S
UPER
®
A+ SERVER
2022TG-HLIBQRF
2022TG-HLTRF
USER'S MANUAL
Revision 1.0c

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2022TG-HLIBQRF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Supero 2022TG-HLIBQRF

Summary of Contents for Supero 2022TG-HLIBQRF

  • Page 1 UPER ® A+ SERVER 2022TG-HLIBQRF 2022TG-HLTRF USER'S MANUAL Revision 1.0c...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.
  • Page 3 About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the A+ Server 2022TG-HLIBQRF/HLTRF. Installation and maintainance should be performed by experienced technicians only. The A+ Server 2022TG-HLIBQRF/HLTRF is a high-end server based on the SC827H-R1620BP 2U rackmount chassis and the dual processor H8DGT-HLIBQF/HLF serverboards.
  • Page 4 A+ Server 2022TG-HLIBQRF/HLTRF USER'S MANUAL Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the H8DGT-HLIBQF/HLF serverboard, including the locations and functions of connections, headers and jumpers. Refer to this chapter when adding or removing processors or main memory and when reconfiguring the serverboard.

  • Page 5: Table Of Contents

    Preface Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processor ......................1-2 Memory ......................1-2 Onboard SATA ....................1-2 PCI Expansion Slots ..................1-2 Onboard Controllers/Ports ................1-2 Other Features ....................1-2 Server Chassis Features ................1-4 System Power ....................
  • Page 6 A+ Server 2022TG-HLIBQRF/HLTRF USER'S MANUAL Installing the System into a Rack ..............2-4 Identifying the Sections of the Rack Rails ............2-4 Locking Tabs ....................2-5 Releasing the Inner Rail ................. 2-5 Installing The Inner Rails on the Chassis ............2-6 Installing the Outer Rails on the Rack ............
  • Page 7 Preface Processor and Heatsink Installation..............5-3 Installing a CPU Heatsink ................5-5 Removing the Heatsink ................... 5-6 Installing Memory .................... 5-7 DIMM Module Population Configuration ............ 5-8 Motherboard Details ..................5-10 Connector Definitions ..................5-12 Jumper Settings .................... 5-15 Explanation of Jumpers ................5-15 Onboard Indicators ..................
  • Page 8 A+ Server 2022TG-HLIBQRF/HLTRF USER'S MANUAL 6-10 Expansion Card Setup .................. 6-14 6-11 Drive Bay Installation/Removal ..............6-16 Accessing the Drive Bays ................6-16 6-12 Power Supply ....................6-20 Power Supply Replacement ................6-20 Chapter 7 BIOS Introduction ...................... 7-1 Main Menu ...................... 7-2 Advanced Settings Menu ................

  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction Overview The A+ Server 2022TG-HLIBQRF/HLTRF is a high-end server comprised of the SC827H-R1620BP 2U server chassis and four distinct computing nodes each with the H8DGT-HLIBQF/HLF dual processor serverboard. Please refer to our web site for information on operating systems that have been certified for use with the system (www.supermicro.com).

  • Page 10: Serverboard Features

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Serverboard Features At the heart of the A+ Server 2022TG-HLIBQRF/HLTRF lies four H8DGT-HLIBQF/HLF dual processor motherboards based upon one AMD ® SR5690 chipset and one AMD SP5100 Southbridge chipset. Below are the main features of the H8DGT-HLIBQF/HLF.
  • Page 11 Chapter 1: Introduction Figure 1-1. AMD SR5690/SP5100 Chipset: System Block Diagram Note: This is a general block diagram and may not exactly represent the features on your motherboard. See the previous pages for the actual specifications of your motherboard. HT3 Link DIMM 1A DIMM 1A (8+8)x(8+8)-6.4GT/s...

  • Page 12: Server Chassis Features

    UID button and LEDs for each node. Rear I/O Each computing node provides a low-profile add-on card slot, a COM port, a VGA port, two USB 2.0 ports, one IPMI Ethernet port, two gigabit Ethernet ports, and one InfiniBand port (2022TG-HLIBQRF only) per node.

  • Page 13: Cooling System

    Chapter 1: Introduction Cooling System The SC827 chassis accepts four system fans powered from the backplane. When Node A and/or Node B are powered on, both fans on the left of the chassis will run. When Node C and /or Node D are powered on, both fans on the right of the chassis will run.

  • Page 14: Contacting Supermicro

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 15: Twin 2 : System Notes

    SATA Backplane/Drives As a system, the 2022TG-HLIBQRF/HLTRF supports the use of twelve SATA drives. A single SATA backplane works to apply system-based control for power and fan speed functions, yet at the same time logically connects a set of three SATA drives to each serverboard.
  • Page 16 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Notes...

  • Page 17: Chapter 2 Server Installation

    Decide on a suitable location for the rack unit that will hold the A+ Server 2022TG-HLIBQRF/HLTRF. It should be situated in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and electromagnetic fields are generated.

  • Page 18: Choosing A Setup Location

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Choosing a Setup Location • Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches) and approximately 30 inches of clearance in the back of the rack to allow for sufficient airflow and ease in servicing.

  • Page 19: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Warning! To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to ensure that the system remains stable. The following guidelines are provided to ensure your safety: •...

  • Page 20: Installing The System Into A Rack

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Installing the System into a Rack This section provides information on installing the chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean that the assembly procedure will differ slightly from the instructions provided.

  • Page 21: Locking Tabs

    Chapter 2: Server Installation Locking Tabs Each inner rail has a locking tab. This tab locks the chassis into place when installed and pushed fully into the rack. These tabs also lock the chassis in place when fully extended from the rack. This prevents the server from coming completely out of the rack when when the chassis is pulled out for servicing.

  • Page 22: Installing The Inner Rails On The Chassis

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Installing The Inner Rails on the Chassis Installing the Inner Rails 1. Confirm that the left and right inner rails have been correctly identified. Place the inner rail firmly against the side of the chassis, aligning the hooks on the side of the chassis with the holes in the inner rail.

  • Page 23: Installing The Outer Rails On The Rack

    Chapter 2: Server Installation Figure 2-5. Extending and Releasing the Outer Rails L-min=676.00(26.61")(outer rail) 21D01 Installing the Outer Rails on the Rack Installing the Outer Rails 1. Press upward on the locking tab at the rear end of the middle rail. 2.

  • Page 24: Standard Chassis Installation

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Standard Chassis Installation Stability hazard. The rack stabilizing mechanism must be in place, or the rack must be bolted to the floor before you slide the unit out for servicing. Failure to stabilize the rack can cause the rack to tip over.

  • Page 25: Checking The Serverboard Setup

    Chapter 2: Server Installation Checking the Serverboard Setup After you install the 2022TG-HLIBQRF/HLTRF in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. Accessing the inside of the System...

  • Page 26: Checking The Drive Bay Setup

    Each processor needs its own heat sink. See Chapter 5 for instructions on processor and heat sink installation. 2. Your 2022TG-HLIBQRF/HLTRF server system may have come with system memory already installed. Make sure all DIMMs are fully seated in their slots.

  • Page 27: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview Several buttons and LEDs indicate the status of the system. There are four control panels, two on each side of the front edges of the chassis, that each monitor the associated computing node. There are also LEDs on the drive carriers that indicate the status of the drive.

  • Page 28: Control Panel Buttons

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Control Panel Buttons There are two push-buttons on each control panel on the front of the chassis. They controll the computing node associated with that control panel. Power: The main power switch applies or removes power to the node from the power supply.

  • Page 29: Drive Carrier Leds

    Chapter 3: System Interface Alert: The Informational LED signals status alerts. Informational LED State Description An overheat condition has occured. Continuously on and red (This may be caused by cable congestion). Blinking red (1Hz) Fan failure, check for an inoperative fan. Blinking red (0.25Hz) Power failure, check for a non-operational power supply.
  • Page 30 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Notes...

  • Page 31: About Standardized Warning Statements

    Chapter 4: Warning Statements for AC Systems Chapter 4 Standardized Warning Statements for AC Systems About Standardized Warning Statements The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance.
  • Page 32 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 33 Warning Statements for AC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬ ‫ل‬ ‫الىقائٍة‬...

  • Page 34: Installation Instructions

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de...

  • Page 35: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 36: Power Disconnection Warning

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A.
  • Page 37 Chapter 4: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 38: Equipment Installation

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.

  • Page 39: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 40: Battery Handling

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خالل استخذاو‬...
  • Page 41 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 42: Redundant Power Supplies

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 43: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 44: Comply With Local And National Electrical Codes

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫اللىحة‬ ‫أوالطاقة المىجىدة على‬ ‫التيار الكهزبائي‬ ‫مه‬ ‫خطز‬ ‫هناك‬ ‫هذا الجهاس‬ ‫خدمة‬ ‫كه حذرا عند‬ ‫يعمل‬ ‫النظام‬ ‫عندما يكىن‬...

  • Page 45: Product Disposal

    Chapter 4: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫المتعلقة‬ ‫المحلية والىطىية‬ ‫قىاويه‬ ‫يجب أن يمتثل لل‬ ‫الكهربائية‬...

  • Page 46: Hot Swap Fan Warning

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 47 Chapter 4: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 48: Power Cable And Ac Adapter

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Power Cable and AC Adapter Warning! When installing the product, use the provided or designated connection cables, power cables and AC adaptors. Using any other cables and adaptors could cause a malfunction or a fire. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only.
  • Page 49 Chapter 4: Warning Statements for AC Systems Attention Lors de l'installation du produit, utilisez les bables de connection fournis ou désigné. L'utilisation d'autres cables et adaptateurs peut provoquer un dysfonctionnement ou un incendie. Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifiés qui ont UL ou CSA indiqué...
  • Page 50 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Notes 4-20...

  • Page 51: Chapter 5 Advanced Motherboard Setup

    Chapter 5: Advanced Motherboard Setup Chapter 5 Advanced Motherboard Setup This chapter covers the steps required to install the H8DGT-HLIBQF/HLF motherboard into the SC827H-R1620BP chassis, connect the data and power cables and install add-on cards. All motherboard jumpers and connections are also described.

  • Page 52: Motherboard Installation

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Motherboard Installation The motherboard installation procedure is expailned in Chapter 6, "Advanced Chassis Setup." I/O Port Connections The I/O ports are color coded to make setting up your system easier. See Figure 5-1 below for the colors and locations of the various I/O ports.

  • Page 53: Processor And Heatsink Installation

    Chapter 5: Advanced Motherboard Setup Processor and Heatsink Installation Caution: When handling the processor, avoid placing direct pressure on the label area of the fan. Also, do not place the serverboard on a conductive surface, which can damage the BIOS battery and prevent the system from booting up. Notes: •...
  • Page 54 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL 3. Use your thumb and your index finger to hold the CPU. Locate and align pin 1 of the CPU socket with pin 1 of the CPU. Both are marked with a triangle. Triangle 4. Align pin 1 of the CPU with pin 1 of the socket.

  • Page 55: Installing A Cpu Heatsink

    Chapter 5: Advanced Motherboard Setup Installing a CPU Heatsink 1. Remove power from the system and unplug the AC power cord from the power supply. 2. Do not apply any thermal grease to the heatsink or the CPU die; Screw #1 Screw #2 the required amount has already been applied.

  • Page 56: Removing The Heatsink

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Removing the Heatsink Caution! We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instructions below to prevent damage to the CPU or the CPU socket.

  • Page 57: Installing Memory

    Chapter 5: Advanced Motherboard Setup Installing Memory Caution: Use extreme care when installing or removing DIMM modules to prevent damage. Installing Memory 1. Insert each memory module vertically into its slot, paying attention to the notch along the bottom of the module to prevent inserting the module incorrectly (see Figure 5-2).

  • Page 58: Dimm Module Population Configuration

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Figure 5-2. Installing DIMM into Slot To Install: Insert Notch Notch module vertically and press down until it snaps into place. Front View Pay attention to the alignment notch at the bottom. Note: Notch should align with...
  • Page 59 Chapter 5: Advanced Motherboard Setup Note 1: Due to OS limitations, some operating systems may not show more than 4 GB of memory. Note 2: Due to memory allocation to system devices, the amount of memory that remains available for operational use will be reduced when 4 GB of RAM is used. The reduction in memory availability is disproportional.

  • Page 60: Motherboard Details

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Motherboard Details See the Figure 5-3 for a layout of the H8DGT-HLIBQF/HLF motherboard. H8DGT-HLIBQF/HLF Quick Reference Jumper Description Default Setting JBT1 CMOS Clear (See Section 5-9) JIB1 InfiniBand Enable/Disable (H8DGT-HLF only) Pins 1-2 (Enabled) JI2C1/JI2C2...
  • Page 61 Chapter 5: Advanced Motherboard Setup Figure 5-3. H8DGT-HLIBQF/HLF Motherboard Layout (not drawn to scale) COM1 JIB1 JPG1 JPB1 JPL1 JWD1 SPEAKER SR5690 JBT1 SP5100 BATTERY CPU1 CPU2 Note: Jumpers not indicated are for test purposes only. Not all ports, connectors and jumpers are available for all server models.

  • Page 62: Connector Definitions

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Connector Definitions Universal Serial Bus Ports Universal Serial Bus Ports Pin Definitions Two Universal Serial Bus ports (USB 2.0) (USB 0/1, USB4) and one additional Type A port (USB4) are USB0/1 USB4 included on the serverboard. See the table...
  • Page 63 Chapter 5: Advanced Motherboard Setup Overheat LED Overheat LED Pin Definitions Connect an LED to the JOH1 header to (JOH1) provide warning of chassis overheating. See Pin# Definition the table on the right for pin definitions. 3.3V OH Active Unit Identifier Button UID Button Pin Definitions A Unit Identifier (UID) button is located on...
  • Page 64 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL JP3 Adapter Card Connector JP3 Adapter card connector slot provides front access to the power supply, serial ATA and Front Panel Control connections for the H8DGT series motherboards. Plug an Adapter card into this connector to use the functions indicated above.

  • Page 65: Jumper Settings

    Chapter 5: Advanced Motherboard Setup Jumper Settings Connector Pins Explanation of Jumpers To modify the operation of the motherboard, Jumper jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function Setting of the connector.
  • Page 66 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL I2C to PCI-Express Slot C to PCI-Express Slot Jumper Settings JI2C1/JI2C2 allows you to enable the I C bus (JI2C1/JI2C2) to communicate with the PCI-Express slot. Jumper Setting Definition For the jumpers to work properly, please set...

  • Page 67: Onboard Indicators

    Chapter 5: Advanced Motherboard Setup InfiniBand Port Enable/Disable InfiniBand Port (H8DGT-HLF only) Jumper Enable (JIB1) Jumper Settings JIB1 enables or disables the InfiniBand port Jumper Setting Definition on the H8DGT-HLF serverboard. The default Closed Enabled position is on pins 1 and 2 to enable the port. Open Disabled See the table below for jumper settings.
  • Page 68 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Power LED Power LED (DP2) DP2 is an Onboard Power LED. When State System Status this LED is lit, it means power is present Standby power present on the serverboard. Be sure to turn off the...

  • Page 69: 5-10 Enabling Sata Raid

    Chapter 5: Advanced Motherboard Setup 5-10 Enabling SATA RAID Now that the hardware is set up, you must install the operating system and the SATA RAID drivers, if you wish to use RAID with your SATA drives. The installation procedure differs depending on whether you wish to have the operating system installed on a RAID array or on a separate non-RAID drive.

  • Page 70: Enabling Sata Raid In The Bios

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Enabling SATA RAID in the BIOS Before installing the Windows operating system, you must change some settings in the BIOS. Boot up the system and hit the <Delete> key to enter the BIOS Setup Utlility. After the setup utility loads, 1.
  • Page 71 Chapter 5: Advanced Motherboard Setup Figure 5-5. DotHill RAID Utility Program Screen Figure 5-6. Adaptec RAID Utility Program Screen Using the DotHill and Adaptec RAID Utility The RAID Utility program allows you to define the drives you want to include in the RAID array and the mode and type of RAID.

  • Page 72: Installing The Raid Driver During Os Installation

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Installing the RAID Driver During OS Installation You may also use the procedure below to install the RAID driver during the Windows OS installation: 1. With the Windows OS installation CD-ROM in the CD drive, restart the system.
  • Page 73 Chapter 5: Advanced Motherboard Setup Figure 5-7. Driver/Tool Installation Display Screen Note: Click the icons showing a hand writing on paper to view the readme files for each item. Click the computer icons to the right of these items to install each item (from top to the bottom) one at a time.

  • Page 74: Superdoctor Iii

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Figure 5-8. SuperDoctor III Interface Display Screen (Health Information) Figure 5-9. SuperDoctor III Interface Display Screen (Remote Control) Note: The SuperDoctor III program and User’s Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/accessories/software/...

  • Page 75: 5-12 Serverboard Battery

    Chapter 5: Advanced Motherboard Setup 5-12 Serverboard Battery Caution: There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarites (see Figure 5-10). This battery must be replaced only with the same or an equivalent type recommended by the manufacturer (CR2032).
  • Page 76 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Notes 5-26...

  • Page 77: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC827H-R1620BP chassis. These steps will help eliminate the most common problems encountered. Some steps may not apply to your particular installation.

  • Page 78: Control Panel

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Figure 6-1. Front and Rear Chassis Views Control Panel Control Panel Control Panel Control Panel SATA Drives (12) Ethernet Ports IPMI LAN Port COM1 Port VGA Port USB Ports Infiniband Port Control Panel The control panels (located on the front of the chassis) must be connected to the backplane in order to power on and to provide you with system status indications.

  • Page 79: Chassis Cover

    Chapter 6: Advanced Chassis Setup Chassis Cover Before operating the SC827 chassis for the first time, it is important to remove the protective film covering the top of the chassis, in order to allow for proper ventilation and cooling. Removing the Chassis Cover and Protective Film (Figure 6-2) 1.

  • Page 80: Air Shrouds

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Air Shrouds Air shrouds concentrate airflow to maximize fan efficiency. The SC827 chassis requires air shrouds for each motherboard node. Air shrouds vary depending upon the motherboard used. See the illustrations below. Installing an Air Shroud (Figure 6-3) 1.

  • Page 81: Checking The Airflow

    Chapter 6: Advanced Chassis Setup Checking the Airflow Checking Airflow • Make sure there are no objects to obstruct airflow in and out of the server. In addition, if you are using a front bezel, make sure the bezel's filter is replaced periodically.

  • Page 82: System Fans

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL System Fans Four fans circulate air through the chassis to lower the internal temperature. They are not hot-swappable. No tools are required for installation. Changing a System Fan 1. If necessary, open the chassis while the power is running to determine which fan has failed.
  • Page 83 Chapter 6: Advanced Chassis Setup 6. Replace the fan housing into the chassis and reconnect the fan's power cord to the backplane (Figure 6-5). 7. Confirm that the fan is working properly before replacing the chassis cover. Figure 6-5. System Fan Placement...

  • Page 84: Removing And Installing The Backplane

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Removing and Installing the Backplane The SC827 chassis backplane is located behind the hard drives and in front of the front system fans. In order to change jumper settings on the backplane, it may be necessary to remove the backplane from the chassis.
  • Page 85 Chapter 6: Advanced Chassis Setup Figure 6-7. Loosening the Spring Bar Screws in the Floor of the Chassis 6. Loosen the three screws in the spring bar, located on the floor of the chassis, indicated by the arrows below (Figure 6-7). 7.

  • Page 86: Installing The Backplane

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Installing the Backplane Installing the Backplane into the Chassis (Figure 6-9) 1. Ensure that all of the hard drive carriers have been removed from the bays in the front of the chassis and that the spring bar has been loosened as directed in the previous section.

  • Page 87: Installing The Motherboard

    Chapter 6: Advanced Chassis Setup Installing the Motherboard I/O Shield The I/O shield holds the motherboard ports in place. The I/O shield does not require installation. Figure 6-10. I/O Shield Placement I/O Shields Permanent and Optional Standoffs Standoffs prevent short circuits by securing space between the motherboard and the chassis surface.
  • Page 88 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL 5. Lay the first motherboard in the drawer aligning the standoffs with the motherboard. 6. Secure the motherboard to the drawer using the rounded, Phillips head screws included for this purpose. Apply no more than 8 inch-pounds to avoid damaging the board and components.

  • Page 89: Adapter Card Replacement

    Chapter 6: Advanced Chassis Setup Adapter Card Replacement Each motherboard drawer comes equipped with an adapter card which plugs into the backplane. In the unlikely event that the adapter card needs to be replaced, installation requires only a Phillips head screwdriver. Removing the Adapter Card 1.

  • Page 90: 6-10 Expansion Card Setup

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL 6-10 Expansion Card Setup The SC827 chassis supports one low-profile expansion slot for each node, for a total of four slots in the chassis. The maximum length for expansion cards is up to 5.9” (149.86 mm).
  • Page 91 Chapter 6: Advanced Chassis Setup Figure 6-14. Installing the Low Profile Expansion Card Add-on Card Riser Card PCI Slot Screw Shield Add-on Card Riser Card Bracket Add-on Card Bracket Screws 4. Connect the expansion card to the riser card. 5. Secure the riser card to the motherboard tray using the riser card screw. 6.

  • Page 92: 6-11 Drive Bay Installation/Removal

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL 6-11 Drive Bay Installation/Removal Accessing the Drive Bays SATA Drives: You do not need to access the inside of the chassis or remove power to replace or swap SATA drives. Proceed to the next step for instructions. You must use standard 1"...
  • Page 93 Chapter 6: Advanced Chassis Setup Removing Hard Drive Trays from the Chassis (Figure 6-16) 1. Press the release button on the drive tray. This extends the drive bay handle. 2. Use the handle to pull the drive out of the chassis. Figure 6-16.
  • Page 94 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL The drives are mounted in drive carriers to simplify their installation and removal from the chassis (Figure 6-17). These carriers also help promote proper airflow for the drive bays. Figure 6-17. Chassis Drive Tray Dummy Drive...
  • Page 95 Chapter 6: Advanced Chassis Setup 2. Remove the tray from the carrier (Figure 6-19). 3. Install a new drive into the carrier with the printed circuit board side facing down so that the mounting holes align with those in the carrier. 4.

  • Page 96: 6-12 Power Supply

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL 6-12 Power Supply The system includes two 1620 Watt power supplies. They are auto-switching capable, so they automatically sense and operate at a 100v to 240v input voltage. An amber light will be illuminated on the power supply when the power is off. An illuminated green light indicates that the power supply is operating.
  • Page 97 Chapter 6: Advanced Chassis Setup Figure 6-20. Changing the Power Supply Release Tab 6-21...
  • Page 98 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Notes 6-22...

  • Page 99: Chapter 7 Bios

    Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMIBIOS™ Setup utility for the H8DGT-HLIBQF/HLF serverboard. The 16 Mb AMI BIOS® is stored in a flash chip and can be easily upgraded using a floppy disk-based program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 100: Main Menu

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Main Menu When you first enter AMI BIOS Setup Utility, you will see the Main Menu screen. You can always return to the Main Menu by selecting the Main tab on the top of the screen with the arrow keys.
  • Page 101 Chapter 7: BIOS is detected, at which point you will need to press the F1 button to re-enter the BIOS setup menu. The options are Enabled and Disabled. Hit 'DEL' Message Display Use this option to Enable or Disable the "Press DEL to run setup" message in POST.
  • Page 102 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Microcode Update This setting Enables or Disables microcode updating. Secure Virtual Machine Mode This setting is used to Enable or Disable SVM. Power Now This setting is used to Enable or Disable the AMD Power Now feature.
  • Page 103 Chapter 7: BIOS Channel Interleaving This option enables channel memory interleaving. Options include Auto or Disabled. CS Sparing This setting will reserve a spare memory rank in each node when enabled. Options are Enabled and Disabled. Bank Swizzle Mode This setting Enables or Disables the bank swizzle mode. ...
  • Page 104 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Memory Timing Parameters This selects the which node's timing parameters to display. Options include CPU Node 0, CPU Node 1, CPU Node 2 or CPU Node 3.  SouthBridge Configuration OHCI/EHCI HC Device Functions These settings allow you to either Enable or Disable functions for OHCI or EHCI bus devices.
  • Page 105 Chapter 7: BIOS PATA Channel Configuration This allows you to set PATA channel configuration. Options include SATA as Primary or SATA as secondary.  Primary/Secondary/Third/Fourth IDE Master/Slave LBA/Large Mode LBA (Logical Block Addressing) is a method of addressing data on a disk drive.
  • Page 106 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL S.M.A.R.T. Self-Monitoring Analysis and Reporting Technology (SMART) can help predict impending drive failures. Select "Auto" to allow BIOS to auto detect hard disk drive support. Select "Disabled" to prevent AMI BIOS from using the S.M.A.R.T. Select "Enabled" to allow AMI BIOS to use the S.M.A.R.T.
  • Page 107 Chapter 7: BIOS Onboard LAN Controller This option Enables or Disables the onboard LAN controller. ROM Scan Ordering This setting determines which kind of option ROM activates prior to another. Options include Onboard First and Addon First. PCIe Slot 1 / SXB2 Riser These setting sets options for the PCIe Slot 1/SXB2 Riser slot on the serverboard.
  • Page 108 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL  SuperIO Device Configuration Serial 1 Address This option specifies the base I/O port address and Interrupt Request address of serial port 1. Select "Disabled" to prevent the serial port from accessing any system resources. When this option is set to Disabled, the serial port physically becomes unavailable.
  • Page 109 Chapter 7: BIOS Selects the flow control to be used for console redirection. Options are None, Hardware and Software. Redirection After BIOS POST Options are Disable (no redirection after BIOS POST), Boot Loader (redirection during POST and during boot loader) and Always (redirection always active). Note that some OS's may not work with this set to Always.
  • Page 110 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL CPU Temperature Display (CTD) CPU Temperature descriptions are defined as: Low  [Tctl Value = Lowest Value, Tctl Value = -45] Medium  [Tctl Value = -46, Tctl Value = 60] High  [Tctl Value = -61 and Above] Note: Only CPU temperature (Low, Medium, High) and system temperature (RT1) are required to be displayed in BIOS and in-system monitoring software.
  • Page 111 Chapter 7: BIOS Condition When a CPU is overheating Front Panel Overheating LED On and Solid Red Onboard Buzzer or Speaker On and Continuous Sound System Fan Speed Controls Full Speed Report PROCHOT BMC Event Log Record PROCHOT Super Doctor Report PROCHOT Super Doctor Event Log Record PROCHOT...
  • Page 112 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL  IPMI Configuration This menu shows static information about the IPMI firmware revision and status of the BMC, as well as options for IPMI configuration.  View BMC System Event Log Pressing the Enter key will open the following settings. Use the "+" and "-" keys to navigate through the system event log.
  • Page 113 Chapter 7: BIOS Subnet Mask In the field provided here enter the Subnet address in the decimal form of xxx.xxx.xxx.xxx with xxx having a value of less than 256 and in decimal form only. The current subnet address in the BMC is shown. Gateway Address In the field provided here enter the Gateway address in the decimal form of xxx.xxx.xxx.xxx with xxx having a value of less than 256 and in decimal form...

  • Page 114: Security Menu

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Security Menu AMI BIOS provides a Supervisor and a User password. If you use both passwords, the Supervisor password must be set first. Change Supervisor Password Select this option and press <Enter> to access the sub menu, and then type in the password.
  • Page 115 Chapter 7: BIOS  Hard Disk Drives This feature allows you to specify the boot sequence from the list of available hard disk drives. A device that is in parenthesis has been disabled in the corresponding type menu.  CD/DVD Drives This feature allows you to specify the boot sequence from the list of available CD/ DVD drives.

  • Page 116: Exit Menu

    A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Exit Menu Select the Exit tab from AMI BIOS Setup Utility screen to enter the Exit BIOS Setup screen. Save Changes and Exit When you have completed the system configuration changes, select this option to leave BIOS Setup and reboot the computer, so the new system configuration parameters can take effect.

  • Page 117: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 118 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Notes...

  • Page 119: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Note: Unless noted specifications apply to a complete system (all serverboards). Processors Two AMD Opteron 6000 series processors in AMD Socket G34 type sockets per node Note: Both CPUs must be of the same type. Note: Please refer to our web site for a complete listing of supported processors.
  • Page 120 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL Serverboard H8DGT-HLIBQF/HLF (proprietary form factor) Dimensions: (LxW) 6.8" x 16.64" (173 x 423 mm) Chassis SC827H-R1620BP (2U rackmount) Dimensions: (WxHxD) (WxHxD) 17.25 x 3.47 x 28.5 in. (438 x 88 x 724 mm) Weight Gross (bare bones): 85 lbs. (38.6 kg.)
  • Page 121 Appendix B: System Specifications Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/-3- 3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) California Best Management Practices Regulations for Perchlorate Materials:...
  • Page 122 A+ SERVER 2022TG-HLIBQRF/HLTRF USER'S MANUAL (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.

This manual is also suitable for:

2022tg-hltrf

Table of Contents
