NEC MultiSync EX241UN-BK User Manual page 10

8. Connect one end of the power cord to the AC inlet on the back of the monitor and the other end to the power outlet.
NOTE: Please refer to the CAUTION section of this manual for proper selection of AC power cord.
9. Turn on the computer and the monitor by pressing the power button on the back of the monitor (Figure E.1).
10. No Touch Auto Adjust automatically adjusts the monitor to optimal settings upon initial setup. For further adjustments, use
the following OSD controls:
• AUTO CONTRAST (Analog input only)
• AUTO ADJUST (Analog input only)
Refer to the Controls section of this User's Manual for a full description of these OSD controls.
NOTE: If you have any problems, please refer to the Troubleshooting section of this User's Manual.
Raise and Lower Monitor Screen
The monitor may be raised or lowered in either portrait or landscape mode.
To raise or lower screen, place a hand on each side of the monitor and lift or lower to the desired height (Figure RL.1).
NOTE:
Handle with care when raising or lowering the monitor screen.
Screen Rotation
Before rotating, disconnect power cord and all cables, then the screen must be raised to the highest level and tilt to avoid
knocking the screen on the desk or pinching your fingers.
To raise the screen, place a hand on each side of the monitor and lift up to the highest position (Figure RL.1).
To rotate screen, place a hand on each side of the monitor screen and turn it from landscape to portrait (Figure R.1).
Power key
Figure E.1
Figure RL.1
Figure R.1
English-8
