DEMO MANUAL DC2492A
parts list
ITEM
QTY
REFERENCE
Required Circuit Components
1
5
C3, C4, C5, C7, C8
2
2
C11, C14
3
1
C12
4
1
C13
5
1
C17
6
1
D1
7
1
Q1
8
1
R1
9
2
R7
10
1
R35
11
1
U1
Additional Demo Board Circuit Components
1
1
C1
2
1
C2
3
0
C6, C9
4
0
C10
5
0
C16
6
2
C18, C19
7
0
C23
8
0
D2, D3, D4
9
1
D5
10
1
D6
11
0
D7
12
0
D8
13
0
D9
14
0
Q2
15
1
Q4
16
1
Q5
17
1
R2
18
1
R4
19
7
R6, R12, R14, R22, R25, R45, R47
20
0
R9, R17
21
0
R13, R18, R19, R33, R34, R36, R39
22
5
R15, R21, R37, R38, R46
23
1
R23
4
PART DESCRIPTION
CAP ., 1µF, X7T, 250V, 1812
CAP ., 1000pF, X7R, 25V, 10%, 0603
CAP ., 0.1µF, X7R, 25V, 10%, 0805
CAP ., 0.1µF, X7R, 200V, 10%, 1206
CAP ., 1µF, X7R, 25V, 10%, 0805
DIODE, ES1PD, 200V, 1A, DO-220AA
MOSFET, N-CH, 150V, POWERPAK-SO-8
RES., SENSE, 0.004Ω, 1W, 2%, 2512
RES., 100Ω, 1/10W, 1%, 0603
RES., 10Ω, 1/10W, 1%, 0603
IC, LTC7000EMSE-1, MSE-16L(12)
CAP ., 10nF, X7R, 200V, 10%, 1206
CAP ., 22µF, ALUM, 160V, 20%, TH C-10X12.5
CAP ., OPTIONAL, 1812
CAP ., OPTIONAL, TH C-10X12
CAP ., OPTIONAL, 1206
CAP ., 0.1µF, X7R, 25V, 10%, 0603
CAP ., OPTIONAL, 0603
DIODE, OPTIONAL, SOT23
DIODE, MMSZ5V1T1, SOD-123
DIODE, MMBD4148, SOT23
DIODE OPTION, PDS4150, POWERDI5
DIODE, OPTION, BAS21, SOT23
DIODE., OPTION, CMMR1U, SOD-123F
MOSFET, N-CH, 80V, PSOF08A
XSTR, PNP , 0.2A, MMBT3906, SOT23
MOSFET, P-CH, -200V, SOT23
RES., 0Ω, 1/10W, 1%, 0805
RES., 100Ω, 1/2W, 5%, 1210
RES., 0Ω, 1/10W, 0603
RES., OPTIONAL, 0805
RES., OPTIONAL, 0603
RES., 100k, 1/10W, 1%, 0603
RES., 787Ω, 1/10W, 1%, 0603
MANUFACTURER/PART NUMBER
TDK, C4532X7T2E105K250KA
MURATA, GRM188R71E102KA01D
AVX, 08053C104KAT2A
AVX, 12062C104KAT2A
AVX, 08053C105KAT2A
VISHAY, ES1PD-M3/84A
FAIRCHILD, FDMS86250
PANASONIC, ERJM1WTF4M0U
VISHAY, CRCW0603100RFKEA
VISHAY, CRCW060310R0FKEA
LINEAR TECH., LTC7000EMSE-1#PBF
AVX, 12062C103KAZ2A
SUN ELECT., 160ME22HPC
OPTIONAL
OPTIONAL
OPTIONAL
AVX, 06033C104KAT2A
OPTIONAL
OPTIONAL
ON SEMICONDUCTOR, MMSZ5V1T1G
DIODES INC., MMBD4148-7-F
OPTIONAL
OPTIONAL
OPTIONAL
FAIRCHILD, FDBL86361_F085
FAIRCHILD, MMBT3906
DIODES INC., ZXMP2120FFTA
VISHAY CRCW08050000Z0EA
NIC, NRCP25J101TRF
VISHAY, CRCW06030000Z0EA
OPTIONAL
OPTIONAL
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW0603787RFKEA
dc2492af
