4. OPERATION FROM PC
4.8

Telefax service

General
FELCOM 50 provides access to telefax service
•
Group4 fax at 64 kbps via the ISDN connector
•
Group3 fax at 9.6 kbps via the Terminal Adapter
•
Group3 fax using 3.1 kHz Audio service
Limitations
FELCOM 50 is fully compatible with the world's leading telefax machines and
telefax software standards. However, transmission may not be possible through
some of the telefax machines available on the market. Please check with your
Net service provider/FURUNO Distributor before purchasing a telefax for use
with FELCOM 50.
Transmission
Telefax calls made by FELCOM 50 are telefax only. Any telephone handset
connected to the telefax machine can not be used.
To send a fax, use the same dialing sequence as when making a call. See "2.12
Various call procedures" earlier in this manual.
The 9.6 kbps telefax transmissions normally take 1 minute per standard text
page using standard resolution. Using superfine or halftone resolution will double
the transmission time. To save time, avoid using a separate cover page.
If a call failure should occur while sending a multi-page document, re-send only
the failed pages.
4-14
Note! On a telefax with keypad, enter
last digit before starting transmission.
ON
48 VDC
SYNC
ALARM
RS-232 A RS-232 B
5 4 3 2 1 5 4 3 2 1
9 8 7 6 9 8 7 6
FELCOM50 CU
Digital
telefax(G4)
as the
ISDN
ISDN
USB
ISDN
RS-422
Terminal
Adapter
Analogue
Analogue
telephone
telefax(G3)
