7
ATTACHING THE FAN BLADES
CAUTION:
Remove the rubber packing mounts and discard before installation.
Insert one fan blade into the blade slot on the motor housing and secure
with the blade support plates and screws. Securely tighten screws. Repeat
process with other blades. (Fig. 15)
BLADE SUPPORT
PLATES
Fig. 15
SCREWS
FAN BLADE
