Gateway Setting - Furuno Felcom 15 Operator's Manual

8.3.3

Gateway setting

Set gateway IP address when mail is sent from a PC on a different network
through a router.
Network 1
LAN Port
FURUNO
FELCOM 15
Note: If the router has DHCP, turn on DHCP in the Network menu to
automatically assign IP address, subnet mask and gateway.
Procedure
1. Press [F8] and [2] to show the System Setup menu.
2. Press the [ ] or [ ] key to choose Network Setup and then press the [Enter]
key.
3. Choose Network and then press the [Enter] key.
4. Press the [ ] key to choose Gateway and then press the [Enter] key.
5. Enter gateway IP address (IP address set on router) and then press the
[Enter] key.
6. Press the [Esc] key to open the update window.
7. Yes is selected; press the [Enter] key to update settings. The message
"Press ESC key to Restart FELCOM15." appears.
8. Press the [Esc] key to restart.
HUB
PC PC
Router
Network 2
PC
PC
8. E-MAIL BY PC
HUB
PC
PC
8-7
