Meter Description
1.
Upper Housing
2.
Interface Protec�ve Cover
3.
Lower Housing
4.
USB Type-C Interface Connector
5.
SD Card Slot
6.
Tripod Mount
7.
Laser Emission Window
8.
LED Light
9.
Infrared Camera Lens
10. Trigger/Image Capture
11. LCD Display
12. OK Bu�on
13. Up Bu�on
14. Power/Back Bu�on
15. Down Bu�on
