QUICK START GUIDE
For a full explanation of all features and instructions, please refer to the User's Guide (available for download
from www.motorolahome.com).
1. Setting up your Digital Video Baby Monitor
A. Connecting the Power Supply of the Baby Unit.
MODELS:
MBP855CONNECT
MBP855CONNECT-2
MBP855CONNECT-3
MBP855CONNECT-4
B. Connecting the Power Supply of the Parent Unit.
WARNING:
Strangulation Hazard:
Children have
STRANGLED in cords.
Keep this cord out of
the reach of children
(more than 1m away).
Never use extension
cords with AC
Adapters. Only use the
AC Adapters provided.
NOTE: When the Baby and Parent Units are both turned on and within range, the Parent Unit should show a
colour image from the Baby Unit camera, but if the room is dark, the image will be in black and white, with an
icon showing, due to the infra-red illumination by the Baby Unit.
• Connect the small plug of the power adapter to the Baby Unit and
the other end to a suitable mains power socket.
• Only use the enclosed adapter (5V DC/ 1500mA).
• Ensure the ON/OFF switch
IMPORTANT: The Baby Unit is able to operate without power
connection up to 3 hours with the support of built-in rechargeable
battery (Ni-MH battery 2.4V, 900mAh). Please charge the unit at
least 16 hours for the first time use.
• Connect the micro USB plug of the power adapter to the Parent
Unit and the other end to a suitable mains power socket.
• Only use the enclosed adapter (5V DC/1500mA).
• A rechargeable battery (Lithium ion battery 1880mAh) inside the
Parent Unit allows you to move it without losing the link and
picture from the Baby Unit. The battery gives up to 5 hours
operation for the Parent Unit. We recommend you charge it for at
least 16 hours before first use, or when the Parent Unit indicates
the battery is low.
• Press and hold the POWER button
Parent Unit to turn it ON.
UK EN
is at the "ON" position.
on the top of the
