Analog Devices Linear DC2492A Manual page 5

parts list
ITEM QTY REFERENCE
24 2 R27, R31
25 1 R28
26 1 R29
27 1 R30
28 1 R32
29 1 SW1
30 1 SW2
31 1 U2
Hardware: For Demo Board Only
1 8 E1-E8
2 1 JP1
3 4 J1, J2, J3, J4
4 1 XJP1
5 4 MH1, MH2, MH3, MH4
DEMO MANUAL DC2492A
PART DESCRIPTION
RES., 240k, 1/10W, 1%, 0805
RES., 976k, 1/10W, 1%, 0603
RES., 232k, 1/10W, 1%, 0603
RES., 182k, 1/10W, 1%, 0603
RES., SENSE, 0Ω, 1/2W, 1%, 1225
SWITCH, SUB MINIATURE SLIDE
SWITCH, MICRO MINIATURE PUSHBUTTON
IC, LTC6993CS6-3, TSOT23-6
TESTPOINT, TURRET 0.094"
CONN., HEADER, 2X3, 2mm
CONN, BANANA JACK
SHUNT, 2mm
STAND-OFF , NYLON 0.559" tall
MANUFACTURER/PART NUMBER
VISHAY, CRCW0805240KFKEA
VISHAY, CRCW0603976KFKEA
VISHAY, CRCW0603232KFKEA
VISHAY, CRCW0603182KFKEA
TEPRO, RN5326
C&K COMPONENTS, JS202011CQN
TE CONNECTIVITY, FSM4JSMA
LINEAR TECH., LTC6993CS6-3#PBF
MILL MAX 2501-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000621121
KEYSTONE, 575-4
WURTH ELEKTRONIK, 60800213421
WURTH ELEKTRONIK, 702935500
dc2492af
5
