4.9

Data service

Data transmission
FELCOM 50 provides access to the international ISDN/PSTN network data
services through its built-in modem capability.
The service is suitable for applications such as high-speed file transfer, video,
e-mail and internet.
The transmission rate over the satellite is 64 kbps, and any standard PC with a
serial port can be used.
Ports supporting 64 kbps data service (UDI):
RS232A
RS232B/RS422
USB
ISDN
For connecting up and configuration, see chapter 6.
ON
48 VDC
SYNC
ALARM
RS-232 A RS-232 B
5 4 3 2 1 5 4 3 2 1
9 8 7 6
9 8 7 6
4. OPERATION FROM PC
ISDN
ISDN
USB
ISDN
RS-422
The driver used with
the RS-232 B (DATA)
port can be switched
to be used with the
RS-422 (DATA) port
instead. The switching
is performed with the
ISDN Handset.
PC ISDN card
USB port
PC serial port
DTE
4-15
