Connecting to Internet

This radio can be connected to a local area network (LAN) via the LAN port at the rear of the
unit.

Wired network

Connect the LAN socket on the unit to the corresponding port on your Router using a
commercially available LAN or Ethernet cable (CAT5 or better with RJ45 connector).
Using a wired network provides a better performance, than a wireless connection because
the attached devices connect directly to the network and are not subject to radio frequency
interference.
Internet
• This unit cannot be connected to a standalone modem directly. A router or a modem
incorporated with a router has to be used.
• When plugging or unplugging the LAN cable, hold the plug portion of the cable. When
unplugging, do not pull on the LAN cable but unplug while pressing down on the lock.
• Do not connect a modular phone cable to the LAN socket.
• Since there are various connection configurations, please follow the specifications and
instructions of your telecommunication carrier, Internet service provider, and router setting
guidebook.
Wired Router
WAN 1 2 3 4
Ethernet Cable
(not included)
To the LAN Socket
