STORAGE
Freezer Storage
FREEZER BASKETS
To remove, pull forward until basket stops. Pull the two
plastic tabs located behind the bottom two corners of the
basket forward, then lift up and out. Refer to the illustration
below. To reinstall, push drawer slides in. Align the basket
with slides and push back until it stops. Press down on the
front of the basket to engage slides. Refer to the illustration
below.
If door opening is limited to 90°, the top basket must be
removed before removing the middle or lower basket.
Freezer basket removal.
|
8 Sub-Zero Customer Care 800.222.7820

ICE CONTAINER

Column | To remove ice container, pull freezer drawer open
until it stops and lift container out. To reinstall, pull drawer
carrier out and align the bottom of the container with the
carrier. Refer to the illustration below.
Tall and drawer | To remove ice container, pull freezer
drawer open until it stops and lift container out. To reinstall,
place in the drawer with tabs on the bottom of the container
aligned with slots in the drawer. Refer to the illustration
below.
The ice maker must be turned off by touching
the ice storage container is removed. The unit is equipped
with a 3-minute delay after the ice container is removed, to
ensure cubes are not ejected before ice maker can be deac-
tivated or ice container is reinstalled.
Column ice container.
when
Tall and drawer ice container.
