FLIR Lorex LBV1511 Series Quick Start Manual

Contents

• IR Night Vision Camera*
• Mounting Kit*
• 60ft BNC / Power Extension Cable*
• Multi-Camera Power Adapter**
* Per camera in multi-camera packs.
** A multi-camera power adapter that provides power to multiple cameras or individual power
adapters may be provided, depending on product configuration.
WARNING - A REGULATED power supply is REQUIRED for use with this
camera. Use of a non-regulated, non-conforming power supply can damage
this product and voids the warranty.

Warning/Caution

• Read this guide carefully and keep it for future reference.
• Follow all instructions for safe use of the product and handle
with care.
• Do not disassemble the cameras.
• Do not point the cameras directly towards the sun or a source of
intense light.
• Use only the supplied regulated power supply. Use of a non-
regulated, non-conforming power supply can damage this
product and voids the warranty.
• Periodic cleaning may be required. Use a damp cloth only. Do
not use harsh cleaners or aerosol cleaners.

Installation Tips

• Point the cameras where there is the least amount of obstructions
(i.e. tree branches).
• Install the cameras where they are difficult for vandals to reach.
• Secure cabling so that it is not exposed or easily cut.
• Cameras rated for outdoor use. Installation in a sheltered
location recommended.

Dimensions

70mm / 2.7"
70mm / 2.7"
154mm / 6.0"
Resources
Need Help?
Visit us online for up-to-date software and complete
instruction manuals
1
Go to www.lorextechnology.com
2
Search the model number of your product
3
Click on your product in the search results
4 Click on the Downloads tab
THE FOLLOWING RESOURCES ARE ALWAYS AT
YOUR FINGERTIPS
Product Information Specification Sheets
User Manuals Software Upgrades
Quick Start Guides Firmware Upgrades
Copyright © 2015 Lorex Corporation
As our products are subject to continuous improvement, Lorex reserves the right to modify product
design, specifications and prices, without notice and without incurring any obligation. E&OE
LBV1511_SERIES_TRIFOLDQSG_EN_R1
HD WEATHERPROOF
NIGHT VISION SECURITY CAMERA
Quick Start Guide
English Version 1.0
LBV1511 SERIES
