FAUCET SPECIFICATIONS
Single Hole Bathroom Faucet
Model VG01023
MODEL VG01023
FEATURES
Solid brass construction
Single hole construction
Ceramic disk cartridge
Single lever faucet
Standard plumbing connections
Finish resist corrosion and tarnishing
PACKING LIST
Faucet Assembly
Brass ring
Rubber washer
Two Metal braided hoses
Nut
DIMENSIONS
MODEL #
FAUCET
HEIGHT
VG01023
6 1/4"
SPOUT
HOLE
REACH
DIAMETER
4 1/2"
1 3/8"
4 1/2"
Advertisement
Table of Contents
Related Manuals for VIGO VG01023
Summary of Contents for VIGO VG01023
- Page 1 FAUCET SPECIFICATIONS Single Hole Bathroom Faucet Model VG01023 MODEL VG01023 FEATURES Solid brass construction Single hole construction Ceramic disk cartridge Single lever faucet Standard plumbing connections Finish resist corrosion and tarnishing PACKING LIST Faucet Assembly Brass ring Rubber washer Two Metal braided hoses...
- Page 2 4 3/4" 3 3/4" 4 1/2" 2 3/8" 6 5/8" 1 7/8" VG01023 THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 1/8"...
- Page 3 Prior to installation please read the instructions thoroughly, confirm that all HOOK-UPS TO SUPPLY LINES. parts are included and visually inspect the unit for any defects. TIGHTENING NUTS SLIGHTLY If you have any questions please contact the Vigo Technical Support WILL STOP ANY MINOR Department before proceeding with installation. LEAKS.
- Page 4 Using either an allen key or a flat head screw driver, tighten the screw so handle has firm connection to cartridge. PARTS LIST - For any parts needed but not shown, please contact Vigo Technical Support PART # PART FINISH...
- Page 5 VIGO or an authorized VIGO dealer, through the lifetime of the original owner or end-user. VIGO warrants the cartridge component of the Product to be free from defects in workmanship and materials under normal use and service for a period of five (5) years from the initial date of purchase by the owner, contractor, or builder, from VIGO or an authorized VIGO dealer.
