INSTALLATION AND
OPERATION INSTRUCTIONS
WCT4820WS
EPA Wood-Burning Fireplaces
P/N 900093-00 REV. C 06/2016
MODEL
WCT4820WS
This installation manual will enable you to obtain a safe, efficient and
dependable installation of your fireplace system. Please read and
understand these instructions before beginning your installation.
Do not alter or modify the fireplace or its components under any circum-
stances. Any modification or alteration of the fireplace system, including
but not limited to the fireplace, chimney components and accessories,
may void the warranty, listings and approvals of this system and could
result in an unsafe and potentially dangerous installation.
IHP wood-burning fireplaces are designed for use as a supplemental
heater. They are not intended for continuous use as a primary heat
source.
Fireplace, also for use in mobile or
manufactured homes with solid fuel only.
WARNING
• The fireplace cannot be operated without a door
or firescreen. Consult your dealer to select the
correct door or firescreen.
• Important! To assure proper alignment of glass
doors: Install this fireplace in a square and
plumb condition, using shims as necessary at
sides and/or bottom.
• Install the fireplace only as described in these
instructions.
Advertisement
Table of Contents
Related Manuals for Superior Fireplaces WCT4820
Summary of Contents for Superior Fireplaces WCT4820
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS WCT4820WS EPA Wood-Burning Fireplaces P/N 900093-00 REV. C 06/2016 MODEL WCT4820WS This installation manual will enable you to obtain a safe, efficient and dependable installation of your fireplace system. Please read and understand these instructions before beginning your installation. Do not alter or modify the fireplace or its components under any circum- stances.
-
Page 2: Safety Rules And Specifications For Mobile Or Manufactured Home Installation
IMPORTANT! GENERAL SAFETY WARNING WARNING PRECAUTIONS. READ AND UNDERSTAND THESE SAFETY Use care when selecting window Always ensure that the air inlet to RULES BEFORE YOUR FIRST FIRE. treatments for windows located the fireplace is free from debris near the fireplace. Avoid using and any other obstructions that combustible flowing window can block the entrance of air. -
Page 3: Table Of Contents
CONGRATULATIONS! PARTS REQUIRED Fireplace Model WCT4820WS When you purchased your new wood fireplace, you joined the ranks of thousands of individuals whose answer to their home heating needs reflects their concern for aesthetics, • .Decorative Cast Iron Door - Required efficiency and our environment. -
Page 4: Operating The Fireplace
OPERATING THE FIREPLACE Building a Fire (starting and maintaining a fire) Push to Close Fuel - USE SOLID NATURAL WOOD FUEL Air Boost To start a fire, place several crumpled up balls of ONLY. This appliance is designed to burn newspaper in the firebox. -
Page 5: Refueling For Best Performance
REFUELING FOR BEST PERFORMANCE E. Chimney not long enough- The minimum Smoke Detectors Recommended Since there are always several potential sources chimney height is twelve (12) feet (3.7 m) not The WCT4820WS fireplace will operate best if of fire in any home, we recommend installing including the fireplace height. -
Page 6: Maintaining Your Wct4820Ws Fireplace
Dealing With a Chimney Fire Chimney Maintenance NOTE: The use of a firewood moisture meter is recommended to ensure the firewood contains Regular chimney maintenance and inspection Regular chimney inspection and maintenance less than 20% moisture. combined with proper operation will prevent can prevent chimney fires. -
Page 7: Finish Door Casing Care
Burning these materials may result in release DOOR ADJUSTMENT Remove ashes only when the fire is out and of toxic fumes or render the heater ineffective the ashes are cold (24 to 48 hours after the The door may need to be adjusted to be com- and cause smoke. -
Page 8: Glass Care - Replacement
GLASS CARE Gasket Replacement If possible, you should choose a location where the chimney will pass through the house without Remove the door from the unit (see Page 7) Glass Replacement cutting floor or roof joists (see fireplace dimen- and lay it on a clean unabrasive surface. To The glass used for the WCT4820WS fireplace sions Page 10). -
Page 9: Framing, Facing And Mantel
Framing, Facing And Mantel WARNING: THE HEARTH EXTEN- The construction of the framing, facing, and SION IS TO BE INSTALLED ONLY mantel must be in accordance with the stan- AS ILLUSTRATED. dards and the following illustrations (Figures Fireplace 7, 8 and 9): A. -
Page 10: Fireplace And Framing Dimensions
Corner Installation Back Wall of Chase/Enclosure Combustion OUTSIDE CHASE Including Finising Materials if any Air Kit 19-1/8” 20-1/2” K (allow space when framing) Rough Framing Face (Unfinished Shown) * Zero Clearance From Back Spacer to Wall FRAMING DIMENSIONS 36-3/8” 924 mm Combustible materials can NOT be used in the space directly above the fireplace. -
Page 11: Insulated Chase Construction
Insulate Joists Same As Ceiling Insulated Chase Construction Storm Collar Roof Support Flashing Draft Stops Attic Radiation Shield Floor Ceiling NOTE: It is recommended that the chase Firestop walls and floor be insulated in the same Wall manner, using the same insulation, as CTDT the rest of the building, below the attic. -
Page 12: Hot Air Ducting Installation
HOT AIR DUCTING INSTALLATION WARNING: The outlet grills The WCT4820WS fireplace is approved for use Outlet Grill should not be installed fac- with a Gravity Kit. ing upward through a floor. Gravity Kit Danger of burns can result if grills in floor are stepped The gravity kit is designed for double hot air outlets and includes: (See Figures 14 and 15) - 2 telescopic lengths 8”... -
Page 13: Central Forced Air Kit Installation
The duct system must be installed respecting CENTRAL FORCED AIR KIT (NOT TESTED E) Fix the back draft damper to the fan outlet. F) Attach a flexible pipe to the fan / flexible pipe the following: UNDER EPA CERTIFICATION) adapter (square to round) and stretch it up to the location where the heat is required. -
Page 14: Outside Air Kit
OUTSIDE AIR KIT - REQUIRED OUTSIDE CONNECTION During operation, the fireplace requires fresh air for combustion and draws air out of the house. It may starve other fuel burning appliances Aluminum Tape such as gas or oil furnaces. As well, exhaust blowers may compete for Outside air, causing negative pressure in the house, resulting in smoke entering Plastic Cover... -
Page 15: Chimney System
THE CHIMNEY SYSTEM 10. Cut and frame square holes in all floors, ceilings, and roof that the chimney will go through to provide a 2” (50 mm) clearance between Chimney Installation Notes the chimney and any combustible materials. Do not fill this 2” space 1. -
Page 16: Chimney Installation Instructions
CHIMNEY INSTALLATION INSTRUCTIONS Attic Radiation Shield Attic Radiation 1. Cut and frame the holes in the ceiling, floor ASHT / S2100 Shield and roof where the chimney will pass (see HT6103+ / HT6000+ Solid Packed Pipe * Flashing Figure 22). Use a plumb-bob to line up the center of the holes. -
Page 17: Offset Chimney Installation
After reaching the location requiring the AC * elbow, proceed as follows: Air Cooled Chimney Chimney ASHT / HT6103+ / S-2100+ / HT6000+ Collar DuraTech DTC Chimneys Spacer (built 1. Install the first elbow; turn it in the required into flashing) direction. - Page 18 Offset Dimensions Total Height Horizontal Offset Chimney Elbow Offset & One Length Between Elbows Two Lengths Between Elbows 6” Height 8” 12” 18” 24” 36” 48” 8” & 48” 12” & 48” 18” & 48” 24” & 48” 36” & 48” 48”...
-
Page 19: Angled Wall Radiation Shield
ANGLED WALL RADIATION SHIELD When traversing a combustible wall with the chimney at a 30º or 45º angle, an angled firestop or wall radiation shield must be installed. Only one is required. RSMI45 / 6DTC-S45 NOTE: 45º angle for Canada only ( Support ACRS In cold climate locations (climates where temperatures will fall below 32°... -
Page 20: Chimney Support Installation
CHIMNEY SUPPORT INSTALLATION Universal Roof Support 18” (460 mm) 18” (460 mm) When installing a support, slightly lift the chimney system so the weight will lie on the support, not on the fireplace to reduce expansion noises. This support has three possible uses: 1. -
Page 21: Masonry Application Instructions
INSTALLATION INSTRUCTIONS FOR MASONRY APPLICATION Follow these steps: WARNING: Before starting the installation, the masonry chimney must 1. Position the fireplace in its location. Temporarily install the ASHT be inspected by a qualified chimney sweep. elbow on the top of the fireplace and, using a level, mark with an oval the location where the flue liner will enter the masonry chimney. -
Page 22: Installation Accessories
OPTIONAL INSTALLATION ACCESSORIES Installation Accessories Fireplace Kits Description Cat./Part No. Description Cat./Part No. Blower (heat activated on/off pre-wired), UZY5 UZY5 Door Kit (Required - Order Separately) Blower motor speed control (wall mount), VRUW VRUW Victorian Arch Shape Doors, Black, BUVBK F1855 BUCEBWZN Rigid firescreen... -
Page 23: Replacement Parts
SPECIFICATIONS REPLACEMENT PARTS LIST WCT4820WS Replacement Parts Cat. No. Model Description Cat./Part No. F1793 WCT4820WS Baffle refractory (2 pieces) PR-ISO2205 Back refractory PR-SR2203 EPA Estimated Model Emission Rate Heat Output Efficiency Right side refractory PR-SR2204D WCT4820WS 3.7 g/hr 10,442-27,746 btu/hr Left side refractory PR-SR2204G Bottom refractory... -
Page 24: Chimney Components Lists
SECURITY CHIMNEYS™ AND DURAVENT - PARTS AND COMPONENTS LISTS ® The components listed below must be ordered from Security Chimneys International™ or DuraVent . Contact your Security ® Chimneys or DuraVent Distributor or Dealer for ordering information. Security Chimneys International Limited M&G DuraVent 1-800-835-4429 450-973-9999... - Page 25 SECURITY CHIMNEYS™ - PARTS AND COMPONENTS LISTS The components listed below must be ordered from Security Chimneys International™. Contact your Security Chimneys Dis- tributor or Dealer for ordering information. Security Chimneys International Limited 450-973-9999 LL Chimney Lining System** ® Tubinox 2125 Monterey, Laval, Quebec 1-800-361-4909 (USA) Rigid Stainless Steel Liner For Relining A Masonry Chimney, 6”...
- Page 26 OVERFIRING Too little draft (below .05” W.C.) will not allow enough combustion air delivery to maintain a fire well or cause performance problems such as smoking (this may result in improper operation of appli- The damage that occurs from overfiring is not covered under the ance, e.g.
-
Page 27: Warranty
Innovative Hearth Products Superior Brand Wood-Burning Fireplace ® 20 Year Limited Warranty THE WARRANTY Innovative Hearth Products ("IHP") 20 Year Limited Warranty warrants your Superior Brand wood burning fi replace ("Product") to be free from defects in materials and ® workmanship at the time of manufacture. -
Page 28: Product Reference Information
WARRANTY Normally, all parts should be ordered through your IHP distributor or dealer. Parts will be shipped at prevailing prices at time of order. Your fireplace is covered by a limited warranty. Please read the warranty When ordering repair parts, always give the following information: to be familiar with its coverage.
