FAUCET SPECIFICATIONS
Pull-Out Spray Kitchen Faucet
Model VG02006
MODEL VG02006
FEATURES
PACKING LIST
NOTE: All faucets are compliant to CEC 2016 regulations. If you
have inquiries about your water flow, please email
techmail@vigoindustries.com.
DIMENSIONS
MODEL #
HOLE
DIAMETER
VG02006
1 3/8"
12"
* = +/- 1"
FAUCET
SPOUT
HEIGHT
REACH
28"
8 5/8"
8 5/8"
1
