5. CONFIGURATION FROM PC
5.12

Routing of incoming calls

When applying for IMN numbers, a Terminal Id (OID/DID) is received from the
Net service provider. All devices connected to FELCOM 50 can make outgoing
calls. For incoming calls it must be assured that the Terminal Ids and MSN
numbers configured are as commissioned.
To make an incoming call reach a particular device, an MSN number and the
Terminal Id "connected" to the IMN number must be programmed into the
Communication Unit (CU). See later in this manual.
The table below lists valid MSN numbers for the available ISDN services.
Numbers to be programmed:
In ISDN device:
MSN number
For an easy start, the some Terminal Ids and MSN numbers have been
preprogrammed into the CU (marked with a star in the table).
In the 4.8 kbps speech, 3.1 kHz audio and 9.6 fax columns of the ISDN
PORTS table the Term.Id is represented by an X, allowing an ISDN Term.Id to
be used for analogue ports.
Note: A Term.Id already entered is not accepted.
VIA 2-line TA
4.8 speech 4.8 kbps speech
Term.ld MSN Term.ld MSN
02* 21* 01* 20*
0X 21
0X 22
0X 23
0X 24
0X 25
9.6 kbps fax (G3)
0X 26
0X 27
Term.ld MSN
0X 28
11* 40*
11/40: -fax on
TA
5-26
MSN number and Terminal Id
(the Terminal Id is paired with a specific IMN number)
LIST OF VALID TERMINAL IDs AND MSN NUMBERS
ISDN PORTS
64 kbps speech 3.1 kHz audio
Term.ld MSN Term.ld MSN
91* 30* 6X 4X
92 31 62* 42*
93 32 6X 4X
94 33 6X 4X
95 34 6X 4X
96 35
97 36
98 37
99 38
3.1 kHz/
64 kbps
audio service
In Communication Unit:
9.6 fax 56 kbps data
Term.ld MSN Term.ld MSN
1X 4X 71* 50*
12* 41* 72 51
1X 4X 73 52
1X 4X 74 53
1X 4X 75 54
76 55
77 56
78 57
79 58
ISDN/RS-232/USB PORTS
64 kbps data
Term.ld MSN
51* 60*
52* 61*
53* 62*
54* 63*
55 64
56 65
57 66
58 67
59 68
51/60, preset for ISDN port
52/61, preset for RS-232A port
53/62, preset for RS-232B port
54/63, preset for USB port
