FLIR Lorex LNE3322 Series Quick Start Manual

Contents
• IP Dome Camera*
• Mounting Kit*
• Mounting Template*
• Cat5e UL Compliant (CM) Ethernet Extension Cable*
* Per camera.
ATTENTION
- It is recommended to connect the camera
to the NVR or an external PoE switch. If using a DC power
adapter with the camera, a REGULATED power supply is
REQUIRED for use with this camera. Use of a non-regulated,
non-conforming power supply can damage this product and
voids the warranty.
Warning/Caution
• Use the camera only with compatible Lorex NVRs
• Read this guide carefully and keep it for future reference
• Follow all instructions for safe use of the product and
handle with care
• Use the camera within given temperature, humidity and
voltage levels noted in Camera Specifications
• Do not disassemble the camera
• Do not point the camera directly towards the sun or a
source of intense light
• Periodic cleaning may be required. Use a damp cloth
only. Do not use harsh cleaners or aerosol cleaners
• The supplied extension cable is rated for surface
mounting only
• Cables for in-wall / floor-to-floor installations are sold
separately

Dimensions

93mm / 3.7"
74mm / 2.9"

Installation Tips

• Point the camera where there is the least amount of
obstructions (i.e. tree branches)
• Install the camera in a location that is difficult for vandals
to reach
• Secure cabling so that it is not exposed or easily cut
• Camera rated for outdoor use. Installation in a sheltered
location recommended

Resources

Need Help?
Visit us online for up-to-date
software and complete instruction manuals
1
Go to www.lorextechnology.com
2
Search the model number of your product
3
Click on your product in the search results
4
Click on the Downloads tab
Copyright © 2015 Lorex Corporation
As our products are subject to continuous improvement, Lorex Corporation reserves the right to modify
product design, specifications and prices, without notice and without incurring any obligation. E&OE
LNE3322_SERIES_TRIFOLDQSG_EN_R1
