SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE
A French manual is available upon request. Order P/N 900998-02.
Ce manuel d'installation est disponible en francais, simplement en faire
la demande. Numéro de la pièce 900998-02.
• Hot! Do not touch! The glass and
surfaces of this appliance will be hot
during operation and will retain heat
for a while after shutting off the appli-
ance. Severe burns may result.
• Carefully supervise children in the
same room as appliance.
• If small children are present in the home, it is
recommended that this appliance be fitted with
an adjustable safety gate or barrier screen.
C
US
WARNING
Listed to standards:
ULC-S610 & UL-127
Report # 14-180
EPA Cert. No. 537
INSTALLATION AND
OPERATION INSTRUCTIONS
WCT4820WS
EPA Wood-Burning Fireplaces
P/N 900998-00 REV. NC 07/2019
MODEL
WCT4820WS
This installation manual will enable you to obtain a safe, efficient
and dependable installation of your fireplace system. Please read
and understand these instructions before beginning your installation.
Do not alter or modify the fireplace or its components under any cir-
cumstances. Any modification or alteration of the fireplace system,
including but not limited to the fireplace, chimney components and
accessories, may void the warranty, listings and approvals of this system
and could result in an unsafe and potentially dangerous installation.
IHP wood-burning fireplaces are designed for use as a supplemental
heater. They are not intended for continuous use as a primary heat
source.
Fireplace, also for use in mobile or
manufactured homes with solid fuel only.
• The fireplace cannot be operated without a door.
Consult your dealer to select the correct door.
• Important! To assure proper alignment of glass
doors: Install this fireplace in a square and
plumb condition, using shims as necessary at
sides and/or bottom.
• Install the fireplace only as described in these
instructions.
This product can expose you to chemicals includ-
ing Carbon Black, which is known to the State of
California to cause cancer, and Carbon Monoxide,
which is known to the State of California to cause
birth defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov
P900998-00
WARNING
WARNING
Advertisement
Table of Contents
Related Manuals for Superior Fireplaces WCT4820WS
Summary of Contents for Superior Fireplaces WCT4820WS
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS WCT4820WS EPA Wood-Burning Fireplaces P/N 900998-00 REV. NC 07/2019 MODEL WCT4820WS This installation manual will enable you to obtain a safe, efficient and dependable installation of your fireplace system. Please read and understand these instructions before beginning your installation.
-
Page 2: Table Of Contents
USE SOLID NATURAL WOOD FUEL INTRODUCTION ONLY. This appliance is designed to burn dry Introduction ........Page 2 The WCT4820WS wood-burning fireplace is seasoned natural wood only (see Page 6 for a Parts Required .........Page 2 an energy efficient, heat circulating, closed list of prohibited fuels). -
Page 3: Mobile Or Manufactured
IMPORTANT! GENERAL SAFETY WARNING WARNING PRECAUTIONS. READ AND UNDERSTAND THESE SAFETY Use care when selecting window Always ensure that the air inlet to RULES BEFORE YOUR FIRST FIRE. the fireplace is free from debris treatments for windows located near the fireplace. Avoid using and any other obstructions that WARNING combustible flowing window... -
Page 4: Starting And Maintaining A Fire
For instance, a long chimney will necessitate the firebox can be diminished by moving the WARNING closing the damper more. To obtain the proper air combustion control from left to right. The combustion, close the damper completely, then primary air is fully opened when the air control Be careful adding wood fuel to open it about 1/4”... -
Page 5: Important Cautions
A. Negative pressure in the house - As the G. Do not burn driftwood which has been in the The chimney shall be inspected at least twice fire burns, air goes up the chimney. This ocean or salt water. The salt will corrode a year during the heating season to determine air must be replaced through leakage into the firebox and chimney. -
Page 6: Fuel
Top Baffle Removal Prior to Cleaning Achieving Clean Burns The Chimney Standard Check the exhaust in about 15 to 20 minutes Cord of 8 Ft. (see below). Large amounts of smoke indicate Wood Before starting to clean your chimney, we (2.4M) an improper burn setting (either too high or too recommend that you remove the top baffle to... -
Page 7: Refractory Installation
The door must be installed only when the installation of the WCT4820WS fireplace is cooled, remove excess ashes. Leave an ash bed completed. All you have to do is fit the male... -
Page 8: Facade Installation
Facade Installation WARNING: THE HEARTH EXTEN- Install the Facade per instructions provided in SION IS TO BE INSTALLED ONLY Facade Kit (ordered separately - see Page 20). AS ILLUSTRATED. Fireplace Framing, Facing And Mantel The construction of the framing, facing, and The crack between the fireplace mantel must be in accordance with the standards and the hearth extension must be... -
Page 9: Glass Care
If possible, you should choose a location where GLASS CARE Gasket Replacement the chimney will pass through the house without Remove the door from the unit (see Page 7) Glass Replacement cutting floor or roof joists (see fireplace dimen- and lay it on a clean unabrasive surface. To The glass used for the fireplace is a high tem- sions Page 10). -
Page 10: Framing Dimensions
Corner Installation Back Wall of Chase/Enclosure Combustion OUTSIDE CHASE Including Finising Materials if any Air Kit 19-1/8” 20-1/2” K (allow space when framing) Rough Framing Face (Unfinished Shown) * Zero Clearance From Back Spacer to Wall FRAMING DIMENSIONS 36-3/8” 924 mm Combustible materials can NOT be used in the space directly above the fireplace. -
Page 11: Nailing Flanges
Insulate Joists Same As Ceiling INSULATED CHASE CONSTRUCTION Storm Collar Roof Support Flashing Draft Stops Attic Radiation Shield Floor Ceiling Firestop Wall NOTE: It is recommended that the chase walls CTDT and floor be insulated in the same manner, Termination using the same insulation, as the rest of the building, below the attic. -
Page 12: Fireplace Blower
FIREPLACE BLOWER Make a 4-1/4” (110 mm) hole in the outside wall of the house at the chosen location. From outside, place the outside air register in the hole (open side down) and fasten the register to the wall with The fireplace comes equipped with a heat acti- screws as shown (see Figure 18). -
Page 13: Heatflow Convection Kit Installation
HEATFLOW CONVECTION KIT INSTALLATION EPA Fireplace - HeatFlo Convection Kit Cat. No. Model Description The wood burning fireplace is approved for use with a Heatflow Convec- F3790 EPA-HEATFLO-KIT EPA Heatflo Conv. Kit tion Kit (hot air ducting system). Table 2 KIT CONTENTS (See Figure 20): TOOLS NEEDED: The Ducted Flex Kit must use both hot air outlets and includes:... - Page 14 It is recommended that the ducted flex kit duct system be installed in HEATFLOW CONVECTION KIT INSTALLATION (continued) the following order: INSTALLATION INSTRUCTIONS: 1. Plan and frame fireplace and outlet locations prior to ducted flex kit For approved installations, the ducted flex kit must meet the following installation.
- Page 15 HEATFLOW CONVECTION KIT INSTALLATION (continued) INSTALLATION NOTES: • When framing for the outlet grill: The minimum height from 5. Fit the wall thimble onto the flex-pipe, prior to the wall thimble installation, and the bottom of the unit to the center of the outlet is 68” (1.7m) fasten together using 4 sheet metal screws.
-
Page 16: Chimney System
Chimney Installation Notes 7. If the chimney extends higher than five (5) feet (1,500 mm) above its 1. The IHP fireplace model WCT4820WS may be installed only with point of contact with the roof, it must be secured using a roof brace. -
Page 17: Only - Snap Pak Chimney
UNITED STATES ONLY 5. The first chimney section through the joist area into attic is to be approximately two (2) feet. If the pipe sections in the attic are not enclosed, an insulation shield (SPIS) must be installed. CHIMNEY INSTALLATION Lower the insulation shield (SPIS) over the SP pipe until the SPIS flange is resting on the joist. - Page 18 INSTALLATION THROUGH A SIDE WALL 1. It is recomended that exterior mounted WALL FIRESTOP AIR CLEARANCE 2” TO (CAT. NO. SPWF) chimneys be enclosed below the roof line COMBUSTIBLES in geographical areas experiencing sus- CHIMNEY PIPE tained low ambient temperatures to help (CAT.
- Page 19 ELBOW INSTALLATION FLASHING INSTALLATION 1. IHP provides a 15 (SPSE15) and 30 (SPSE30) Elbow to allow 1. Continue the SP chimney to the roof. Cut the roof opening, cen- ° ° chimneys to avoid framing members or roof peaks. A maximum tered over the chimney.
- Page 20 TERMINATION Additional support is required above the roof if the chimney height exceeds four (4) feet. Many building codes specify a minimum chimney heights above the Select the proper support for your application-using either a roof roof top. These specifications are summarized in what is known as the brace (Figure 36), or a support band with guy wires (Figure 37) “Ten Foot Rule”.
-
Page 21: Chimney Chase And Multiple Terminations
CANADA ONLY CHIMNEY CHASE AND MULTIPLE TERMINATIONS CHIMNEY INSTALLATION For the purpose of this manual, a chimney chase is considered a part of the chimney system rather than part of a building. The termination must INSTRUCTIONS USING SECURITY be placed a minimum of 18” (460 mm) above the chase. CHIMNEYS ASHT For installations where more than one chimney is located in the same chase or within the same area, we suggest that their terminations be... -
Page 22: Masonry Application Instructions
Follow these steps: INSTALLATION INSTRUCTIONS FOR MASONRY APPLICATIONS FOR BOTH UNITED STATES AND CANADA 1. Position the fireplace in its location. Temporarily install the 30° insu- WARNING: Before starting the installation, the masonry chimney must lated elbow on the top of the fireplace and, using a level, mark with an be inspected by a qualified chimney sweep. -
Page 23: Installation Accessories
OPTIONAL INSTALLATION ACCESSORIES Fireplace Kits Installation Accessories Description Cat./Part No. Description Cat./Part No. Blower (heat activated on/off pre-wired), UZY5 UZY5 Door Kit (Required - Order Separately) Blower motor speed control (wall mount), VRUW VRUW Contemporary Arch Shape Door, Black, BUCBK F1856 Central Forced Air Kit Accessories Outside Air Kit (Required - Included With Fireplace) -
Page 24: Replacement Parts
Fireplace to Flex adaptor and 2 clamps, BISAF BISAF Mantel: 45” (1143 mm) measured from the base of the fireplace. WCT4820WS Metal Fab Collar and Sleeve F4188 Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP. -
Page 25: Chimney Components Lists
SECURITY CHIMNEYS AND DURAVENT - PARTS AND COMPONENTS LISTS ® ® The components listed below must be ordered from Security Chimneys or DuraVent . Contact your Security Chimneys or ® ® DuraVent Distributor or Dealer for ordering information. Security Chimneys ®... -
Page 26: Safety/Listing Label
SAFETY / LISTING LABEL - WCT4820WS... -
Page 27: Warranty
Innovative Hearth Products Superior Brand Wood-Burning Fireplace ® 20 Year Limited Warranty THE WARRANTY Innovative Hearth Products ("IHP") 20 Year Limited Warranty warrants your Superior Brand wood burning fireplace ("Product") to be free from defects in materials and ® workmanship at the time of manufacture. The Product body, firebox and ceramic glass carry the 20 Year Limited Warranty. Ceramic glass carries the 20 Year Limited Warranty against thermal breakage only. -
Page 28: Product Reference Information
WARRANTY Normally, all parts should be ordered through your IHP distributor or dealer. Parts will be shipped at prevailing prices at time of order. Your fireplace is covered by a limited warranty. Please read the warranty When ordering repair parts, always give the following information: to be familiar with its coverage.
