Parts List - Analog Devices LT7182S Demo Manual

PARTS LIST

ITEM QTY REFERENCE
23 11 R1, R11, R12, R14, R16, R18, R23, R25,
R35, R38, R41
24 5 R5, R6, R37, R39, R56
25 0 R13, R15, R22, R24, R26, R27, R28,
R33, R34, R36, R40, R42, R43, R49,
R50, R62, R63, R67
26 0 R29, R30
27 2 R44, R45
28 2 R46, R61
29 0 R48
30 5 R51, R52, R64, R65, R66
31 1 R53
32 0 R54
33 1 R57
34 1 U2
35 1 U3
36 1 U4
Hardware: For Demo Board Only
1 6 E1, E2, J3-J6
2 13 E12-E21, E40, E47, E48
3 6 E41-E46
4 1 J8
5 1 J9
6 1 J10
7 3 J11, J12, J13
8 4 JP1, JP2, JP3, JP4
9 4 MP1, MP2, MP3, MP4
10 2 SW1, SW2
11 4 XJP1, XJP2, XJP3, XJP4
DEMO MANUAL DC2836A
PART DESCRIPTION
RES., 0Ω, 1/10W, 0603
RES., 10k, 1%, 1/10W, 0603
RES., OPTION, 0603
RES., OPTION, 2512
RES., 10Ω, 5%, 1/10W, 0603
RES., 4.99k, 1%, 1/10W, 0603
RES., OPTION, 1206
RES., 866Ω, 1%, 1/10W, 0603
RES., 0Ω, 1W, 2010
RES., OPTION, 2010
RES., 0.01Ω, 1%, 1W, 2512
IC, EEPROM, 2Kb (256x8), TSSOP-8
IC, IDEAL DIO, 10DFN
IC, LDO, TSOT23-5
BANANA JACK, FEMALE
TEST POINT, TURRET, 0.094"
TEST POINT, TURRET, 0.064"
CONN., HDR, MALE, 2x6, 2mm
CONN., HDR, MALE, 2x7, 2mm
CONN., HDR, FEMALE, 2x7, 2mm
CONN., BNC, 50Ω
CONN., HDR, MALE, 1x3, 2mm
STANDOFF , NYLON, SNAP-ON, 0.50"
SWITCH, SLIDE, DPDT, 0.3A, 6VDC, PTH
CONN., SHUNT, FEMALE, 2 POS, 2mm
MANUFACTURER/PART NUMBER
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW060310R0JNEA
VISHAY, CRCW06034K99FKEA
VISHAY, CRCW0603866RFKEA
VISHAY, CRCW20100000Z0EFHP
VISHAY, WSL2512R0100FEA
MICROCHIP , 24LC025-I/ST
ANALOG DEVICES, LTC4413EDD#PBF
ANALOG DEVICES, LT1761ES5-3.3#PBF
KEYSTONE, 575-4
MILL-MAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
AMPHENOL, 98414-G06-12ULF
MOLEX, 0877601416
SULL. CONN. SOLU., NPPN072FJFN-RC
AMPHENOL RF , 112404
WURTH ELEKTRONIK, 62000311121
KEYSTONE, 8833
C&K, JS202011CQN
WURTH ELEKTRONIK, 60800213421
Rev. 0
9
