PDF Logger Configuration Tool
Connect the datalogger to PC USB port. The PC will prompt to view files. Open the 'PDF
Logger Configuration Tool' from the list of available files. Refer to the Operation
Section for additional details on this tool:
3
4
5
6
7
8
9
1. CONVERT TO EXCEL: Create a spreadsheet report of the logged data
2. CONVERT TO PDF: Create a PDF report and a trend graph of the logged data
3. CONFIGURATION: Click to configure the logger
4. LANGUAGE SELECTION
5. SAMPLING RATE: Datalogger recording interval
6. START DELAY: Delay period from when START is pressed and datalogging begins
7. TEMP. UNIT: Temperature unit selection (
8. PASSWORD: Select a 16‐character password for tamper protection
9. COMPANY NAME: 20‐Character user label for inclusion in logging report
10. SAVE: Press SAVE to confirm the configuration
11. MANUAL: Open the supplied PDF User Manual
12. CANCEL: Abort the configuration
13. ALARM LIMIT: Select the RH% and Temperature low/high alarm limits. Note that
for the TH30, RH% is replaced by external temperature probe alarm limit
14. ALARM DELAY: Datalogger will ignore alarms for the programmed period of time
15. ALARM TYPE: Select Alarm mode
888.610.7664
2
1
10
11
www.calcert.com
15
10
20
5
25
0
30
15
14
13
12
o
o
C/
F)
5
RHT30_TH30‐en‐GB_V1.0 (11/16)
