Summary of Contents for Elmo P100N
-
Page 1: Document Camera
Français P000~P000 Deutch P000~P000 English P64~P125 P00~P00 Français P000~P000 Deutch P000~P000 DOCUMENT CAMERA P100N INSTRUCTION MANUAL Please read this instruction manual carefully before using this product and keep it for future reference. -
Page 2: Important Safeguards
ENGLISH IMPORTANT SAFEGUARDS I Read Instructions – All the safety and operating instructions should be read before the appliance is operated. I Retain Instructions – The safety and operating instructions should be retained for future reference. I Heed Warnings – All warnings on the product and in the operating instructions should be adhered to. - Page 3 I Grounding or Polarization – This product may be equipped with either a polarized 2-wire AC line plug (a plug having one blade wider than the other) or a 3-wire grounding type plug, a plug having a third (grounding) pin. The 2-wire polarized plug will fit into the power outlet only one way.
- Page 4 ENGLISH I Damage Requiring Service – Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: G When the power-supply cord or plug is damaged. G If liquid has been spilled, or objects have fallen into the product.
- Page 5 WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT THIS PRODUCT MAY CAUSE RADIO INTERFERENCE IN WHICH CASE THE USER MAY BE REQUIRED TO TAKE ADEQUATE MEASURES.
- Page 6 ENGLISH BEFORE YOU USE I Be sure to use the power cord and AC adapter attached to this camera system as accessories. I The power cord applicable to the local power specifications is attached. Be sure to use the power cord applicable to your local power specification. I Do not leave this product under direct sunlight or by heaters, or this product may be discolored, deformed, or damaged.
- Page 7 ENGLISH...
-
Page 8: Table Of Contents
ENGLISH CONTENTS 1. PART NAMES AND FUNCTIONS Name of Each Part...73 Appearance...73 Functions ...74 Front Operating Panel ...74 Rear Panel ...75 Side Panel ...76 OSD (On-Screen Display) ...77 Camera Mode (Menu when camera image is in display)...77 SD Mode (Menu when image stored in an SD card is in Wireless Remote Control ...80 Receivable Range ...82 Battery Change ...82... - Page 9 CONTENTS 5. VARIOUS FUNCTIONS AND OPERATIONS Lighting ...104 Zoom ...105 Image Selection ...106 Input image signal that can be output from the video output terminal [VIDEO OUT] into the analog RGB input terminal [RGB IN] ...107 Focus...108 Auto Focus...108 Manual Focus...109 Brightness Adjustment...110 Auto Brightness Adjustment...110 Manual Brightness Adjustment...110...
-
Page 10: Part Names And Functions
ENGLISH PART NAMES AND FUNCTIONS Name of Each Part I Appearance Front r r r e e e t t t w w w o o o Rear/Side q q q u u u y y y Front Name Camera head Lamp head Setup grip Camera column... - Page 11 Functions I Front Operating Panel * Hereinafter the menu items to be displayed/selected on the monitor or projection screen are referred to as "OSD (On-Screen Display)". Name q LCD panel LAMP e TEXT (Text mode) r GRAPHICS (Color document) t BRIGHTNESS (Dark) (Brightness) (Light)
- Page 12 ENGLISH I Rear Panel Name q DVI OUT To output digital video signal to the projector, the (DVI Output Terminal) PC monitor or other DVI input device w RGB OUT To output analog video signal to the projector, the (Analog RGB PC monitor or other RGB input device Output Terminal) e RGB IN...
- Page 13 I Side Panel w w w q q q Name (USB terminal, compliant with 2.0) (SD Card Slot) Main Switch (Ethernet terminal, 100BASE/10BASE) t MIC (Microphone input terminal) Explanation of the Ethernet terminal LED ENGLISH r r r e e e Function To enable the image transfer or the main unit control by using the utility software on the supplied CD-ROM when...
-
Page 14: Osd (On-Screen Display)
ENGLISH OSD (On-Screen Display) The menu items displayed/selected on the monitor or the projection screen are referred to as "OSD (On-Screen Display)". When the [MENU] button on the wireless remote control is pressed, the OSD menu appears on the monitor screen. (When this [MENU] button is pressed again, the OSD menu disappears.) Move to the item to be set by pressing the [ control, and press the [ENTER] button to fix the setting. - Page 15 Name Top hierarchy 2nd hierarchy 3rd hierarchy Capture Ethernet Guide Video Out All Mode Camera & SD (Image of Camera & SD only) Flickerless 60Hz (Flicker compensation) 50Hz Ethernet Status Default Setting change becomes effective when the power switch is turned OFF and then turned ON.
- Page 16 ENGLISH Name Top hierarchy 2nd hierarchy 3rd hierarchy Slide Interval Show (Interval of Image 5 Sec Settings Feed) P.98 Effect (Effect of Image Feed) Select (Object File) Order (Order of Image Feed) Repeat Start Slide Show Display Single 3×3 4×4 ] indicates the factory settings.
-
Page 17: Wireless Remote Control
Wireless Remote Control Name q PRESET (State Save) w CALL (State Call) e (Memory No.) ENGLISH Function To save the current setting state of the unit Use this function together with the memory No. To call the setting state Use this function together with the memory No. To indicate the memory No. - Page 18 ENGLISH Name r (OSD MENU t Operation) ENTER (Input) (Directions) (Menu Cancel) i POSI/NEGA o COLOR/B&W (Color/Black and White) !0 BRIGHT NORMAL NESS (Bright) (Brightness adjustment) (Dark) !3 ZOOM (Telescopic) (Wide-angle) To zoom out (Image Save) (SD mode) (CAMERA) (PC) !9 GRAPHICS (Color documents) @0 Text (Text Mode) @1 EDGE EFFECT...
-
Page 19: Receivable Range
I Receivable Range Point the infrared emitting part of the wireless remote control at the infrared sensor of the main unit, and press the button for desired function. The receiving range may be reduced when the main unit is placed in direct sunlight, near an inverter fluorescent lamp or in any other unfavorable surroundings. -
Page 20: Web Screen
ENGLISH WEB Screen When connection is made to http://192.168.0.100 on the browser, its top page opens. By clicking each item there, the clicked item can be operated. “192.168.0.100” is default. Input the IP address used in the network configuration of SET UP. I Top page It is necessary to set USB Mode/Ethernet to Ethernet on the OSD, and use it in the camera mode. - Page 21 I LIVE Name q CONTROL (WEB remote control) I REFRESH Name q manual w Interval e refresh r CAPTURE t TOP When the [PAUSE] button on the wireless remote control is pressed in the SD mode, the video image and the still image cannot be displayed. ENGLISH Function To display the WEB remote control when this item is...
-
Page 22: Configurations
ENGLISH I CONFIGURATIONS Name q Network Configuration w e FTP Client Configuration r t TOP Function To display the network configuration page Configuration of the current network To display the FTP client configuration page Configuration of the current FTP client To display the top page P.86 P.87... - Page 23 I Network Configuration Name q IP address w Subnet mask e Default gateway r Root password t User password Change u Setup i Clear o Configurations Network configuration change becomes effective when the power switch is turned OFF and then turned ENGLISH Function (<...
- Page 24 ENGLISH I FTP Client Configuration Name q The IP address of the image receiving server w The port number of the image receiving server e User account for the image receiving server r Password for the image receiving server t Passive Mode y Destination directory to save u The name of image file i Add the sequence number to...
-
Page 25: Web Remote Control
I WEB remote control Name q ZOOM TELE WIDE e LAMP r BRIGHTNESS NORMAL OPEN CLOSE u FOCUS NEAR !0 GRAPHICS !1 TEXT !2 EDGE EFFECT !3 IMAGE ROTATION !4 POSI/NEGA !5 COLOR/B&W ENGLISH Function (One-click operation) To zoom in To zoom out Each time this button is pressed, the material illumination lights up →... -
Page 26: Setting Up
ENGLISH SETTING UP Setting Up Release the camera column lock by turning the security lock knob. As shown in the right figure, hold the setup grip and raise the camera column. At this time, the camera head slides up in conjunction with the rise of the camera column. - Page 27 If the camera column is pulled or pushed forcedly, the camera might be pushed out of position by a function not to break mechanical parts, and the camera image might be displaced from the display center. In this case, initialize the camera position as follows: Fold the camera column on the stage.
-
Page 28: Connecting Cables
ENGLISH Connecting Cables MIC terminal • From PC microphone (electret condenser microphone) SD card USB terminal • To PC Ethernet terminal • To PC • To HUB To protect this product and the peripheral units to be connected to this product, be sure to turn OFF the power supply to all units beforehand. - Page 29 e Connecting to the unit having the analog RGB input terminal Connect the analog RGB cable to the [RGB OUT] terminal on the rear panel. The display position may be displaced from the center of the screen. In such case, adjust the horizontal and vertical positions manually from the connected device.
-
Page 30: Storing
ENGLISH STORING Storing Return the lamp to the original position. Then, hold the setup grip of the camera column and fold the camera column. At this time, the camera head slides down and the lamp column also folds. Turn OFF the power switch before the storing. Lock the camera column and the lamp column by turning the security lock. -
Page 31: Operation Procedure
OPERATION PROCEDURE Turning ON/OFF the Power Supply Be sure to use the main switch on the main unit to turn ON/OFF the power supply to the main unit. Do not turn ON/OFF the power supply by plugging/unplugging the AC adapter or the power plug. When connecting to other units, turn OFF the power supply to all connecting units. -
Page 32: Presentation By Using Documents, Films, Etc
ENGLISH Presentation by Using Documents, Films, etc. q Setting the main unit Set the main unit as show in the above figure, connect the main unit to the projector or the PC monitor, and then turn ON the power supply. w Adjusting the size Place an object on the stage, and adjust the position of the object with the zoom dial [ZOOM] on the front operating panel or the zoom button ([... -
Page 33: Presentation Using Optional Sd Card (Option)
This product can store images up to 2048 pcs. ELMO is not liable for any damage caused by the loss of the data in the SD card or passive damage. The dedicated conversion software attached to this camera system cannot be used in the SD mode. Also, do not switch the mode to the SD mode during when the dedicated conversion software is in use, or failure could be caused to this camera system. -
Page 34: Saving The Image
ENGLISH Presentation using optional SD card (Option) I Saving the Image (1) Press the [ ] button on the front operating panel or wireless remote control to switch the image mode to the Camera mode. (2) Press the [ ] button on the wireless remote control. (3) When the [ ] mark lights up on the screen, the image saving starts. -
Page 35: Deleting The Image
I Deleting the Image (1) Press the [ ] button on the front operating panel or wireless remote control to display the images stored in the SD card in the full screen display mode or the divided screen display mode. (2) Select the image to be deleted by using the direction buttons [ remote control. -
Page 36: Presentation Using The Supplied Software
"Utility Software" is available from the supplied CD-ROM supplied from us. "Utility Software" contains PC link software "Image Mate for Presentation" and TWAIN driver "ELMO TWAIN DS" (VHN) to allow the following operation: • Transfer of moving/still images to the PC •... -
Page 37: Transferring The Images From The Sd Card
Transferring the images from the SD card into the USB-connected PC Set [USB Mode/Ethernet] to [Mass Storage] on the OSD. When this product is USB-connected to the PC, image data in the SD card can be transferred into the PC. The connectable PC is one that has been installed with Microsoft OS Windows2000 (SP4 or newer) / XP (SP2 or newer) / Vista. -
Page 38: Displaying The Video Image Through
ENGLISH Displaying the Video Image through Network Connection Set [USB Mode/Ethernet] to [Ethernet] on the OSD. When connection is made to http://192.168.0.100 on the browser, its top page opens. When [50%], [75%] or [100%] of [Live] is clicked, the video image is displayed. When [REFRESH] or [CAPTURE] is clicked, the still image is displayed. -
Page 39: Capturing The Image Through Network Connection
Capturing the Image through Network Connection with the FTP Set [USB Model/Ethernet] to [Ethernet] on the OSD. Set [Capture] to [Ethernet] on the OSD. (FTP client function) The following 2 functions are available: • FTP client function — Saving the image file in the FTP server by pressing the [ the wireless remote control •... -
Page 40: Shooting Off The Stage
ENGLISH Shooting off the stage <Forward shooting> When the camera head is set in the horizontal direction, walls, distant views, etc. can be shot. When the object is distant, open the close-up lens holder. Do not fold the camera column when the close-up lens holder remains open, or the close-up lens could be damaged. -
Page 41: Lighting
VARIOUS FUNCTIONS AND OPERATIONS Lighting Front operating panel This camera is equipped with material illumination for presenting materials, such as printed matter, and base illumination for transparent materials, such as slide films and negative films. When the [ LAMP] button on the front operating panel or wireless remote control is pressed, the fluorescent lamp lights up in 1 –... -
Page 42: Zoom
ENGLISH Zoom Front operating panel When the zoom dial [ operating panel is turned or the zoom button [ ] on the wireless remote control is pressed, the document display range can be adjusted. According to the zoom dial turning angle, the zooming speed varies in 3 steps (3-step speed change). -
Page 43: Image Selection
Image Selection Front operating panel Each time the [ ], [ ] button and [ on the front operating panel or wireless remote control are pressed, the image is switched among the camera image, the image inputted in the analog RGB input terminal [RGB IN] and the image stored in the SD card. -
Page 44: Input Terminal [Rgb In]
ENGLISH I Input image signal that can be output from the video output terminal [VIDEO OUT] into the analog RGB input terminal [RGB IN] Signal Horizontal Mode name VGA1 37.861 VGA2 37.861 VGA3 37.927 VGA@60Hz 31.469 VGA@72Hz 37.861 VGA@75Hz 37.500 VGA@85Hz 43.269 SVGA@56Hz... -
Page 45: Focus
Focus Front operating panel The focus on the object is adjusted. I Auto Focus When the [AF] button on the front operating panel or wireless remote control is pressed, the camera is focused automatically. This product is of one-shot auto focus type. That is, once the camera is focused, the auto focus operation is released, and then focus position is maintained. -
Page 46: Manual Focus
ENGLISH Limit of focus adjustment: • With close-up lens TELE (Telescopic) WIDE (Wide-angle) : 85 – 410 mm (3.3 – 16.1 in) from close-up lens • Without close-up lens TELE (Telescopic) WIDE (Wide-angle) : 100mm – I Manual Focus When the focus button [FOCUS · NEAR] or [FOCUS ·... -
Page 47: Brightness Adjustment
Brightness Adjustment Front operating panel When either of the brightness adjustment buttons [ ] on the front operation panel or either of the brightness adjustment buttons [NORMAL · on the wireless remote control or WEB remote control is pressed or clicked, the image brightness is adjusted through the adjustment of the lens iris. -
Page 48: State Presetting
ENGLISH State Presetting The setting position of this product can be saved/called. Up to 8 positions can be saved. The presets that can be saved are as follows: • Current zoom field angle (Optical zoom range) • Brightness status • White Balance state •... -
Page 49: Microphone Input
Microphone Input Flickerless Ethernet Status Call Mic Volume Adjusting the microphone volume When [ ] of [Mic Volume] is pressed on the OSD, the volume level bar is displayed. Then, adjust the volume by using the direction buttons [ When the volume is brought to the left end of the level bar, the microphone falls into the mute status. White Balance I How to use [Auto] To be used for adjusting the white coloring automatically according to the status of the... -
Page 50: Setting Up
ENGLISH RS-232C SPECIFICATIONS This product can be controlled from a PC connected to this product through the RS-232C terminal [RS-232C]. Setting Up q Connect this product to a PC with an RS-232C cable. When using an RS-232C cable available on the market, make sure that pin connections are the same as below. -
Page 51: Data Format Specification
Data Format Specification This command is executed in the form of 1-command/1-packet. The next command is not accepted until the previous processing is completed. • The communication command always starts with STX (Start of Text), and ends with ETX (End of Text). -
Page 52: Transmission Specifications
ENGLISH Transmission Specifications • Full duplex start-stop sync. mode • Start bit • Data bit • Stop bit • Parity bit • X parameter • Baud rate (Communication speed) : 9600bps UART Communication Format Commands, parameters and data are all transmitted in ASCII code. Function Command Auto Focus... - Page 53 Function Command Parameter Slide-show image 0 (Left to right) feed effect 1 (LT to RB) 2 (RT to LB) 3 (None) Slide-show object 0 (All) file 1 (Locked) Slide-show feed 0 (FWD) order 1 (BWD) Slide-show image 0 (3s) feed interval 1 (5s) 2 (10s) 3 (15s)
-
Page 54: Connection
ENGLISH Function Command Image rotation 0 (0°) 1 (180°) Edge effect 0 (OFF) 1 (Low) 2 (Mid) 3 (High) White balance AW 0 (Manual) 1 (Auto) 2 (One Push) 3 (R_Up) 4 (R_Down) 5 (B_Up) 6 (B_Down) Text 0 (GRAPHICS) 1 (TEXT1) 2 (TEXT2) 3 (TEXT3) -
Page 55: Symptoms And Confirmation
TROUBLESHOOTING Symptoms and Confirmation Check the following items. If any abnormality is found, consult the seller from whom you have purchased this product or our branch/office near your location. Symptom No image is displayed • The cable is not connected correctly to the video-in terminal of the on the TV monitor. - Page 56 ENGLISH Symptom The network operation • The WEB connection works only in the following environment: is unstable. 1. The OS installed is Microsoft Windows2000/XP/Vista. 2. JRE1.5.0_12 or newer has been installed and Java (Sun) is valid. 3. Internet Explorer6 or 7 has been installed. The LAN cable cannot •...
-
Page 57: Replacement Of Lighting Lamp (Fluorescent Lamp)
Replacement of Lighting Lamp (Fluorescent Lamp) The lighting lamps (fluorescent lamps) are expendables. When any of them begins to shimmer or dim, replace it. For the replacement of the lamp, consult the dealer from whom you have purchased this product or our branch/office near your location. -
Page 58: General
ENGLISH SPECIFICATIONS I General Item Power source 12VDC (AC adapter: 100 ~ 240VAC) Power consumption 35W (AC adapter included) Outside dimensions 457×562×138mm (18.0×22.1×5.4 in) (When folded) 457×519×587mm (18.0×20.4×23.1 in) (When set up) Weight Approx. 8.5kg (18.7 lbs) (Main body only) Input selection Main body / External one system Output terminal... -
Page 59: Main Camera
I Main Camera Item Lens f = 4.9 ~ 78.4mm (16-time zoom), F = 2.7 Shooting speed 30 frames/sec Shooting area SXGA 405×324mm (15.9×12.8 in) max. 30×24mm (1.2×0.9 in) min. HDTV 405×224mm (15.9×8.8 in) max. 30×17mm (1.2×0.7 in) min. XGA 405×303mm (15.9×11.9 in) max. 30×23mm (1.2×0.9 in) min. Limit of focus With close-up lens: adjustment... -
Page 60: Network
Video cable (RCA pin connector) (3m) Analog RGB cable (DSUB 15P connector) (2m) DVI cable (2m) Infrared wireless remote control Batteries (Type R03, AAA) Instruction Manual for P100N Warranty Card for P100N USB cable (1.8m) Utility Software Installation Manual Utility Software CD-ROM Ethernet cross cable (1m) For the RCA pin, use a pin plug compliant with EIAJ RC-6703. -
Page 61: Copyright, License, Etc
Disclaimers Please be informed that Elmo shall not be liable at all to any damage, direct or indirect, caused by the use of our Ethernet function. Depending on the software installed in your PC or peripheral unit connected to your PC, the... - Page 62 ENGLISH Trademark Acknowledgements is a trademark of ELMO Co., Ltd. VESA and SVGA are registered trademarks of Video Electronics Standards Association. SXGA, VGA and XGA are trademarks or registered trademarks of International Business Machines Corporation. : SD logo is a trademark.
