User Manual
IRTC600
Thermal Imaging Camera
Introduction
Congratulations on your purchase of the Triplett
IRTC600 Thermal Imaging Camera. This instrument
is useful in many applications such as preventative
maintenance, troubleshooting of electrical and
HVAC systems, mechanical breakdowns, water leaks
and moisture buildup, heat loss from missing
insulation and faulty windows/doors, automotive
repair, and other places to find leaks and hot spots.
With proper care the instrument will last for many
years of accuracy and service.
Safety
Please read the safety information carefully before attempting to
operate the meter. Failure to do so could cause personal injury
or damage to the meter. Please read this manual carefully to
ensure safe and correct use.
Do not attempt to repair this device:
Please contact Triplett Technical Support for any issues
Product Support — Triplett Test Equipment & Tools
Considerations
Please observe the following guide in order not to damage the
product:
Don't assemble or dismantle the product without permission.
The product is a type of super precise equipment. Don't
try to dismantle, assemble, or remodel any part of the
product. Repair of the product should be made by
technical personnel designated by Triplett service
technicians only.
Advertisement
Table of Contents
Related Manuals for Triplett IRTC600
Summary of Contents for Triplett IRTC600
- Page 1 Please read this manual carefully to ensure safe and correct use. Do not attempt to repair this device: Please contact Triplett Technical Support for any issues Product Support — Triplett Test Equipment & Tools Considerations...
-
Page 2: Charging Battery
Avoid damage to probe of the product Charging Battery Note: don’t put the product close to strong heat source directly **NOTE: Product Clicking – Sensor is automatically calibrating for Use USB data line to charge: image, The product has built-in chargeable 26650 lithium batteries. When the product works, there is light sound of clicking When the battery level is low, the top right of the screen will display every several seconds. - Page 3 Meter and Keypad Description Specifications Model IRTC600 3.5 ″ full angle TFT Display screen display screen Infrared image resolution 220×160 Field angle 35°×26° Visible image resolution 300,000 pixels LCD resolution 320×240 Shortest focus length 0.15M 0.07℃ Thermal sensitivity Temperature -20℃ to 300℃ (-4°F to 572°F)
- Page 4 File format Micro USB 2.0 Power supply Built-in chargeable 26650 battery Working time 2-3 hours Automatic power-off time Selectable: 5 minutes/20 minutes/ not power off automatically Unit, Language, Date, Time, Information Setting command Language English, Chinese, Italian, German Product size 248mm×97mm×112.8mm Product weight 588 g...
- Page 5 Operation Maximum and Minimum Temperature Display POWER ON/OFF • Press and hold the “ ” button for more than 3 The highest/ and lowest temperature is shown at the bottom seconds to turn the Thermal Imaging on or off. of the screen over the image after normal start up, pressing the “...
-
Page 6: Recording Video
Press the left of “MENU” key and the menu bar appears. They are “Image Recording Video registration”, “Images”, “Videos”, “Color palette”, “Emissivity” and Long press or pull of the image capture trigger the screen will “Settings” submenus. prompt “record video?”, if you select “Yes” at this time, please press the SELECT/ENTER button and video will start to be recorded. -
Page 7: Deleting Images
Video (Submenu) Images (Submenu) View video View image Press the “ ” button to enter the main menu and select “ button to enter the main menu and select “ Press the ” (videos) in the main menu. ” (images) in the main menu. 171229-105030 171229-105030 171229-105031... - Page 8 Color Palette (Submenu) Selecting Color Palette Color palette Description Color palette Spectra The palette can be used to change the pseudo-color display of the Iron infrared image on the display. Some tune Swatches are better suited Cool for specific applications and can be set up as needed. The palette is White divided into rainbow, iron red, cool, white hot, black hot, five palettes.
-
Page 9: Emissivity Setting
Emissivity Setting Emissivity (Submenu) The product is provided with four types of object measurement modes: Emissivity description Matt (0.95) Semi-matt (0.85) The emissivity of the product can be adjusted from 0.01 to 1.00 with the Semi-glossy (0.60) default value of 0.95. Many common objects and materials (such as Glossy (0.30) timber, water, skin and textile fabric) can reflect the heat energy According to the characteristics of the measured objects, users may set... -
Page 10: Settings (Submenu)
If you select "self-defined" emissivity, press the “SELECT/ENTER” ” button to Settings (Submenu) enter the editing state. Press “ ” / “ ” Keys to select the number to be changed, press “ ” “ ” Keys to change the value. - Page 11 Auto Power OFF (APO) Setting Time Setting As shown in the figure, after selecting “ ” (set time), press “ ” After entering the “Settings” Submenu Select “Auto Shutdown”. The selections in the navigation key to enter the setting time. available are No, 5 mins or 20 minutes.
- Page 12 T hermal Analysis Software Software Installation and Operation 1. Connect the product with a USB cable, and then connect to the computer Open the removable disk in the computer, find the "INSTALLATION PACKAGE" folder and open it, and click to install the software. 2.
-
Page 13: Icon Introduction
Software User Interface Introduction Icon Introduction 1. Select the language in the upper right corner of the interface, you can choose Chinese, English, and switch between the two languages. 1. " " icon, take the temperature of the thermal image. 2. - Page 14 Warranty Triplett / Jewell Instruments extends the following warranty to the original purchaser of these goods for use. Triplett warrants to the original purchaser for use that the products sold by it will be free from defects in workmanship and material for a period of (1) one year from the date of purchase.
