TECHNICAL FEATURES

LIFE home integration reserves the right to make changes to technical characteristics at any time and without prior notice, without changing its intended
use and function.
ACER: Irreversible electromechanical operator for sliding gates with optical/magnetic encoder and built-in ECU
Version:
Built-in ECU
Power supply
Motor power supply
Motor power
Power input from mains 230V / Max. motor absorption at pick-up 24 V
Capacitor
Thrust
Lubrication
Thermal protection device
Limit switch
Encoder
Speed
External toothed wheel module
Number of teeth external toothed wheel
Work cycle
Nominal work time
Battery recharge time (optional)*
Opening cycles with charged battery*
Operating temperature
Protection class
Motor insulation class
Assembly
Dimensions / weight
Dont use in acid, saline or potentially explosive environment
Max gate weight (lev el gate)
* for 2 Ah batteries (optional and installed).
1.0 INSTALLATION
1.1 Operator release
Attention:
• The fitter must permanently fix the label describing the manual release operation close to the manual release key.
• The activation of the manual release could cause an uncontrolled movement of the gate in the event of mechanical damage or unbalanced
conditions.
• Before performing the manoeuvre switch off the electricity supply to the automation.
• To avoid breaking the key, do not apply excessive force.
a) Slide the lock protection cover (1). See fig. (1.1).
b) Insert the key (2) in the lock and turn to the right through 90°.See fig. (1.2).
c) Gently pull the key outwards until the hatch is protruding, then pull outwards until it stops. See fig. (1.3).
d) The operator is now free and can be moved by hand. A microswitch assembled on the blockage device prevents the motor from operating when
the power comes back on.
e) To reconnect the transmission, turn the opposite way and move the gate manually until it hitches up.
