QUICK START GUIDE

For a full explanation of all features and instructions, please refer to the User's Guide.
1. Setting up your Digital Video Baby Monitor
MODELS:
A. Connecting power supply for
MBP853CONNECT
MBP853CONNECT-2
MBP853CONNECT-3
MBP853CONNECT-4
Switch to turn ON
the camera
C. Fastening the cover for the Parent Unit.
WARNING:
Strangulation Hazard:
Children have
STRANGLED in cords.
Keep this cord out of the
reach of children (more
than 1m (3ft) away).
Never use extension
cords with AC Adapters.
Only use the AC Adapters
provided.
the Baby Unit.
Connect the small plug of
Power
the power adapter to the
adapter plug
Baby Unit and the other end
to a suitable mains power
socket
Only use the enclosed
ON OFF
adapter (5V DC/1500mA).
Ensure the ON/OFF switch
is at "ON" position.
Small cross head or Flat
end screw driver
B. Installing the battery pack for the Parent Unit.
Insert the wire tab of the
rechargeable battery
Red
pack into the contact slot
as shown above and fit
the battery pack into the
compartment.
Black
D. Connecting the power supply for the Parent Unit.
Connect the small plug of
the power adapter to the
parent unit and the other
end to a mains power
socket.
Only use the enclosed
adapter (5V DC / 600mA).
Recommend charging
time of at least 16 hours
before first use.
