Incoming 30
LCD screen
Amp fuse
Speed select Delay select Function select Display select
Open the gate
Stop gate
movement
Close the gate
Selection up
OK or Enter
Selection down
