Table Of Contents - peerless-AV MOD-FPP2KIT200 Manual

F ( 1 ) G ( 1 ) H ( 2 )
tilt box tilt plate horizontal rail
I ( 1 ) J ( 1 ) L ( 8 ) M ( 2 )
M8 x 15mm M8 x 55mm
left vertical rail right vertical rail
Q ( 2 )
M6 x 80mm
R ( 2 ) S ( 2 )
M5 x 16mm M6 nut
O ( 3 )
P (1)
4mm allen wrench
5mm allen wrench
T ( 2 )
support collar
AA ( 4 ) BB ( 4 ) CC ( 4 ) DD ( 4 )
M6 x 12mm M6 x 25mm M8 x 12mm M8 x 25mm
EE ( 8 ) FF ( 8 ) K ( 8 ) N ( 2 )
spacer M6/M8 washer M5 x 10mm set screw
